- Page 1 LED HD COLOUR MONITOR WBXML32RS...
-
Page 2: Table Of Contents
Contents Contents ......................1 Safety ........................ 1 Cautions ......................2 FCC RF Interference Statement .................. 3 Features ......................4 Controls & Menu Operation ..................5 Mounting Guide ..................... 8 Accessories ......................9 Power Indicator / Modes of Operation ................9 Care ........................ -
Page 3: Cautions
9. Please cut off power or remove the connecting line immediately if there is smoking, off-odor or abnormal noise. Contact the after-sales service center after affirming there is no more smoking or off-flavor. Without proper maintenance, fire can occur. 10. Only qualified servicemen can maintain. If the product gets any kind of damage, such as damage to the plug, splash or foreign matter into the facility, exposed to rain or humidity, not able to function or dropped, please fix it immediately. -
Page 4: Fcc Rf Interference Statement
connecting line emphatically might cause damage to it. 9. Cut off power and the connecting line immediately and contact the after-sales service center if the product or the connecting line is damaged for some reason. Continuing using without maintaining might cause smoking or off-odor. 10. -
Page 5: Features
CE Compliance This monitor complies with the basic protection requirements of the Electromagnetic Compatibility (EMC) Directive 2004/108/EC for electrical and electronic equipment imported into the European Union (EU): The electromagnetic disturbance generated by the apparatus does not exceed the level specified in the harmonized EMC Standards for this type of apparatus. It has a level of immunity to the electromagnetic disturbance to be expected in its intended use, and should operate without unacceptable degradation of its specified performance. -
Page 6: Controls & Menu Operation
Please connect the monitor to external devices according to the following I/O interface list, and choose the corresponding incoming signal channel. WBXML32RS Main Menu Press the menu buttons on the bottom right side of the screen which allows the main menu to be displayed on the screen. - Page 7 B. “DOWN” button Press the button to scroll the cursor to desired function. Press the button to decrease the value of selected function in sub OSD menu. C. “UP” button Press the button to scrolling the cursor to desired function. ...
- Page 8 Option Menu Option menu can adjust OSD language set, restore the unit to factory defaults, trigger a software update when a USB is present with new firmware, adjust OSD transparency, OSD duration, and enable / disable auto sleep. Press ▲▼ button to adjust value when item is selected, press menu button to exit.
-
Page 9: Mounting Guide
In order to prevent losing these screws, we suggest replacing the screws in their original holes. 2. Attach the VESA mount, WBXML32RS(200mm x 100mm), plate to the rear of the monitor and follow all of the instructions provided with the mount to complete the mounting process. -
Page 10: Accessories
Accessories Power Indicator / Modes of Operation LED Indicator LED is off when power is off; LED glows green when power is on. The power management feature of the monitor is designed for security surveillance applications. When there is no video, the monitor remains ON to be instantly ready to display video when the source is changed or if a PC changes state from sleep/standby to active mode. -
Page 11: Dimensions
Dimensions Model WBXML32RS Letter Dimension inch Width of monitor body 743.95 29.30 Height of monit or body 443.40 17.45 Depth of monitor body 58.70 2.31 Height of monitor on base 523.70 20.62 Width of base 349.36 13.75 Depth of base 199.29... - Page 12 Specifications Model WBXML32RS Screen diagonal dimension (inches) Viewable area W x H (inches) 27.50*15.47 Led Type Pixel Pitch (mm) 0.36 Screen Maximum Resolution 1920x1080 720x400; 640x480; 800x600; 1024x768; 1280x1024; 1920x1080;1360x768; Supported Panel Display Resolutions 1440x900; 1600x900; 1680x1050; 1920x1080; 720x400; 640x480; 800x600; 1024x768; 1280x1024; 1920x1080;1360x768;...
-
Page 13: Limited Warranty
Subject to the terms and conditions of this Limited Warranty, from the date of sale through the period of time for product categories specified in Section 1(b), ADI warrants its W Box Technologies products to be free from defects in materials and workmanship under normal use and service, normal wear and tear excepted. - Page 14 ADI only warrants those products branded as W Box Technologies products and sold by ADI. Any other products branded by third parties are warranted by the third party manufacturer for a...
- Page 15 DVR's, NVR's 60 Months IP Cameras 60 Months Racks 60 months TV Mounts 60 months PIR’s 60 months Analog Cables Limited Lifetime B Connectors Limited Lifetime Bus Terminals Limited Lifetime Extension Cords Limited Lifetime HDMI Cables Limited Lifetime Jacks, Cords and Intrusion Communication Accessories Limited Lifetime Patch Cables Limited Lifetime...
- Page 16 ADI reserves the right to issue a credit only in lieu of replacement. If any W Box Technologies product is found to be in good working order or such product’s inability to function properly is a result of user damage or abuse, the product will be returned to Buyer in the same condition as received and Buyer shall be responsible for any return freight changes.
- Page 17 5. Governing Law This Limited Warranty shall be governed by the law of England and Wales. 6. Miscellaneous Where any term of this Limited Warranty is prohibited by such laws, it shall be null and void, but the remainder of the Limited Warranty shall remain in full force and effect.
