Hydro Crunch Heat Mat Thermostat Instructions

Heating and Cooling
Thermostat User Manual
INSTRUCTIONS:
Thermostats are widely applied to aquariums, reptile markets, incubators, green houses and
refrigerators, where constant temperature controlling is required (heating and cooling).
MAIN FEATURES:
1. LED display, friendly interface, easy to read, operates and set the parameters.
2. Can choose COOL or HEAT mode.
3. Can switch between °C and °F
MAIN FUNCTIONS AND PARAMETERS:
◆ Temperature controlling range:16~40°C
◆ Resolution: 0.1°C; Accuracy: ± 1.0°C
◆ Relay: 10A/220V
◆ Input voltage: 110Vac± 15%
◆ Ambient Requirements: Temperature: -10~60°C; Humidity: 20%~85%°C
◆ Control load:≤ 550W/110V
KEYS:
KEY ACTION
H/C single press switch between HEAT and COOL mode
single press enter into setting mode of DIFF and DELAY
SET single press save and exit
press 5 sec. switch between °C and °F mode
UP single press enter into setting mode of stop temperature
UP single press upward adjust the parameter value
DOWN single press downward adjust the parameter value
DOWN single press enter into setting mode of stop temperature
ICONS:
MEANING
ICON
Display Not display
SNOW cool working cool not working
SUN heat working heat not working
COOL cool mode non cool mode
HEAT heat mode non heat mode
DIFF /
DELAY /
◆ Temperature measuring range: -40~100°C
◆ Input: 1 NTC sensor
◆ Product consumption: ≤ 3W
RESULT
In normal work status
In normal work status
In setting status
In normal work status
In normal work status
In setting status
In setting status
In normal work status
Flash
/ In normal work status
/ In normal work status
/ In normal work status
/ In normal work status
/ DIFF adjustable In setting status
/ DELAY adjustable In setting status
STATUS
STATUS
