Revision 1.0
10/2017
HTC Gateway
Quick Start Guide
A-HRIO
REQUIRED SOFTWARE
The HTC Gateway requires Aparian Slate software to setup and configure. The
software installation can be found at www.aparian.com/software/slate.
MODULE INSTALLATION
The HTC Gateway requires input power of 18-28Vdc. The wiring of the power
connector can be found in the wiring diagram below. The HTC Gateway communicates
on both Ethernet and Hitachi RIOH and ROW. The wiring of the Hitachi connector can
be found in the wiring diagram below. The Ethernet connector should be wired
according to industry standards which can be found in the additional information
section.
Document No. D133-011
Page 1 of 2
Advertisement
Table of Contents
Summary of Contents for APARIAN A-HRIO
-
Page 1: Quick Start Guide
Quick Start Guide A-HRIO REQUIRED SOFTWARE The HTC Gateway requires Aparian Slate software to setup and configure. The software installation can be found at www.aparian.com/software/slate. MODULE INSTALLATION The HTC Gateway requires input power of 18-28Vdc. The wiring of the power connector can be found in the wiring diagram below. -
Page 2: Network Setup
DHCP server to assign an Ethernet network address to the module. Refer to the additional information section for DHCP servers. Once the module has been assigned an Ethernet address the user can configure the module with Aparian Slate. ADDITIONAL INFORMATION The following resources contain additional information that can assist the user with the module installation and operation.
