SAMSUNG MULTI – CLIP MANUAL

1.OPERATING WITH SAMSUNG MULTI-CLIP

Insert clip to the phone.

Cell should be switched on or swithed off (it depends on phone model). In most

cases it should be switched off.

Clip is power supplied from the phone, but there is no problem to use 9v battery

power supply (construction of the clip allows that).

After choosing adequate model press "unlock" button.

REPAIR OPTION

THIS OPTION IS AVAILABLE TO MODELS: A200/T100-T700/R200-R225/N100-

N620

ALL YOU NEED TO DO IS PRESS "REPAIR" BUTTON. THERE's NO NEED TO

CHOOSE MODEL OF THE PHONE.

1. FUNCTION OF THE BUTTONS.

Page 1 All manuals and user guides at all-guides.com SAMSUNG MULTI – CLIP MANUAL 1.OPERATING WITH SAMSUNG MULTI-CLIP Insert clip to the phone. Cell should be switched on or swithed off (it depends on phone model). In most cases it should be switched off.
Page 2 All manuals and user guides at all-guides.com 2. CHOOSING MODEL Press button “choose model” several times. Observe following situations. If no diode is shining, You choose models : Q100,Q105,Q108,Q200,Q205 Q208,Q300,Q305,Q308 If diode nr1 ( orange) is shining, You choose models: V100,V200,V205,V208 S100-S300...
Page 3 All manuals and user guides at all-guides.com If diode nr2 ( green) is shining, You choose model: A800 If diode nr3 ( yellow) is shining, You choose models: A100, A300, A400, M100 If diode nr4 ( red ) is shining, You choose models: A200 T100-T700...
Page 4 All manuals and user guides at all-guides.com If all diodes are shining, You choose model C100...
