- Page 1 User Manual 4KVIEWER Series HDMI 1.4 4K Quad Multi View 4KVIEWER-HDMI-4 · 4KVIEWER-KVM-4 4KVIEWER Series 4KVIEWER-HDMI-4 · 4KVIEWER-KVM-4 HDMI 1.4 4K Quad Multi View...
-
Page 2: Rohs
EMC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Package Contents
Package Contents The 4KVIEWER-HDMI-4 consists of: 1 4KVIEWER-HDMI-4 1 DC 12@3A Power 1 IR Remote Control 1 User Instructions The 4KVIEWER-KVM-4 consists of: 1 4KVIEWER-KVM-4 1 DC 12@3A Power 1 IR Remote Control ... -
Page 4: Table Of Contents
CONTENT User Manual ..........................1 EMC Information ........................i RoHS ............................i Package Contents ........................ii About this Manual ........................1 Chapter 1 ..........................2 Introduction ..........................2 Overview ..........................2 Features..........................3 Requirements ......................... 4 Operating Systems ......................... 5 Components ........................... - Page 5 Picture in Picture ......................23 Feature Functions ........................ 24 Transparent Function (Picture in Picture Mode)............24 Disable Function......................25 Audio Selections......................26 Resolution Selections ....................27 Preset Configuration ......................28 The OSD Menu ........................28 Specifications ........................29...
-
Page 6: About This Manual
4-Port USB 4K-Quad View Switch-HDMI An overview of the information found in the manual is provided below. Chapter 1, Introduction, introduces you to the 4KVIEWER series. Its purpose, features and benefits are presented, and its front and back panel components are described. -
Page 7: Chapter 1
IR remote control, On-Screen Display (OSD), through hotkey combinations entered from the console keyboard and mouse. The 4KVIEWER series allows users to access 4 computers/devices from a single console, consisting of a USB keyboard, USB mouse, and HDMI monitor. You can connect to monitor –... -
Page 8: Features
Features Multi-view modes allow users to view and control up to four video channels on one screen with display modes including Quad View, Picture in Picture (PiP), Picture by Picture (PbP), and Picture on Picture (PoP) Easy resizing and/or repositioning of PiP or PbP to suit users’ viewing needs ... -
Page 9: Requirements
Requirements Refer to the table below to prepare the required devices, equipment, and cables to set up a 4KVIEWER series. 4KVIEWER-HDMI-4 4KVIEWER-KVM-4 1~5 x HDMI cable 1 ~5 x HDMI cable Console 1 x USB mouse 1 x USB mouse ... -
Page 10: Operating Systems
Operating Systems Supported operating systems are shown in the table below: Version Windows 7, 8.1, 10 RedHat CentOS 7, Ubuntu 16.04 Linux SuSE OpenSuSE 13.2 UNIX Novell Netware MacOS 10.12... -
Page 11: Components
Components 4KVIEWER-KVM-4 Front View Component Description When power and the source to be connected, the indicator Power & HDMI Input LED light will be bright. Press this to invoke the on-screen display (OSD) Menu. Menu When the OSD Menu is enabled, press the OSD button to Button go back to the previous menu/submenu. -
Page 12: 4Kviewer-Kvm-4 Rear View
4KVIEWER-KVM-4 Rear View Component Description Power DC jack Connect 12V DC power supply to this port. Connect HDMI cable between this port and display HDMI Output Ports device. Keyboard and Plug Keyboard and Mouse to access KVM function Mouse Ports Connect HDMI cable between this port and source HDMI Input device. -
Page 13: 4Kviewer-Hdmi-4 Front View
4KVIEWER-HDMI-4 Front View Component Description Power & HDMI When power and the source to be connected, the Input LED indicator light will be bright. OSD Button To control OSD function via these button To receives signals from the IR remote control through an IR extension, which can be purchased IR Receiver separately... -
Page 14: 4Kviewer-Hdmi-4 Rear View
Rear View 4KVIEWER-HDMI-4 Component Description DC 12V Connect 12V DC power supply to this port Connect HDMI cable between this port and display HDMI Output device. Keyboard and Plug Keyboard and Mouse to access KVM function Mouse Ports Connect HDMI cable between this port and source HDMI Input device. -
Page 15: Chapter 2
Chapter 2 Hardware Setup Installation 4KVIEWER-HDMI-4 Single Station Installation 1. Link DC power 12V@3A 2. Link Ethernet cable CAT-5e to Ethernet Hub or pc Control Quad-View HDMI Switch 3. Link Keyboard and Mouse Control Quad View HDMI Switch 4. HDMI Cable to link Source 5. -
Page 16: 4Kviewer-Kvm-4 Single Station Installation
4KVIEWER-KVM-4 Single Station Installation 1.Link DC power 12V@3A 2.Link Ethernet cable CAT-5e to Ethernet Hub or pc Control QV HDMI Switch 3.Link Keyboard and Mouse Control Quad View HDMI Switch 4.HDMI Cable to link Source 5.HDMI Cable to link Source 6.HDMI Cable to link Source 7.HDMI Cable to link Source 8.Link to TV(4k@30) -
Page 17: Chapter 3
This section includes switching methods, display modes and preset configuration. It explains the basic components used to switch and display computers connected to the 4KVIEWER series Switch. Identifying the Source Device The channel information can be shown on the top in the screen. -
Page 18: Switching
Switching The 4KVIEWER Switch features its independent switching: It offers user to switch KVM (keyboard, video, mouse) on computer and audio independently between different computers. It means to work on one computer (KVM) while access the audio to another (stereo audio). -
Page 19: Led Display
LED Display The front panel has three LEDs sections that indicate the power, HDMI sources and the computer USB connection status. The LEDs light green or orange depending on which source is being accessed on what computer, as explained in the table LED Sections Indication Power... -
Page 20: Hotkey Switching
Hotkey Switching To reach OSD and KVM functions using hotkeys from the keyboard. NOTE : Above Hotkey operates in 4KVIEWER-HDMI-4... -
Page 21: Ir Remote Switching
IR Remote Switching You can operate and select OSD with the IR remote control. Point the remote at the 4KVIEWER and press the button you want to access. To identify or to hide the AVsource Enter to OSD Sub-manual bar Enter a choice you have made Navigation Arrow 4. -
Page 22: Osd Switching
OSD Switching To operate the OSD menu bar by a console mouse with following steps: 1. Click one time right mouse button to display, to return or to hide the OSD main-menu bar. The OSD menu bar will appear at bottom center of the screen. - Page 23 4. Click one time left mouse button to access and enter the function of your selected icon. 5. Same steps as above 1~4 for HD resolution, Audio and Disable Images on OSD. 6. Move the cursor to the PC image that you want to use KVM function. 7.
-
Page 24: Display Modes
Display Modes You can view multiple computers connected to the 4KVIEWER series on the same screen, in different layout by setting the display mode. This section introduces you to different display modes, and ways of switching to them. Quad View A quad view displays four computers on the monitor in 3 default layouts: Equal sized windows, Picture by Picture-Quad in 2 type of layouts. - Page 25 Press “Alt” + “F1~F3” for layout selections. Keyboard Hotkey See Page 20 for operation of Hokey switching Console In the OSD, one time right mouse button for main-menu, Mouse click on for sub-menu and select layout See Page 22-23 for operation of OSD Switching.
-
Page 26: Full Screen
Full Screen A full-screen view displays one computer in full extension. Total 4 Default full-screen layouts. Method Actions Front press Panel press for sub-menu press Button press for selection enter Press “Menu” for sub-menu Remote Control for selection ... -
Page 27: Free-Style
Free-Style A free style of display includes picture-on-picture (PoP) up to 4 computers in separate windows on the monitor as default layout. Using the console mouse to resize and re-position each window on the screen and can be saved. Method Actions Front Panel ... -
Page 28: Picture In Picture
Picture in Picture A quad PiP view has up to 4 computers on the monitor with one computer as the main display and the other three which can be resized and re-positioned by using the console mouse overlapping the main display in inset windows. Method Actions Console Mouse In the OSD, one time right mouse button for main-menu,... -
Page 29: Feature Functions
Feature Functions This section explains the 4KVIEWER series feature functions including: Transparent Function, Disable Functions, Audio and Resolution selections. Transparent Function (Picture in Picture Mode) At PiP display, one computer as the main display and others as sub-display can be transparent by mouse wheel roll down or up. The transparent function... -
Page 30: Disable Function
Disable Function Method Actions Front Panel Button press press Press sub-menu press to select a channel enter IR Remote Press “Menu” press right button Control up button for sub-menu to select a disable channel , then press Press “Alt”... -
Page 31: Audio Selections
The audio is independent from visuals. You can select and play an audio source from up to 4 HDMI inputs while display from a different source. 4KVIEWER series also offers auto-play audio from the full-screen source in a PIP mode. -
Page 32: Resolution Selections
See Page 22-23 for operation of OSD Switching. Resolution Selections 4KVIEWER series supports up to 4K/30. It offers 2 resolution options for display: 1080p or 4K. When the resolution of the monitor does not support 4K, the screen will be in black for 8-9 seconds before display 1080p again. -
Page 33: Preset Configuration
Preset Configuration Steps Description 1. Configure the display setting as required under the Free-style mode. 2. Move the console mouse to the current Free-style icon. 3. Click one time left mouse button 4. The “Tick and Cross” bar will appear. 5. -
Page 34: Specifications
Specifications Function 4KVIEWER-HDMI-4 4KVIEWER-KVM-4 Computer Connections Front-panel Pushbuttons, Hotkeys, IR Remote Control, On- Port Selection screen Display (OSD), Commands 1 x USB Type A Female 1 x USB Type A Female Keyboard (Black rear panel) (Black, rear panel) Console Video 1 x HDMI 1 x HDMI Ports...
