Semtronics SmartLog X3 62580 Manual

Wrist strap and footwear tester automated esd record keeping
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3
62580
SmartLogX
™
Wrist Strap and Footwear Tester
Automated ESD Record Keeping
Personal Grounding Verifier with Data Transmission
Hardware & Software Setup Instructions
Corporate Office:
For sales and Service in
For sales and service in Europe and Asia
3651 Walnut Avenue,
North America contact:
contact:
ESD Systems.com
Chino, CA 91710
OK International - European Headquarters
www.esdsystems.com
Phone: (909) 627-8178
Eagle Close, Chandlers Ford,
sales@esdsystems.com
Fax (909) 627-7449
Hampshire, SO53 4NF U.K. England
Phone: 508-485-7390
http://www.okintl.com/locations
Fax: 508-480-0257
Tel: +44 (0)23 8048 9100
Fax: +44 (0)23 8048 9109
TB-6123
Page 1 of 12
Revision 10/06

Advertisement

Table of Contents
loading

Summary of Contents for Semtronics SmartLog X3 62580

  • Page 1 62580 SmartLogX ™ Wrist Strap and Footwear Tester Automated ESD Record Keeping Personal Grounding Verifier with Data Transmission Hardware & Software Setup Instructions Corporate Office: For sales and Service in For sales and service in Europe and Asia 3651 Walnut Avenue, North America contact: contact: ESD Systems.com...
  • Page 2 Carefully unpack the Semtronics 62580 SmartLogX ™ wrist strap and footwear tester. 62580 SmartLogX ™ comes factory default and ready to install without any changes to clock’s configuration. If a second SmartlogX ™ is being added or is going to be “Daisy-Chained”, refer to next set of instructions for configuring clocks on a daisy-chain.
  • Page 3 1. Configuration of Clocks Setting, Mounting and Cable Connection Figure 1. Back Side of SmartlogX ™ A. Clocks Baud Rate, ID, Parity, Daylight Option and Port expand Referring to Figure 1. 1. Plug the 120 volt AC power supply into the unit and then to the appropriate AC source. Refer to Figure 1.
  • Page 4 7. Port expand should be set to yes (factory default). 8. Press Enter button once more to cycle to next setting before hitting Menu button to exit. Note: Setting will not change if you don’t cycle to the next setting (by hitting the Enter button).
  • Page 5 Figure 2. Data Cable Connections and Clock Settings SmartlogX ™ Hardware A. 10 Digit Key pad can be use to manually punch in ID badge number if no card is present. Press CLEAR, enter ID number and press ENTER to start test. B.

  • Page 6: Limited Warranty

    Semtronics factory. Warranty replacements will take approximately two weeks. If your unit is out of warranty, Semtronics will quote repair charges necessary to bring your unit up to factory standards. Call Customer Service at 909-627-8178 for proper shipping instructions and address.
  • Page 7 DUAL INDEPENDENT FOOTWEAR AND WRIST STRAP TESTER Installation and Operating Instructions The Semtronics Dual Independent Footwear and Wrist Strap Tester is designed to test personal grounding devices, wrist strap and ESD footwear, to satisfy the requirements and the recommendations of the ESD Association.

  • Page 8: Default Setting

    the ESD protected area, testing for functionality before reentry to the ESD protected area should be considered.” The test resistance limits for footwear and wrist strap tests are controlled by the DIP switches inside the tester. For a configuration different than the default settings, remove the unit from the sign, remove the back of the case, and reset the DIP switches inside the unit as desired.
  • Page 9 Installation Insert one stereo plug of the 62103 Stereo Plug to Stereo Plug into the stereo jack on the bottom of the tester. (See Figure 1.) Insert the other end of the stereo plug into the stereo jack at the back of the foot plate.

  • Page 10: Testing Procedure

    If any of the test results are failed “HIGH” or “LOW” an audible alarm will sound. The LED(s) indicating the failed test will be displayed for approximately three (3) seconds, and the internal relay will not activate. CALIBRATION AND PERIODIC TESTING: The accuracy is specified as: 1.
  • Page 11 5. Select the “10M safe” or “35M safe” setting, whichever one is appropriate, on the 62080/62100/62102 and repeat the test. The results of the test should be “pass” for the wrist strap. 6. Select the “10M high” or “35M high” setting, whichever one is appropriate, on the 62080/62100/62102 and repeat the test.
  • Page 12 TECHNICAL SUPPORT: Europe Semtronics Charleswater 3651 Walnut Avenue Unit 17, Millbrook Business Park, Sybron Way Chino, CA 91710 Crowborough, East Sussex, TN6 3JZ, U.K. Tel: (909) 627-8178 Tel: 01892 665313 Fax: (909) 627-7449 Fax: 01892 668838 LIMITED WARRANTY Semtronics Semtronics...
