- Page 1 Assembly and Operating Instructions Please read this manual carefully and keep it for future reference. 'Standard' Swimming Pools...
- Page 2 Assembly and Operating Instructions 'Standard' Pools KURZANLEITUNG / QUICK START GUIDE / NOTICE SOMMAIRE / GUIDA RAPIDA / BEKNOPTE HANDLEIDING / KORTFATTAD BRUKSANVISNING / STRUČNÁ PŘÍRUČKAG / STRUČNÝ NÁVOD / KRATKA NAVODILAG / GYORS ÚTMUTATÓ / MANUAL CU INSTRUCŢIUNI PE SCURT Possible –...
- Page 3 Assembly and Operating Instructions 'Standard' Pools FOR PARTIAL INGROUNG/INGROUND FOR FIGURE-8 SHAPED POOLS INSTALLATION Schichtweise Betonhinterfüllung Graben für Stahlträger Concrete backfill in layers Trench for steel girder Remblai en béton par couches Creusement pour poutre en acier Riempimento calcestruzzo a strati Scavo per trave d‘acciaio Beton laagsgewijs vullen Greppel voor stalen drager...
- Page 4 Assembly and Operating Instructions 'Standard' Pools Stahlmantel aufstellen Stahlwand verschrauben Installation of steel wall (jacket) Assembly of steel wall Mise en place de la paroi en acier Assemblage de la paroi en acier Disporre la lamiera Avvitare la parete Stalen mantel opstellen Stalen wand vastschroeven Ställa upp stålmanteln Skruva ihop stålväggen...
- Page 5 En utförlig anvisning på ditt språk finns att ladda ner på Internet under adressen http://download.waterman-pool.com Podrobné pokyny ve vašem jazyce jsou k dispozici na internetu jsou pro vás připraveny pod http://download.waterman-pool.com Podrobný návod vo vašom jazyku nájdete na internete na stránke http://download.waterman-pool.com celotna navodila v Vašem jeziku najdete na spletni strani...
-
Page 6: Electrical Safety
Assembly and Operating Instructions 'Standard' Pools ELECTRICAL SAFETY • • The power supply for your Free-standing filter systems/pumps exceeding 12 swimming pool must be protected volts must be installed with a minimum distance by means of a residual current of 3 m from the pool, and a distance of 3.5 from circuit breaker (30 mA). - Page 7 Assembly and Operating Instructions 'Standard' Pools SAFE USE OF THE SWIMMING POOL • • Dives into the pool are not allowed, never jump Place life-saving equipment (bars, safety buoys, into shallow water (danger of serious injuries or first aid emergency numbers) near the pool. •...
- Page 8 Assembly and Operating Instructions 'Standard' Pools PURCHASE INFORMATION / TECHNICAL DATA ROUND POOLS Note: This pool conforms to the EN16562-1 standard. It is supplied as above- ground pool kit. Time required Diameter Height Volume Water Max. Max. for setup (with- No.
- Page 9 Assembly and Operating Instructions 'Standard' Pools Note: This pool conforms to the EN16562-1 standard. It is supplied as above- ground pool kit. Time required Length Width Height Volume Water Max. Max. for setup (with- No. of people (meter) (meter) (meter) (liters) surface depth of water...
-
Page 10: Choosing A Location
Assembly and Operating Instructions 'Standard' Pools Before setting the pool up, check that all required parts are available according to the attached parts list: 1 x Steel wall 1 x Steel wall Round pool kits: Figure-8 shaped pool kits: 1 x Liner 1 x Liner 1 x Pack of profile rails 1 x Pack of profile rails... - Page 11 Assembly and Operating Instructions 'Standard' Pools PREPARING THE TOP RAIL FOR A ROUND POOL The best substrate for your swimming pool is a Dimensions swimming pool Length of concrete slab (thickness approx. 20 cm), which must cord be perfectly level (terraces, paved areas, etc. are 300 cm 160 cm critical/not suitable, since they use slopes).
- Page 12 Assembly and Operating Instructions 'Standard' Pools INSTALLING THE FLOOR PROTECTION FLEECE After the foundation has been properly prepared and is perfectly level, you must cover the ground with a synthetic floor protection fleece (not included in the delivery). Clean the surface thoroughly once again and remove all stones/unevenness, which could be dangerous for the liner.
- Page 13 Assembly and Operating Instructions 'Standard' Pools STEEL WALL ASSEMBLY Assemble the ends of the steel wall securely with the screws (from the inside to the outside and connected to washer and nut). To provide additional stabilization, assemble also the two fasting rails both from the outside and the inside as shown in the illustration.
- Page 14 Assembly and Operating Instructions 'Standard' Pools POOL SETUP (FIGURE-8 SHAPED POOLS) There are 3 different mounting options: • Above ground / ground level • Semi-inground Possible – but not recommended! (Attention, the built-in part of the pool requires a lean concrete backfill.) •...
- Page 15 Assembly and Operating Instructions 'Standard' Pools It is mandatory to provide a trench with a width of 240 mm and a depth of 255 mm in the middle of the concrete slab. This is where the steel slab will be inserted (recessed) and fixed with concrete later.
- Page 16 Assembly and Operating Instructions 'Standard' Pools INSTALLING THE FLOOR PROTECTION FLEECE AND THE FLOOR RAILS After the substrate has been prepared, spread out the floor protection fleece (not part of delivery for every pool). Either allow the edges to overlap (which may be visible through the liner) or place the fleece end-to-end and fix it with double-sided adhesive tape from below.
-
Page 17: General Information
Assembly and Operating Instructions 'Standard' Pools TIPS FOR WINTERIZING All our steel wall swimming pools are winterproof. protection cap, and remove the hose from the They can be filled with water also in the winter skimmer so that rainwater is drained. Underground (water level in the pool at least three-quarters). -
Page 20: Warranty
As a matter of course, our customer service is Waterman Customer Service available for you also after the warranty period. Bahnhofstr. 68, 73240 Wendlingen/Germany Tel.:...
