MAN – FDIPD-MD Ver 2
Manufactured by MILIC, LLC with marketing support from Flight Display Systems.
This product does not have FAA PMA approval.
TECHNICAL SUPPORT
678-867-6717, or
www.FlightDisplay.com
All manuals and user guides at all-guides.com
Rev:
B
FDIPD-MD VERSION 2
Installation and Operation Manual
Revision Date:
08/08/2012
Page 1 of 12
iPod Docking Station

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FDIP-MD VERSION 2 and is the answer not in the manual?

Questions and answers

Related Manuals for Flight Display Systems FDIP-MD VERSION 2

Summary of Contents for Flight Display Systems FDIP-MD VERSION 2

  • Page 1 MAN – FDIPD-MD Ver 2 Page 1 of 12 FDIPD-MD VERSION 2 Installation and Operation Manual iPod Docking Station Manufactured by MILIC, LLC with marketing support from Flight Display Systems. This product does not have FAA PMA approval. TECHNICAL SUPPORT 678-867-6717, or www.FlightDisplay.com...
  • Page 2 Revision Date: 08/08/2012 MAN – FDIPD-MD Ver 2 Page 2 of 12 FDIPD-MD VERSION 2 iPod Docking Station © 2010 Flight Display Systems. All Rights Reserved. Flight Display Systems 1765 Grassland Parkway Alpharetta, GA 30004 678-867-6717 Phone 678-867-6742 Fax sales@flightdisplay.com www.flightdisplay.com...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/08/2012 MAN – FDIPD-MD Ver 2 Page 3 of 12 Table of Contents General Information ........................4 1. Front View ..........................4 2. Additional Information ....................4 Specifications ..........................5 Operating Instructions ........................5 Safety Bar ............................6 Installation Instructions ......................6 1.

  • Page 4: General Information

    (as shown on Drawing MSD-130 at the end of this manual) is preferred, please contact your local Flight Display Systems sales representative. If multiple FDIPD-MD Version 2 units are utilized, the user will have multiple iPod Audio/Video sources to choose from.

  • Page 5: Specifications

    The FDIPD-MD Version 2 is operated using the original control interface for the iPod or iPhone product. Video or audio output can be selected using any of the Flight Display Systems cabin control modules. These include the FDCCM1, FDCCM2, FDCCM3, FDCCM43, FDCCM7, and FDCCM10 (and all separate versions of these products).

  • Page 6: Installation Instructions

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/08/2012 MAN – FDIPD-MD Ver 2 Page 6 of 12 The FDIPD-MD Version 2 comes equipped with an optional use safety bar. This can be used to secure the iPod during flight turbulence or when the FDIPD-MD Version 2 has been mounted vertically.
  • Page 7 All manuals and user guides at all-guides.com Rev: Revision Date: 08/08/2012 MAN – FDIPD-MD Ver 2 Page 7 of 12 Connector, HD-15 Female M24308/2-286 or Equivalent Female Pins M39029/57-354 or Equivalent FDIPD-MD Ver 2 Number Description 28V DC Power Power Return Ground Video Audio R Audio L...

  • Page 8: Ship Kits

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/08/2012 MAN – FDIPD-MD Ver 2 Page 8 of 12 Ship Kit Items Product FDIPD-MD Version 2 Shipping Materials  (1) BAR, SAFETY  (1) SHIPKIT-DB15F  (1) FERRITE INSTALL ...

  • Page 9: Pre-Amp Selection

    Adjust these settings until optimal volume settings are achieved. Technical Support Should you have any questions concerning this product or other Flight Display Systems products, please contact our Product Support representatives at (678) 867-6717. Flight Display Systems...

  • Page 10: Warranty Information

    If the return of the unit to the factory is required, an RMA number will be issued at that time. Flight Display Systems will, upon receipt of the failed hardware, remanufacture or replace the unit at our discretion.

  • Page 11: Installation Drawing

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/08/2012 MAN – FDIPD-MD Ver 2 Page 11 of 12 Installation Drawing...

  • Page 12: Log Of Revisions

    All manuals and user guides at all-guides.com Rev: Revision Date: 08/08/2012 MAN – FDIPD-MD Ver 2 Page 12 of 12 Log of Revisions Date Page Description 11/19/2010 Initial Release 08/08/2012 Update format, warranty and non-PMA info...
