Summary of Contents for TECHLIGHTING 700FJPJLD7 Series
Page 1
920FJPJLD7C Installation Instructions for Combination FreeJack and Power Jack Canopy 700FJPJLD7_ MULTI CANOPIES ENERAL RODUCT NFORMATION This product is suitable for dry locations only. IMPORTANT! If the canopy is wood, do not install any head or pendant closer than 12 inches to this canopy. C AUTION —...
Page 2
Install the Canopy SAFETY CABLE SAFETY BRACKETS Line up an anchor with the center of a backplate hole and push the anchor in up to the threads. Screw the anchor the rest of the way in with a screwdriver. Secure the backplate to the anchors with the screws and washers provided.
Page 3
Install the FreeJack Fixtures FREEJACK PORT FREEJACK CONNECTOR Screw a FreeJack connector into each FreeJack port. Install the Power Jack Fixtures CANOPY CONNECTOR FIXTURE POWER JACK Connect the black fixture wire to the hot power line wire with a wire nut. Connect the white fixture wire to the neutral power line Line up the fixture Power Jack with the canopy connector.
