Hobart UCX Installation And Operation Instruction Manual

Container washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

UCX
Container Washer
INSTALLATION
OPERATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UCX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hobart UCX

  • Page 1 Container Washer INSTALLATION OPERATION...

  • Page 3: Table Of Contents

    Installation and Operation Instruction for HOBART Container Washer Model UCX Content Page 1 Assembly ....................4 2 Electrical connection ................5 3 Water connection .................. 5 4 Steam or high pressure hot water connection ........6 5 Dosage of detergent and rinse agent ........... 7 6 First run ....................

  • Page 4: Assembly

    Assembly Should be carried out by a HOBART technician. Transport to installation location – If possible in its packing and on skid. – Push on rollers. – Avoid damage to floor and doors. Remove packing – Cut steel bands. – Remove carton.

  • Page 5: Electrical Connection

    Electrical connection Must be carried out by an qualified technician according to the national and local codes. Check – Open control box (with key) and take out wiring diagramme from the inside of the door. – Check machine specifications to make sure they correspond to those of the site supply and the wiring diagramme.

  • Page 6: Steam Or High Pressure Hot Water Connection

    Drain connection to be connected to site drain: – Tank drain (50 mm Ø). – DUAL rinse drain (hose 3/4") – Drip water drains of tabling, sink and other elements. – All drains must be connected to goose neck (individually or single point).

  • Page 7: Dosage Of Detergent And Rinse Agent

    Please pay attention to the manufacturers safety rules and instructions. First run Must be carried out by an authorized HOBART technician to adjust and check machine functions. Preparation – Check if detergent and rinse agent containers are filled.
  • Page 8 Fill rinse booster heater – Fill machine until water sprays out of rinse jets. – Electrically heated machine: Switch on fused isolator of rinse booster heater. Heating switches on. – Steam / high pressure hot water heated machine: Open heating valves. Check –...
  • Page 9 Adjust temperatures Must be carried out by an authorized HOBART technician. RINSE BOOSTER HEATER Actual temperature – Measure temperature at water outlet (contact thermometer). – Set switch "S1" at the rinse booster circuit board to right position. – Adjust "P1" until digital display "L2/L1" and actual temperature correspond.

  • Page 10: Controls

    Controls Get-ready button (green) switches on: – rinse booster heater – fill – tank heating Shut-off button (red) switches off all above functions Machine is off duty. Operation button (green) switches on: – conveyor – wash systems Off button (red) switches off all above functions Machine stays ready for operation.
  • Page 11 Function display °C °C Functions: Temperatures: 1 not used 8 wash 2 rinse booster heater 9 rinse 3 fill 4 tank heater 5 wash pump 6 rinse 7 not used Green lamp illuminated: temperatures correct. If green lamp goes out, temperature of the tank °C °C dropped 15°C below pre-set value: check heaters.

  • Page 12: Preparation For Use

    Preparation Put curtains in place. Check correct strainer position. Check wash arms. Close inspection doors Switch ON main circuit breaker "I". When green lamp illuminated, (drains close automatically). Push get-ready button. machine is ready for operation. Push operation button. Operation °C Slide washware into the machine.

  • Page 13: After Washing

    After washing Push shut-off button. Remove and clean strainer baskets Remove and clean wash arms. Set main switch to "0" and open and flat strainers. inspection doors. Take out curtains. Drain tanks by lifting lever at left Hose down interior of machine. tank wall.

  • Page 14: Position Of Curtains

    Position of curtains 231 540-2 231 540-3 231 540-1 231 540-1 231 540-1 231 602-1 231 602-2 230 781 231 602-2 230 781 Mod.154120 Mod.154119 lg = 210 lg = 290 lg = 250 lg = 210 lg = 420 Frost prevention Must be carried out by a qualified technician.

  • Page 15: Trouble Shooting Guide

    POSSIBLE CAUSE REMEDY tank fill too slow line strainer of fill clogged clean line strainer solenoid valve defective call the HOBART after sales service tank not filled to correct drain leaking check drain gasket level temperatures too low heaters defective...
  • Page 16 As continued product improvement is a policy of HOBART, specifications are subject to change without notice. Printed in Germany AG-20999-A-10-00-PC...
