SAFETY PRECAUTIONS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
FCC WARNING:
This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless
the modifications are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an unauthorized
change or modification is made.
ATTENTION:
POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA
PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE
LA PRISES ET POUSSER JUSQU'AU FOND.
All manuals and user guides at all-guides.com
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MDF1071-BLK and is the answer not in the manual?

Questions and answers

Summary of Contents for Memorex MDF1071-BLK

  • Page 1: Safety Precautions

    SAFETY PRECAUTIONS All manuals and user guides at all-guides.com CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the...
  • Page 2: Surge Protectors

    SAFETY PRECAUTIONS All manuals and user guides at all-guides.com INFORMATION: This equipment complies with Class B digital device regulations. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 3 All manuals and user guides at all-guides.com Dear Customer: Selecting fine audio and video equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
  • Page 4: Location Of Controls

    LOCATION OF CONTROLS All manuals and user guides at all-guides.com MAIN UNIT 1. Screen 12. Navigation Right/Skip n 2. Remote Sensor Button 3. MODE/Stop (X) Button 13. Navigation Left/Skip o Button 4. SELECT/Play/Pause (®p) 14. Mini USB Jack (Side of Unit) Button (USB CABLE PART NO.
  • Page 5 LOCATION OF CONTROLS (CONTINUED) All manuals and user guides at all-guides.com REMOTE 1. Navigation π Button 13. MODE/Stop (X) Button 2. SETUP Button 14. Navigation ® Button 3. SELECT/Play/Pause (®p) 15. Skip n Button Button 16. Search l Button 4. Navigation √ Button 17.
  • Page 6: Power Source

    POWER SOURCE All manuals and user guides at all-guides.com AC CONNECTION Insert the small end of the AC adapter into the DC 12V IN jack (located on the bottom of the unit). Connect the other end to a wall outlet having 120V AC, 60 Hz.
  • Page 7: Optional Features

    OPTIONAL FEATURES All manuals and user guides at all-guides.com HEADPHONES JACK (BOTTOM OF UNIT) For private listening, plug headphones into this jack. The speakers will be disconnected when a plug is inserted into this jack. WALL MOUNT HOLES (2) (REAR OF UNIT) If desired, the digital frame can be mounted onto a wall.
  • Page 8: Getting Started

    GETTING STARTED All manuals and user guides at all-guides.com USING A MEMORY CARD You can access media files from an external memory card as described below. This unit accepts memory cards up to these sizes: SD, SDHC, MMC, MS, MS Pro, MS DUO (with adaptor), XD, CF up to 4GB.
  • Page 9 GETTING STARTED (Continued) All manuals and user guides at all-guides.com COPYING MEDIA FILES FROM YOUR COMPUTER You can also copy media files directly from your computer to this digital frame using a mini USB cable (included). USB jack Mini USB jack USB cable Computer 1.
  • Page 10: Operation

    OPERATION All manuals and user guides at all-guides.com MAIN MENU: Press the MODE/Stop (X) button repeatedly until the Main menu appears to access the Main menu. Select a source (Card [to access the SD/MMC/MS/xD Card Slot], USB [to access the USB jack], CF [to access the CF Card Slot] or INT [to access the Internal Memory]) at the right side of the Main menu using the Navigation π...
  • Page 11 OPERATION (Continued) All manuals and user guides at all-guides.com Video: Select to play video files from the selected source, see page 16 for details. Calendar: Select and the unit will enter the calendar/clock view and show a slideshow of your photos on the left. To pause a slideshow, press the SELECT/Play/Pause button, press again to resume playback.
  • Page 12 OPERATION (Continued) All manuals and user guides at all-guides.com ROTATE (Photos) ZOOM (Photos/Videos) While viewing a photo, press the While viewing a photo, press the Rotate button to rotate the photo Zoom button 1; the unit will enter 90 degrees clockwise. Repeat to Zoom Mode 1.
  • Page 13 OPERATION (Continued) All manuals and user guides at all-guides.com SKIP SEARCH (MP3s/Videos) Press the Skip o 1 and/or n 2 Press the Search m 1 and/or l 2 button to skip to the previous or button to start searching through next picture, MP3 or video.
  • Page 14 OPERATION (Continued) All manuals and user guides at all-guides.com BASIC PHOTO PLAYBACK (Supported format: JPEG) Press the Power switch on the Select Photo using the Navigation main unit to the On (I) position to √,® buttons 1; then press the turn the unit on.
  • Page 15 OPERATION (Continued) All manuals and user guides at all-guides.com BASIC MUSIC PLAYBACK (Supported format: MP3) Press the Power switch on the Select Music using the Navigation main unit to the On (I) position to √,® buttons 1; then press the turn the unit on.
  • Page 16 OPERATION (Continued) All manuals and user guides at all-guides.com BASIC VIDEO PLAYBACK (Supported format: AVI) Video: MPEG-4 Video (AVI) Frame Rate: 30fps Dimensions: 512 x 384/320 X 240 Audio: PCM/MP3 Encoded type: Simple Profile Press the Power switch on the Select Video using the Navigation main unit to the On (I) position to √,®...
  • Page 17: Deleting A File/Folder

    OPERATION (Continued) All manuals and user guides at all-guides.com DELETING A FILE/FOLDER Press the Power switch on the Select Folder using main unit to the On (I) position to Navigation √, ® buttons 1; then press the SELECT/Play/Pause turn the unit on. (®p) button 2 to enter the Folder This unit will either show the Main menu.
  • Page 18 OPERATION (Continued) All manuals and user guides at all-guides.com COPYING A FILE/FOLDER TO INTERNAL MEMORY Press the Power switch on the Select Folder using main unit to the On (I) position to Navigation √, ® buttons 1; then press the SELECT/Play/Pause turn the unit on.
  • Page 19: Setup Menu

    OPERATION (Continued) All manuals and user guides at all-guides.com SETUP MENU The Setup menu lets you customize this digital frame by allowing you to turn the background music on or off, adjust the speed of the slideshow and more! Use the instructions on the following pages to navigate and change the options.
  • Page 20: Setup Options

    OPERATION (Continued) All manuals and user guides at all-guides.com Date/Time Normal Default Default setting SETUP OPTIONS Language: Use this option to select the desired language for the menus. Choose from English, Spanish or French. Open Screen: Use this option to set what will appear when the unit is turned on (a Slideshow, the Standard {Main Menu} or the Calendar Window).
  • Page 21 OPERATION (Continued) All manuals and user guides at all-guides.com Time: After selecting this option, set the hour using the Navigation π,† buttons, then press the Navigation ® button and the minutes will be highlighted. Set the minutes using the Navigation π,† buttons, then press the SELECT/Play/Pause (®p) button and the time will be set.
  • Page 22: Troubleshooting Guide

    TROUBLESHOOTING GUIDE All manuals and user guides at all-guides.com If you experience a problem with this unit, check the chart below before calling for service. SYMPTOM CAUSE SOLUTION Main unit, no power. AC adapter is not Connect AC adapter connected. as shown on page 6.
  • Page 23: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS GENERAL: Power Source ......AC Adapter, DC 12V Z Weight...............1.5 Lbs Dimensions ......11" (H) x 7.5" (W) x 0.75" (D) Weight and dimensions are approximate. LCD Display Size......10" (measured diagonally) Resolution.............800 x 480 Internal Memory ............128MB Speaker ..............2 x 1 W Specifications are subject to change without notice.
