Tips & notes
• In DOS and Window's safe mode, the USB interface will not work (or it is limited to enabling
the continued use of a USB mouse/keyboard). The USB SoundBox cannot be used in this
case.
• If necessary, select the correct sound card from the Windows Control Panel (internal sound
card or onboard sound or the USB SoundBox).
After connecting the USB SoundBox to the computer, it is normally activated automatically
and ready for use. The power LED lights up.
• The desired input (e.g. Line-In, Mic-In, S/PDIF-In) must be selected in the Control
Panel before it is possible to record.
For example, if you want to record using a microphone (or use a microphone for a voice
function in multi-player games), the microphone input must be selected in the Control Panel.
• With the sound recorder integrated in Windows, you can test the sound recording, adjust the
microphone recording level or check if the system settings are correct.
If the microphone is too quiet, the microphone amplifier can be activated in the
Windows Control Panel.
• On the enclosed CD, you will find a comprehensive manual in English. To view the PDF
file, you need "Acrobat Reader", for example, which you can download free of charge at
www.adobe.com
• To play back via all of the loudspeakers, the appropriate software (e.g. DVD player software)
and appropriate sources (e.g. films) are of course required.

Care and cleaning

• Disconnect the product from the power supply before cleaning.
• Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as
they can cause damage to the housing and malfunctioning.
• Clean the product with a dry, fiber-free cloth.
• Do not immerse the product in water.
Disposal
Electronic devices are recyclable waste and must not be disposed of in the
household waste. At the end of its service life, dispose of the product according to
the relevant statutory regulations.
You thus fulfil your statutory obligations and contribute to the protection of the
environment.

Technical data

Input voltage .........................................5 V/DC
Power consumption ..............................max. 400 mA
Operating conditions .............................0 to +40 ºC, 10 – 85 % RH
Storage conditions ................................-10 to +70 ºC, 5 – 90 % RH
Dimensions (W x H x D) .......................127 x 28 x 64 mm
Weight ..................................................107 g (without accessories)
