OPERATIONAL ADVICE
WARNING:
TO PREVENT SERIOUS INJURY, PLEASE
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
SAVE THIS MANUAL
Keep this manual in a safe place for future reference. This manual contains
useful information relating to the safe use and operation of a High Lift Jack.
WORKING LOAD LIMIT:
1500KG
PLU: 299575
Advertisement
Summary of Contents for RIDGE RYDER 299575
- Page 1 AND INSTRUCTIONS BEFORE USE. SAVE THIS MANUAL Keep this manual in a safe place for future reference. This manual contains useful information relating to the safe use and operation of a High Lift Jack. WORKING LOAD LIMIT: 1500KG PLU: 299575...
-
Page 2: Operating Precautions
INTRODUCTION: Ridge Ryder High Lift jack is one of the most practical recov- fill the holes or position articles such as rocks, wood or sand ery accessories you can have. It can be used in a number of tracks to assist in creating traction for the wheels. - Page 3 OPERATING INSTRUCTIONS When using this High Lift Jack, safety precautions should always be followed to reduce the risk of personal injury and damage to the Jack. Every situation is di erent; this information provided is to be used as a guide only. This guide does not cover each individual situation you must use your common sense and good judgement.
- Page 4 POSITION THE JACK: STABILISE THE LOAD: Make sure the control lever is in the up position. Unlock the Do NOT use the jack to support the load, use accessories such handle from the upright position. Hold the handle firmly and as vehicle support stands that are rated greater than the load pull the lifting mechanism up and position it completely and being lifted to support the load.
- Page 5 FINISHED WINCHING OPERATION: BEGIN THE WINCHING OPERATION: Secure the load. Before you move the control lever to the Secure the load behind the direction of the pull. Make sure down position lock the handle into position parallel to the lifting the control lever is in the upright position.
-
Page 6: Maintenance Instructions
MAINTENANCE INSTRUCTIONS LUBRICATING: IMPORTANT: Once the jack has been cleaned and allowed to dry you must NEVER PREFORM ANY MAINTENANCE WHILE THE JACK IS IN now lubricate it with a Penetrating oil or silicone spray. Grease OPERATION UNDER LOAD. and motor oil are not appropriate for lubricating the jack. The High Lift Jack is not self lubricating. - Page 7 JACK COMPONENTS IDENTIFICATIONS & BREAKDOWN Top Clamp Bolt, Washer & Nut Top Clamp Lifting Bar Handle Safety Labels Reversing Switch Control Lever Reversing Switch Handle Spring (Behind Socket Bolt Reversing Latch) Pitman Shear Pin Climbing Pin Spring (2 Required) Cross Pin (2 required) Climbing Pin Pitman...
