Installation Instructions Assembly Name MiX interface cable Assembly P/N N/A – prototype only Revision History Date Name Change Description 10 Mar 2017 Jess Benning First release Parts Part Image 5m USB to RS232 Cable Page 1 of 4... - Page 2 USB clamp maintenance cover Cable Tie Page 2 of 4...
- Page 3 Assembly Steps Step Details Step Image 1. Remove existing maintenance panel using a T6 torx screwdriver 2. Plug in USB end of the USB to RS232 cable Page 3 of 4...
- Page 4 3. Fit USB clamping maintenance cover. 4. Tighten the cover screws. Ensure the connector mould is fitted into the slotted end of the cover 5. Apply cable tie, tighten and cut Ensure the cable tie is on the cover side of the barb. 6.
