Summary of Contents for CAME XVia STAND-ALONE
- Page 1 TRIPOD TURNSTILES FA 00384 -E N INSTALLATION MANUAL TAND LONE English...
- Page 2 WARNING! important safety instructions for people: READ CAREFULLY! PARTS ALL ANCHORING POINTS INCLUDING CABLES AND ANY ACCESSIBLE CONNEC REMISE • T TIONS EEP ANY HINGES MOVING JOINTS AND FRICTION POINTS PROPERLY LUBRI HIS PRODUCT SHOULD ONLY BE USED FOR THE PURPOSE FOR WHICH IT WAS •...
-
Page 3: Intended Use
LEGEND This symbol shows which parts to read carefully. ⚠ This symbol shows which parts describe safety issues ☞ This symbol shows which parts to tell users about. The measurements, unless otherwise stated, are in millimeters. DESCRIPTION Motor powered bidirectional turnstile made of AISI 304 satin fi nished stainless steel complete with control board, LED directional arrows, fall-away arm and automatic resetting system, and anti-trespassing system. -
Page 4: General Installation Guidelines
Dimensions 1176 Ø 40 GENERAL INSTALLATION GUIDELINES ⚠ Only skilled, qualified staff must install this product. Preliminary checks ⚠ Before installing the turnstile, you need to: • if needed, set up corrugated tubing for the electrical cables to pass through; •... -
Page 5: Tools And Materials
Tools and materials Make sure you have all the tools and materials you will need for installing in total safety and in compliance with applicable regulations. The figure shows some of the equipment installers will need. INSTALLATION The following illustrations are mere examples. The space for fastening the turnstile and accessories varies depending on the overall dimensions. It is up to the installer to find the most suitable solution. - Page 6 Preparing the turnstile Open the locks and remove the top cover, lifting it from the front and pushing it back. ❶❷ The power-supply and control unit is inside the left leg ❸; you can move it to the right leg, after disconnecting it from the devices. Be careful about the cable lengths, when reconnecting the devices.
- Page 7 Preparing the (PSXV03) fixed-arm turnstile Remove the three ABS covers. ❶ Open the arms to hook up the fastening brace, by turning the latter. ❷❸ Fasten the braces using the supplied M4x8 bolts. ❹ Tighten all nuts and bolts. ❺❻ Refit the ABS covers and fasten them using the 3.9x16 screws.
- Page 8 Fastening the turnstile Position the turnstile and fasten it soundly. Fastening the tripod Open the arms until they mechanically latch. ❶ Fasten the tripod to the rotating mechanism by using the supplied M8x20 nuts and bolts. ❷ Fasten the small cover using the supplied M4x25 bolt ❸...
-
Page 9: Electrical Connections
ELECTRICAL CONNECTIONS ⚠ Before acting on the control board, cut off the main power supply. The 24 V DC output power is of the SELV type. All connections are quick-fuse protected. FUSE TABLE TOR500 -> Motor (A) 3 - F ->... -
Page 10: Power Supply
Power supply Hardwire the plug to the power-supply cable. ❶ Default power supply: 230 V AC To switch to 120 V current, unplug the power supply and control unit to access, via the lateral hole, the selection lever, and flick it upwards. ❷❸ ⚠... -
Page 11: Emergency Devices
Command and control devices Command for counter-clockwise operation (NO), with local and remote device. For counter-clockwise release of the turnstile Command for clockwise operation (NO), with local and remote device. For clockwise release of the tripod. Emergency devices STOP button (NC). It allows the turnstile to be locked and then repositioned. - Page 12 PROGRAMMING You can program directly on the control panel, by opening the turnstile body, or, by installing the PSXVA5/6 kit, with the RFID Master card. Menu map Start programming by first performing function A 3 [Calibrate rotation]. F 77 Turnstile operating mode Total stop F 78 Emergency release Input 2-CX setup...
- Page 13 Description ( the default values appear with a black backdrop ) Function F 77 Turnstile operating mode. Setting the activity status for each transit direction. Selection IN (entry) OUT (exit) Locked Locked LEGEND: Locked Controlled • Controlled = passage allowed only for Controlled Locked authorized users (green arrow lit up);...
- Page 14 Description of programming commands with RFID cards The PSXVA5/6 kit if for programming even with an RFID Master card. * The first [U0001] and the second [U0002] cards both become master cards and can be memorized only from the control panel (see Memorize Users function).
- Page 15 U 3 - Delete all users • Enter the programming mode and select Delete all users [U3] and then [1]; • once you activate the function, the flashing wording [CLrA] will appear; • press the [ENTER] key or swipe the master card past the sensor to confirm deletion; the wording [CLr] will appear on the display to confirm al users have been deleted (excluding master cards);...
-
Page 16: Final Operations
Before doing any maintenance, cut off the power supply, to prevent any hazardous situations caused by accidentally activating the operator. To properly maintain the AISI 304 stainless steel, refer to the stainless steel cleaning part of the 119RW48 manual (https:\docs.came.com and type inox). -
Page 17: Troubleshooting
• Contact technical assistance DISMANTLING AND DISPOSAL ☞ CAME S.p.A. applies a certified Environmental Management System at its premises, which is compliant with the UNI EN ISO 14001 standard to ensure the environment is safeguarded. Please continue safeguarding the environment. At CAME we consider it one of the fundamentals of our operating and market strategies. Simply follow these brief... - Page 18 List of registered users 1/..MASTER 1 MASTER 1 U0001 U0001 U0050 U0050 U0099 U0099 MASTER 2 MASTER 2 U0002 U0002 U0051 U0051 U0100 U0100 U0003 U0003 U0052 U0052 U0101 U0101 U0004 U0004 U0053 U0053 U0102 U0102 U0005 U0005 U0054 U0054 U0103 U0103...
- Page 19 List of registered users ../..
- Page 20 CAME S.p.A. CAME S.p.A. Via Martiri Della Libertà, 15 Via Cornia, 1/b - 1/c 31030 Dosson di Casier Dosson di Casier 33079 Sesto al Reghena Sesto al Reghena Treviso Treviso - Italy Pordenone Pordenone - Italy (+39) 0422 4940 (+39) 0434 698111...
