GigE Vision
VGA Monochrome CCD Camera
FV-G030B1
User's Guide
RICOH COMPANY, LTD.
FV-G030B1
User's Guide Rev. 1.02
All manuals and user guides at all-guides.com
1/38

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FV-G030B1 and is the answer not in the manual?

Questions and answers

Related Manuals for Ricoh FV-G030B1

Summary of Contents for Ricoh FV-G030B1

  • Page 1 All manuals and user guides at all-guides.com GigE Vision VGA Monochrome CCD Camera FV-G030B1 User’s Guide RICOH COMPANY, LTD. FV-G030B1 1/38 User’s Guide Rev. 1.02...

  • Page 2: Table Of Contents

    4.4.2 Camera Command List (Device Code: 100000) ....................23 4.4.3 Descriptions of the Camera Control Commands (Device code: 000000); ............25 4.4.4 Descriptions of the Camera Commands (Device code: 100000);..............31 GenICam Command / Camera Command Reference Table ................35 FV-G030B1 2/38 User’s Guide Rev. 1.02...

  • Page 3: Connector Specifications

    Please use a 1Gb supported NIC, HUB and LAN cable. Check that the NIC and HUB being used is “1Gb transferring”. Damaging or mishandling the CAT5e cable may cause the transferring speed to change from 1Gb to 100Mb. If this happens, please replace the CAT5e cable. FV-G030B1 3/38 User’s Guide Rev. 1.02...

  • Page 4: Dc Iris Lens Connector

    For I/O-1 (Pin No. 2) For I/O-2 (Pin No.3) FrameTriggerWait (initial setting) (initial setting for I/O-1) Set Value Set Value UserOutput ExposureActive (initial setting) (initial setting for I/O-2) TriggerAuxiliary TriggerInternal SensorReadOut StrobeSignal 7H-FH 7H-FH For Test Use Only FV-G030B1 4/38 User’s Guide Rev. 1.02...
  • Page 5 The TriggerInternal signal is the input trigger signal with the trigger delay time. 6) SensorReadOut The SensorReadOut signal is the FVAL signal, which is the image output period of the time. 7) StrobeSignal The StrobeSignal signal is the strobe control signal. FV-G030B1 5/38 User’s Guide Rev. 1.02...

  • Page 6: Equivalent Circuit For The Input Pin Of The I/O Connector

    +10.8 to +26.4V Trigger_In+ Trigger_In- +3.3V +3 to +26.4V IO_Out 3 to 5mA IO_Out 2.2K 2.2K Trigger Signal Customer GND TOSHIBA TLP181 TOSHIBA TLP181 +3.3V TOSHIBA TOSHIBA RN1105MFV RN1105MFV +3.3V TOSHIBA TOSHIBA RN1105MFV RN1105MFV FV-G030B1 6/38 User’s Guide Rev. 1.02...

  • Page 7: Camera Output Timing Charts

    648 CLK 132 CLK Horizontal blanking Video output Vertical Timing Full Scanning 2.2.1 1 H = 21.1852 µseconds, 89.91172 Hz 525H One vertical (1V) FVAL 494H Video out 494H Vertical blanking Video output LVAL FV-G030B1 7/38 User’s Guide Rev. 1.02...

  • Page 8: 1/2 Partial Scanning

    Video out 243H Vertical blanking Video output LVAL DVAL 1/4 Partial Scanning 2.2.3 1 H = 21.1852 μs, 360.33325 Hz One vertical (1V) FVAL 104H Video out 104H Video output Vertical blanking LVAL DVAL FV-G030B1 8/38 User’s Guide Rev. 1.02...

  • Page 9: Aoi (Area Of Interest)

    Blanking (Back) Number of the effective lines [Y] [BLK_F] [BLK_B) Total number of the line at 1 frame [TOTAL_LINE] Optical black Dummy bit Blanking (Front) Effective CCD effective lines lines Blanking (Back) Optical black FV-G030B1 9/38 User’s Guide Rev. 1.02...

  • Page 10: Pixel Transferring Image

    All manuals and user guides at all-guides.com Pixel Transferring Image Pixel1 of Pixel2 of Data Data Pixel (n) of Data: nth pixel being transferred FV-G030B1 10/38 User’s Guide Rev. 1.02...

  • Page 11: Camera Operational Modes

    Note 1: The video output is going to be V reset by the next internal HD signal immediately after the exposure is finished. The exposure time is set by the pulse width of the trigger signal. Note 2: The FVAL signal does not output when the exposure by the trigger signal does not exist. FV-G030B1 11/38 User’s Guide Rev. 1.02...

  • Page 12: Exposure Timing With The Positive Polarity Trigger Signal

    Note 1: The trigger signal will be removed by the filtering if the pulse width of the input trigger signal is less than 30 CLK. Please input a trigger signal with more than 31 CLK pulse width. Note 2: The exposure will start 105 CLK after the rising edge of the trigger signal. FV-G030B1 12/38 User’s Guide Rev. 1.02...

  • Page 13: Edge Preset Trigger Mode

    Note 1: The video output will be V reset by the next internal HD signal immediately after the exposure is finished. Note 2: The exposure time is set by the preset electronic shutter speed. FV-G030B1 13/38 User’s Guide Rev. 1.02...

  • Page 14: Exposure Timing With The Positive Polarity Trigger Signal

    Note 1: The trigger signal will be removed by the filtering if the pulse width of the input trigger signal is less than 30 CLK. Please input a trigger signal with more than 31 CLK pulse width. Note 2: The exposure will start 105 CLK after the rising edge of the trigger signal. FV-G030B1 14/38 User’s Guide Rev. 1.02...

  • Page 15: Edge Preset Trigger Mode (Trigger Input While The Image Is Out)

    Note 1: The video output will be V reset by the next internal HD signal immediately after the exposure is finished. Note 2: The exposure time is set by the preset electronic shutter speed. FV-G030B1 15/38 User’s Guide Rev. 1.02...

  • Page 16: Exposure Timing With The Positive Polarity Trigger Signal

    Note 1: The trigger signal will be removed by the filtering if the pulse width of the input trigger signal is less than 30 CLK. Please input a trigger signal with more than 31 CLK pulse width. Note 2: The exposure will start 105 CLK after the rising edge of the trigger signal. FV-G030B1 16/38 User’s Guide Rev. 1.02...

  • Page 17: H Reset Mode

    The maximum delay to start exposure from the trigger input is 1H. Trigger signal (Rising edge） Next HD Internal HD Normal SUB pulse timing SUB pulse Noise Noise Noise Noise CCD exposure Video out FV-G030B1 17/38 User’s Guide Rev. 1.02...

  • Page 18: Communication Protocol

    The Receiving Data format from the camera is as follows: After sending the Write Command: Data Length Receiving Code (8bit) (8bit) “00H” (1 byte) (8bit) After sending the Read Command: Data Length Data (8bit) (8bit) (n bytes) (8bit) FV-G030B1 18/38 User’s Guide Rev. 1.02...
  • Page 19 13H: Communication frame error (only for Gamma data upload), 14H: Time out error (Two seconds), 15H: Check sum error (only for Gamma data upload), 16H: Data length error (Not matching), 17H: EEPROM write error FV-G030B1 19/38 User’s Guide Rev. 1.02...
  • Page 20 Note3: When saving the non-consecutive sequence of commands, the above steps, 1) to 4), are necessary for the same number of times. i.e.) saving the commands “10H, 13H, 19H, 1BH” or “20H, 23H, 25H”, etc. FV-G030B1 20/38 User’s Guide Rev. 1.02...

  • Page 21: Camera Control Command

    (us) (Integer) (24bit: D[7..0]) strobe signal delay time (us) (Integer) (24bit: D[15..8]) 0 to 2,000,000 strobe signal delay time (us) (Integer) (24bit: D[23..16]) strobe signal delay time (us) (Decimal) (8bit: D[7..0]) FV-G030B1 21/38 User’s Guide Rev. 1.02...
  • Page 22 (us) (Integer) (24bit: D[23..16]) strobe signal active time (us) (Decimal) (8bit: D[7..0]) 94 to EFH reserved signals of the power-/IO connector (8bit: D[7..0]) user output signal for the power-I/O connector (8bit: D[7..0]) F2 to FFH reserved FV-G030B1 22/38 User’s Guide Rev. 1.02...

  • Page 23: Camera Command List (Device Code: 100000)

    40 to 4FH reserved Y_offset for AOI (8bit: D[7..0]) 2 <= Y <= 494, Y_offset for AOI (16bit: D[15..8]) where Y = offset height for AOI (8bit: D[7..0]) + height height for AOI (16bit: D[15..8]) FV-G030B1 23/38 User’s Guide Rev. 1.02...
  • Page 24 AOI (8bit: D[7..0]) offset + width width for AOI (16bit: D[15..8]) 58 to 5FH reserved camera mode1 (8bit: D[7..0]) 61 to 91H reserved iris lens manual adjustment (8bit: D[7..0]) 93 to FFH reserved FV-G030B1 24/38 User’s Guide Rev. 1.02...

  • Page 25: Descriptions Of The Camera Control Commands (Device Code: 000000)

    01: No Function (Prohibited setting. Do not set these values) D2 to D0: No Function Always set as “000” Note 1: The trigger polarity is automatically set to positive when using the software trigger; the trigger polarity cannot be changed. FV-G030B1 25/38 User’s Guide Rev. 1.02...
  • Page 26 The image data is not output when resetting the image data. D[7..0] D7 to D1: No Function Always set as “0000000” 0: FVAL/LVAL/Image data reset Image Data Reset (FVAL, LVAL and the image data are low state data) 1: FVAL/LVAL/Image data out FV-G030B1 26/38 User’s Guide Rev. 1.02...
  • Page 27 Clamp level = (CLAMP[7..0] x 8 + 56) / 4 (for 10bit output) Clamp level = (CLAMP[7..0] x 8 + 56) / 16 (for 8 bit output) Whenever it is set greater than 31, it will automatically resets to 31. FV-G030B1 27/38 User’s Guide Rev. 1.02...
  • Page 28 Sets the No.2 pin and No.3 pin of the I/O signal polarity. IOSIGNAL_POL[7..0] D[7..0] D7 to D2: No Function Always set as “000000” No.3 pin (I/O-2) polarity 0: Non-invert 1: Invert No.2 pin (I/O-1) polarity 0: Non-invert 1: Invert FV-G030B1 28/38 User’s Guide Rev. 1.02...
  • Page 29 Always set as “0000000” D6 to D0: Write control to the EEPROM 0: Prohibited 1: Accept Note: This bit is cleared to “0” automatically by the internal processes after the execution of the command. FV-G030B1 29/38 User’s Guide Rev. 1.02...
  • Page 30 UswerOuput signal for 2pin of the power/IO connector 0: Low 1: High D2 to D0: No function Always set as “000” Note: The UserOutput signal is enabled whenever “UserOutput signal” is selected at the “Output signal selection (OUTSEL)”. FV-G030B1 30/38 User’s Guide Rev. 1.02...

  • Page 31: Descriptions Of The Camera Commands (Device Code: 100000)

    D7 to D4: Weight for ALC weight area 4 Range: 0 to 15 D3 to D0: Weight for ALC weight area 3 Range: 0 to 15 *Please set the ALC weight area with “30H to 3FH” FV-G030B1 31/38 User’s Guide Rev. 1.02...
  • Page 32 When set as 0 (Average: 100%, Peak: 0%), the ALC function with the average brightness of the photometry area. When set as 255 (Average: 0%, Peak: 100%), the ALC function with the peak brightness of the photometry area. FV-G030B1 32/38...
  • Page 33 Sets the horizontal 3 position for the ALC weight area. 3EH: [7..0] [Vertical_4 position for the ALC weight area] 3FH: [15..8] Initial data: 612, data range: 0 to 647 Sets the horizontal 4 position for the ALC weight area. FV-G030B1 33/38 User’s Guide Rev. 1.02...
  • Page 34 Sets the iris lens manual adjustment operation. D[7..0] D7 to D2: No function Always set as “000000” D1 to D0: Manual adjustment operation 00: Hold 01: Open 10: Close 11: No Function (Prohibited setting. Do not set this value) FV-G030B1 34/38 User’s Guide Rev. 1.02...

  • Page 35: Genicam Command / Camera Command Reference Table

    Output signal polarity for 2 pin of the power-I/O connector LineInverter1 000000 5DH.1 Output signal polarity for 3 pin of the power-I/O connector StrobeSignalOnTime 000000 90-93H Strobe signal active time StrobeSignalDelay 000000 54-57H The delay time for the strobe signal (us) FV-G030B1 35/38 User’s Guide Rev. 1.02...
  • Page 36 Horizontal1 position for the ALC weight area (pixel) ALCWindowH2 100000 3A-3BH Horizontal2 position for the ALC weight area (pixel) ALCWindowH3 100000 3C-3DH Horizontal3 position for the ALC weight area (pixel) ALCWindowH4 100000 3E-3FH Horizontal4 position for the ALC weight area (pixel) FV-G030B1 36/38 User’s Guide Rev. 1.02...
  • Page 37 Please use command name defined by GenICam when changing these values, as exampled in the following sample code. In the case to change the Width BOOL SetWidth( PvDevice *pDevice, PvInt64 lValue ) PvGenInteger* lGenInteger = dynamic_cast<PvGenInteger*>( pDevice->GetGenParameters()->Get( "Width" ) ); PvResult lResult = lGenInteger->SetValue(lValue); return lResult.IsOK(); FV-G030B1 37/38 User’s Guide Rev. 1.02...
  • Page 38 Deleted description about white balance GenICam command Deleted white balance description 1.02 2012/08/25 Updated Pin Assignment of Power-I/O Connector Added 1/2 and 1/4 Partial Scanning in Camera Output Timing Charts RICOH COMPANY, LTD. URL http://www.ricoh.com/fa_security/ FV-G030B1 38/38 User’s Guide Rev. 1.02...
