  • Page 1 Pronto G20/G25 Instructions for installation (GB / IE) Please retain this document carefully 95901302UK Install_G20.indd 1 95901302UK Install_G20.indd 1 2-2-10 14:28 2-2-10 14:28...
  • Page 2: Table Of Contents

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Inhoudsopgave Preface 1. Introduction 2. CE declaration 3. Safety General 3.2 Regulations 3.3 Precautions / safety instructions during installation 4.
  • Page 3: Preface

    I N S T R U C T I O N F O R I N S TA L L AT I O N Preface DRU, a manufacturer of gas heating appliances, develops and produces products that comply with the highest qua- lity, performance and safety requirements.
  • Page 4: Safety

    ➠ do not make any changes to the appliance; ➠ only use the fl ue gas discharge / combustion air supply system supplied by DRU; ➠ suspend the appliance from a wall of incombustible and heat resistant material ➠...
  • Page 5: Installation

    In appendix 1 / table 4 you can see which parts you should have after removing the packaging. Contact DRU Service if you do not have all the parts after you fi nished removing the packaging. Dispose packaging in accordance with local regulations.
  • Page 6: Flue Gas Discharge / Combustion Air Supply System

    The passage to the outside can be made with a wall duct (see section 6.5.2) or with a roof duct (see section 6.5.3). If necessary, you can also use an existing discharge channel (see section 6.5.4). Caution: - Only use the concentric system supplied by DRU (Ø100 / Ø150 mm). This system was tested in combination with the appliance;...
  • Page 7 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N 6.5.2 Application with wall duct 6.5.2.1 Construction of concentric system with wall duct The concentric system with wall duct has to comply with the following conditions (see...
  • Page 8 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N !Caution - Make sure that the right insertion length is maintained; - Place the wall duct with the groove/folded seam at the top;...
  • Page 9 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Tabel 1: Relation construction concentric system / setting appliance Total number of Total number of meters vertical and/or sloping pipe length G25/G20 meters horizontal pipe...
  • Page 10: Connecting Gas

    The following requirements apply when connecting to an existing chimney fl ue: - only allowed when used in combination with the special DRU chimney installation set. The installation regulation is also supplied; - the dimensions should be at least 150 x 150 mm;...
  • Page 11: Placing The Wood Set

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Fig. 9 Fig. 8 Fig. 10 Fig. 11 ➠ Unscrew the 2 parkers (N) and remove them. ➠...
  • Page 12: Panes

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N !Caution - You can infl uence the fl ame image by moving the vermiculite, yet - the burner deck has to remain covered with vermiculite in order to prevent that the life expectancy of the burner is reduced;...
  • Page 13 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Fig. 16b Fig. 16c Fig. 16d Fig. 16e Fig. 16f Fig.
  • Page 14: Operation

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Fig. 17d Fig. 17e !Caution - Make sure the front pane will continue to rest on the horizontal frame. !Caution - Make sure the front pane will continue to rest on the horizontal frame ➠...
  • Page 15: Receiver

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Fig. 19 Fig. 20 7.1 Receiver The receiver is placed at the underside of the appliance. The gas control block is located here as well. (see Fig.
  • Page 16: Placing / Replacing The Batteries

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N 7.2 Placing / replacing the batteries Follow the procedure below when placing / replacing the batteries: ➠...
  • Page 17: Flame Image

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N !Tip When the gas valve is opened, the motor will run; this is audible. ➠...
  • Page 18: Malfunctions

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N 11. Malfunctions In the following table you will fi nd an overview of malfunctions that might occur, the possible causes and the reme- dies Table 3: diagnosis of malfunctions Problem...
  • Page 19 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Table 3: diagnosis of malfunctions Problem Possible cause Remedy F. Electronics keep 1.
  • Page 20: Appendix 1 Parts Included With The Delivery

    P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Appendix 1 Parts included with the delivery In the following table you can fi nd the parts that are supplied with the appliance. Table 4: Parts included with the delivery part quantity...
  • Page 21 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Notities / Notes / Notizen ........................................... . .
  • Page 22 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Notities / Notes / Notizen ........................................... . .
  • Page 23 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N Notities / Notes / Notizen ........................................... . .
  • Page 24 P R O N T O I N S T R U C T I O N F O R I N S TA L L AT I O N DRU Verwarming B.V. The Netherlands Postbus 1021, NL-6920 BA Duiven Ratio 8, NL-6921 RW Duiven 95901302UK Install_G20.indd 24...
