Johnson Safety Myron & Davis DVR300 Manual

Night vision hd 1080p
Hide thumbs
Table of Contents

Advertisement

Quick Links

Dash Cam DVR
DVR300
Night Vision HD1080P
Thanks for purchasing this DVR from our company, Please
read this manual carefully and save it for future reference, as
it contains information about the wonderful features as well as
some tips to operate this device easily.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Myron & Davis DVR300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Johnson Safety Myron & Davis DVR300

  • Page 1 Dash Cam DVR DVR300 Night Vision HD1080P Thanks for purchasing this DVR from our company, Please read this manual carefully and save it for future reference, as it contains information about the wonderful features as well as some tips to operate this device easily.

  • Page 2: Product Structure

    Product Structure Front view Back view Right view ③ ① ② Top view Left view ⑦ ⑧ ⑨ ⑩ ① MIC ⑧ Down ② Lens ⑨ UP ③ Speaker ⑩ Menu ④ Power AV port ⑤ TF card slot HDMI Port Preset ⑥...

  • Page 3: Pre-Installation

    Pre-Installation 1. Clean windshield thoroughly before installing the DVR with the suction cup mount. 2. Review your local and state laws regarding car DVR recorders objects that may block the driver’s view. Do not break any laws or obstruct the driver’s view when you install your DVR. 3.
  • Page 4 SD Card Formatting Instructions 1. Format : Press twice to enter into setting and press Down button to a appropriate mode (format), press REC button to confirm.

  • Page 5: Basic Operation

    Basic Operation 1. Please insert the TF card, DVR supports the memory size from 1G to 32G. 2. Connect the car charger with the DVR, then connect the DVR with car cigarette socket. 3. Recording (1) Manual Recording: Press ON/OFF button for one second, the DVR will switch on, and you will hear one "beep"...
  • Page 6 4. Photo Taking In standby mode, press the MODE button to click the video and photograph switching, enable the photo taking function, press REC button,the screen turns off for a while, then turns on again,It means that photo taking is successfully. The DVR supports 4x digital zooms by pressing the UP/DOWN button to adjust the focus.
  • Page 7 7.PC Webcam Use the USB cable to connect PC and it will pop up “MSDC / PCCAM / POWER”, choose PCCAM. Open “my computer” and it will display the icon double click the icon and it can be used as PC camera. 8.Files Storage and playback from PC When you finish recording, connect the USB data cable to computer, and you can copy or cut the files to computer for...
  • Page 8 Menu Setting under recording mode Press ON/OFF button, the DVR has the feature of recording automatically upon power going on，so press the REC to stop recording, then press Menu button to enter into setting, Press UP/DOWN button to select the menu which you need to adjust, press REC to confirm, press MENU button one more time to exit.
  • Page 9 4. Motion Detect: Movement recording, press MENU to enter into setting, and press UP/DOWN button to select the appropriate mode (Default:Off) Press REC button to confirm. 5. Record Audio: The video with sound or without, press MENU button to enter into setting, and press UP / DOWN button to select the appropriate mode (Default: off) Press REC button to confirm.
  • Page 10 1. Capture Mode: Press MENU button to enter into setting, then press UP/DOWN button to select the appropriate mode (Default:Single), press REC button to confirm. 2. Resolution: Pixel selection, press MENU/SNAP button to enter into setting, then press UP/DOWN button to select the appropriate mode (Default:3M), press REC button to confirm.

  • Page 11: System Setting

    8. ISO: Press MENU button to enter into setting, then press UP/DOWN button to select the appropriate mode (Default: Auto), Press REC button to confirm. 9. Exposure: Adjust the brightness of photos, press the MENU button to enter into setting, then press UP/DOWN button to select the appropriate mode (Default: +0.0).
  • Page 12 1. Date/Time: Press MENU to enter into setting, and press UP/DOWN button to select, if you need to modify the time, press the REC to enter at this time, you can press UP/ DOWN to adjust the time, if you need to change the date display format, press DOWN button for selection, press REC button to confirm.
  • Page 13 7. Frequency: Press MENU button to enter into setting, then press UP/DOWN button to select the appropriate mode (Default:50Hz), press REC button to confirm. 8. Lamp setting: Press MENU button to enter into setting, then press UP/DOWN button to select the appropriate mode (Default:off), press REC button to confirm 9.
