RLH Industries T1 Mux User Manual

USER GUIDE
2 Channel T1 Mux
DIN Fiber Link System
SYSTEM INSTALLATION INFORMATION
Description
The T1 Multiplexer (or Fiber Mux System) transports up to two T1
lines over two strands of fiber. It has B8ZS and AMI compatibility,
with LED status indicators for system monitoring, alarm and dual
power inputs.
It provides cost effective, high density regenerated T1 over fiber
in a compact DIN form factor. This hardened, rugged system is
covered by our Limited Lifetime Warranty.
Key Features
• Applications for critical, high voltage, remote or un-manned
locations that must remain operating 24/7/365.
• Simplex 60mA line powered on the drop side from the T-1 span
or HDSL NIU/RT unit, eliminating costly external power
arrangements.
• Compatible with 2 Channel T1 Fiber Link Card.
• May be powered externally with 24~56VDC 100mA local power
on dual redundant power connectors.
• Environmentally hardened to operate in -40°F to +158°F
(-40°C to +70°C) environments.
• Accommodates up to two incoming T-1 4 wire copper lines over
one fiber pair.
• Ideal for T-1 applications where available fiber strands, enclosures
or mounting space are limited.
• The same module may be used at either end of the fiber system,
simplifying spares and ordering.
• Operates from any HDSL-1, HDSL-2 or HDSL-4 NIU/RT signal.
• RJ48C T1 connections.
• Loop back features with independent channel testing.
• Provides simultaneous multiplexing and de-multiplexing of two
asynchronous T-1 channels.
• Frame integrity LED and remote T1 channel fault LEDs.
• Compact modules are DIN rail or wall mountable.
• Can be used within or beyond customer premise
environment.
• Covered by our Limited Lifetime Warranty
RLH Industries, Inc.
RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com
The leader in
rugged fiber optic
technology.
2 Channel T1 Mux DIN Mount Module
Contents
Description & Key Features
General Safety Practices _________________
Application _____________________________
Installation _____________________________
Connections ___________________________
Powering the System ____________________
Switch Settings _________________________
LED Indicators __________________________
NIU Compatibility ______________________
Specifications _________________________
Ordering Information ___________________
Technical Support _____________________
Compliance Information
The RLH 2 Channel T-1 Mux DIN Fiber Link System is
compliant with the following industry standards:
• FCC PART-15
• FCC PART-68B
• IEEE-487
• IEEE-1590
• Motorola R56
• BR 876-310-100 BT (Telcordia)
• Bellcore SR-3966
• GR-1089
• GR-63
U-023 2019A-1017
_______________ 1
2
3
5
6
6
7
8
10
11
12
12
Page 1
