Summary of Contents for Blackbox Emerald EMD4000T
- Page 1 STEP X - Name of Step QUICK START GUIDE EMD4000T, EMD4000R EMERALD KVM 4K 24/7 TECHNICAL SUPPORT AT 877.877.2269 OR VISIT BLACKBOX.COM...
- Page 2 STEP 1A - Transmitter Diagrams Front panel Back panel...
- Page 3 STEP 1B - Transmitter Components TABLE 1. EMD4000T COMPONENTS NUMBER IN DIAGRAM AT LEFT DESCRIPTION DESCRIPTION Power LED LED indicates power status 12-VDC, 3-A Power In connector Connect to supplied power adapter DB9 connector Connects to serial console port Connect to PC/workstation USB USB Type B connector connector RJ-45 connector...
- Page 4 STEP 2A - Receiver Diagrams Front panel Back panel...
- Page 5 STEP 2B - Receiver Components TABLE 2. EMD4000R COMPONENTS NUMBER IN DIAGRAM AT LEFT DESCRIPTION DESCRIPTION Powers on and off unit. LED On/Off button indicates power status. Audio LIne Out Connects to speakers Audio Microphone In Connects to microphone (2) USB Type A connectors Connect to USB peripherals 12-VDC, 3-A Power In connector Connect to supplied power adapter...
-
Page 6: Step 3 - Connect Power
STEP 3 - Connect Power CONNECT POWER TO RECEIVER CONNECT POWER TO TRANSMITTER Locate the power supply adapter and the AC Locate the power supply adapter and the AC line cord. line cord. 2. Plug the DC connector of the power supply 2. -
Page 7: Step 4 - Connect The Peripherals
STEP 4 - Connect the Peripherals CONNECT THE RECEIVER CONNECT THE TRANSMITTER 1. Attach the monitor, keyboard, mouse, USB 1. Attach the Emerald Transmitter to the target and audio devices to the Emerald Receiver. PC/workstation using DisplayPort and USB Type B cables. 2. -
Page 8: Default Settings
STEP 5 - Starting Up and Default Settings for IP DEFAULT SETTINGS STARTING UP Default Settings: 1. Once everything is connected, press the Power button on the front of the Emerald Transmitter IP Address: 192.168.1.22 Receiver. Receiver IP Address: 192.168.1.21 2. - Page 9 STEP 6 - Point-to-Point Installation for IP POINT-TO-POINT INSTALLATION In a point-to-point configuration, no administrator setup of the Emerald Transmitter or the Emerald receiver is required. This enables you to install the system quickly, directly out of the box. In the point-to-point configuration, you can install only one transmitter and receiver pair on a subnet and both must be on the same subnet...
-
Page 10: Getting Started
STEP 7 - Matrix Installation and Getting Started for IP GETTING STARTED MATRIX INSTALLATION Once the IP addresses have been configured, In an IP installation, every Emerald transmitter each receiver will need to be configured for and receiver requires its own IP address. users, user passwords, user access rights The network setting is set to static, so the and default video resolutions. - Page 11 NOTES...
- Page 12 STEP X - Name of Step Contact our free, 24/7 technical support in the US at 877-877-2269 or INFO@BLACKBOX.COM For other countries, go to BLACKBOX.COM/CONTACT-US COPYRIGHT 2018 BLACK BOX CORPORATION. ALL RIGHTS RESERVED. EMD4000T_EMD4000R_QSG_REV1.PDF...
