MusicMan BT Dongle User Manual

Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
Please find the Declaration of Conformity for this device under following internet-link:
Read the instructions carefully before using the device.
Charge the battery about 3–5 hours before using the device the first time.

Features

Support routes calls and music from a smartphone through car speakers
Seamlessly switches between calls and music
Bluetooth 3.0 + EDR for superior wireless performance
Built-in high performance stereo audio codec
Supports HSP (Headset Profile), HFP (Hands-Free Profile), A2DP (Advanced Audio Distribution
Profile), AVRCP (Audio / Video Remote Control Pofile)
Supports AUX-IN when connected to car stereo
Embedded microphone mounts anywhere on the dashboard for the best voice pick-up
Accessories: Micro USB charging cable, 3.5mm – 3.5mm phone jack cable, User Manual
MusicMan
User Manual
www.technaxx.de/konformitaetserklaerung/musicman_bt_dongle
®
BT Dongle
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT Dongle and is the answer not in the manual?

Questions and answers

Summary of Contents for MusicMan BT Dongle

  • Page 1: User Manual

    ® MusicMan BT Dongle User Manual Please find the Declaration of Conformity for this device under following internet-link: www.technaxx.de/konformitaetserklaerung/musicman_bt_dongle Read the instructions carefully before using the device. Charge the battery about 3–5 hours before using the device the first time.

  • Page 2: System Requirement

    Function Table STATUS RED light Charging Flashing RED light Low batterie Steady BLUE light Playing or pairing done Steady PURPLE light BT music is connecting status for charging Rapid flashes of BLUE light Searching previous pairing Slow flahes of BLUE light Searching new pairing / Incoming phone call First flashing PURPLE then BLUE light of flicker Power ON RED and BLUE light of flicker interlace...
  • Page 3 More Features Functions Support any Bluetooth transceiver mobile device, e.g. iPhone, iPod, iPad series, Android, Windows Phone High Speed Transmission High Quality Music Convenient Easy to carry Easy to use Let you easily switch between calls and music in the car. Because of built-in battery you can listen to music everywhere.

  • Page 4: Technical Specifications

    Technical Specifications Bluetooth Bluetooth V3.0 with EDR Bluetooth profile HSP (Headset Profile) HFP (Hands-Free Profile) A2DP (Advanced Audio Distribution Profile) AVRCP (Audio / Video Remote Control Profile) Effective range Class 2 Battery Re-chargable with 240mAh capacity Working / Charging / Standby time ~10 hours / ~3 hours / ~7 hours Weight / Dimensions of device 26g / 52 x 52 x 13mm...
  • Page 5 Follow the onscreen instructions. Click on “Pair” and the device will be connected. If LED shows a steady BLUE light after a few seconds, device pairing is done. Go to the Bluetooth manager of your Android phone and turn on “Bluetooth”.Follow as shown below.
  • Page 6 Note: 1) “Bluetooth Music” in the text = Device itself 2) Android phone just show “Connected to phone audio” or “Connected to media audio” on screen, then the device just have one function. 3) Android phone only shows “Connected to media audio” on screen, the device do not have phone audio function.
