Mi True Wireless Earbuds
User Manual
This version is for private use only and should not be distributed.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mi True Wireless Earbuds TWSEJ02LM and is the answer not in the manual?

Questions and answers

Summary of Contents for Xiaomi Mi True Wireless Earbuds TWSEJ02LM

  • Page 1 Mi True Wireless Earbuds User Manual This version is for private use only and should not be distributed.
  • Page 2: Product Overview

    Product Overview Charging Case Charging Port Charging Pins Charging Indicator Charging Case Earbuds Touch Panel Indicator Microphone Ear Tips The earbuds come with the size M of ear tips installed, you can switch to size S or L if the installed size does not suit your ear.
  • Page 3 Wearing Gently insert the earbud into the ear canal, make sure it is not easy to sway when shaking your head. Please pay attention to adjust the earbud to expose the microphone during calls. During calls, point the earbud's microphone toward your mouth to make the call clearer. This version is for private use only and should not be distributed.
  • Page 4 Charging Before using the device, please tear off the protective film from the earbuds' contact points to fully charge them and their charging case. Use a USB charging cable to charge the charging case. Protective Film Battery Level of Charging Case Indicator Status Low Battery The indicator of the charging case blinks red every 3 seconds.
  • Page 5: Turning Off

    Turning On Once you remove the earbud from the charging case, it automatically turns on. While the earbud is off, press and hold the touch panel for 1 second till the indicator turns white. Press and hold for 1 second Turning Off Once you place the earbud into the charging case, it automatically turns off.
  • Page 6 Note: All earbuds have been reset at the factory, and can be paired with a device directly. Press and hold for 1 second to turn on Manual Connection: When the earbuds are turned off, manually turn on both earbuds. Both indicators will quickly blink white, and the indicator of the right earbud will slowly blink white after the connection between the earbuds has been established.
  • Page 7: Function Overview

    Reset Earbuds If the earbuds cannot connect properly, please carry out the following steps to reset: Remove the earbuds from the charging case, and make sure they are turned off. Press and hold the touch panel on both earbuds for about 15 seconds. After the indicator alternately blinks red and white three times for twice, then release the panel and place the earbuds back in the charging case.
  • Page 8: Play/Pause Music

    Play/Pause Music While standby, gently tap the touch panel to play/pause music. Note: A music player needs to be running in the background. Turn On Voice Assistant While standby, gently tap the touch panel twice to turn on the voice assistant. Note: The function of voice assistant and quick wake-up must be supported and enabled on your device.
  • Page 9: Specifications

    Mute/Unmute During calls, gently tap the touch panel twice to mute/unmute. Specifications Name: Mi True Wireless Earbuds Model: TWSEJ02LM Operating FP: +4 dBM Max. Output Power: 2402–2480 MHZ Earbuds Dimensions: 23 × 14.5 × 13 mm Wireless Range: 10 m (in an obstacle-free environment) Battery Capacity: 43 mAh (per earbud) Input: 5 V ⎓...
  • Page 10 Features Bluetooth 5.0, compatible with most Bluetooth-enabled devices on the market Bluetooth 5.0 Touch-operated for an enhanced user experience 2-in-1 storage and charging function Independent wireless design Illustrations of product, accessories, and user interface in the user manual are for reference purposes only.
  • Page 11: Weee Information

    5. Do not clean this product with alcohol or other volatile liquids. 6. Avoid any contact with liquids. 7. Excessive sound pressure from the earbuds can cause hearing loss. EU DECLARATION OF CONFORMITY Hereby, [Name of manufacturer] declares that the radio equipment type [designation of type of radio equipment] is in compliance with Directive 2014/53/EU.
