Summary of Contents for Matrix SETU VG Series
- Page 1 SETU VG Quick Start...
- Page 3 SETU VG Multi-Port VoIP to GSM Gateway Quick Start...
- Page 4 Documentation Disclaimer Matrix Comsec reserves the right to change, at any time, without prior notice, the product design, specifications, components, as engineering and manufacturing may warrant. This is a general documentation for all models/configurations of the product. The product may not support some of the features/facilities described in this document.
-
Page 5: Table Of Contents
Contents Know Your SETU VG ..................1 Overview ......................1 Installing SETU VG ..................3 Before You Start ....................3 Getting Started ....................3 Connecting SETU VG ..................5 Power ON SETU VG ..................8 Accessing Jeeves (GUI) ................11 Connecting a Computer .................. - Page 6 Table of Contents...
-
Page 7: Know Your Setu Vg
Know Your SETU VG Thank you for choosing the Matrix SETU VG. Please read the instructions in this Quick Start to install and operate SETU VG. This Quick Start is meant to help you install and configure the basic parameters of the system. For Advanced configuration and feature description, please refer the SETU VG System Manual available Online. - Page 8 Maintenance in the System Manual. SETU VG is easy to install and operate. The built-in web server, Jeeves, allows you to configure the system parameters and features On-site as well as from a remote location. Matrix SETU VG Quick Start...
-
Page 9: Installing Setu Vg
SETU VG contains a 3VDC/18mAh (Li-Al) alloy-Manganese Dioxide Coin Battery (ML 1220 - Rechargeable) of diameter 12.5mm and height 2.0mm. Battery should be replaced only by authorized dealers of Matrix. There is a risk of explosion if the Battery is replaced in an incorrect manner. Please dispose-off used Batteries. - Page 10 If you are mounting the system on a wall, refer to the mechanical dimensions of the product and use the mounting template for drilling holes on the wall. The Package of SETU VG4 contains only one GSM Antenna with SMA Connector. Matrix SETU VG Quick Start...
-
Page 11: Connecting Setu Vg
Antenna cable through the duct, as it will degrade the signal strength. Connecting to the IP Network • Connect the WAN Port of SETU VG to the IP Network—a DSL modem/router or a LAN Switch—using the Ethernet cable supplied for the port. Matrix SETU VG Quick Start... - Page 12 If connecting to a Private Network (Behind a NAT Router), • Plug one end of the Ethernet cable into the WAN Port of SETU VG and the other end into the LAN Switch/Hub. The default IP Address of the WAN Port is: 192.168.1.100 Matrix SETU VG Quick Start...
- Page 13 3G module installed in the system and Internet services activated on the SIM. • At every power on, it takes about 3 minutes for the Mobile Ports to get registered with the network. Once registration with the mobile network is completed, the Mobile Port can be used. Matrix SETU VG Quick Start...
-
Page 14: Power On Setu Vg
Few Initialisation (i.e WebJvs, Green CallManager, PortCnfg etc.) VOPP Program Download Green Success 1000 Green 1000 All Init Done, 1000 System goes Live 1000 Green 1000 (Continuous Green blinking as given in last 2 steps) Matrix SETU VG Quick Start... - Page 15 500msOn-1500ms Off (3 Blinks) 500ms On - 500ms Off - SIM PIN Wrong 500ms On - 2500ms Off (2 Blinks) 500ms On - 3500ms Off (1 Blink) SIM Absent 1sec On - 1sec Off GSM network absent Matrix SETU VG Quick Start...
- Page 16 SIP Registration Failed 200ms On - 200ms Off - 200ms On - 3400 Off SIP Authentication Failed (2 Blinks) When the Reset Cycle is completed, you may configure the system using the embedded web server, Jeeves. Matrix SETU VG Quick Start...
-
Page 17: Accessing Jeeves (Gui)
• Make sure the IP Address of the computer and the LAN Port of SETU VG do not conflict, and that both are in the same Subnet. The default IP Address of the LAN Port of SETU VG is: 192.168.2.100 The default Subnet Mask of the LAN Port of SETU VG is: 255.255.255.000 Matrix SETU VG Quick Start... - Page 18 • In the address bar of the browser, enter the default IP address of the LAN Port: 192.168.2.100 • The Login page will open. • In Login Password, enter 1234, the default Password. • Click the Login button. On successful login, the Home page of Jeeves opens. Matrix SETU VG Quick Start...
- Page 19 Maintenance allows you to carry out system maintenance and monitoring activities like uploading/upgrading firmware and configuration, system debug, system restart. Status allows you to view the system details and the status of all the ports. You may now configure the Basic Settings of SETU VG. Matrix SETU VG Quick Start...
- Page 20 Matrix SETU VG Quick Start...
-
Page 21: Configuring Setu Vg
• The Collapse button , collapses a link, hides all the parameters under a link on the page. • The Settings icon , enables you to configure / edit the settings of a parameter further. Matrix SETU VG Quick Start... -
Page 22: Using Selective Configuration
Expand: expands a link to display all parameters under the link. Collapse: collapses a link; hides all parameters under the link. Settings: enables you to configure / edit the settings of a parameter further. Matrix SETU VG Quick Start... - Page 23 • Set the parameters on the page to the desired values and click the Submit button to save. You may use the Wizard or selectively configure the Basic Settings pages, whichever works best for you. Read the SETU VG System Manual for detailed instructions. Matrix SETU VG Quick Start...
- Page 24 MATRIX COMSEC Head Office 394-GIDC, Makarpura, Vadodara - 390010, India. M: +91 85111 73344 E-mail: Customer.Care@MatrixComSec.com www.MatrixTeleSol.com...
