Summary of Contents for MSEL Master Relay
- Page 2 The master relay is connected between the positive terminal of the battery Pin 4 of the master relay connector provides a logical output for a PDM / and the rest of the vehicles positive power supply. See the diagram on the ECU allowing engine kill functionality with alternator load dump protection.
