Summary of Contents for Befour PS-6615
- Page 1 “ The BEST in scales and portable scoring systems.” PS-6615 Professional Portable Scale INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
Cautions & Warnings ....... Care and Maintenance Cleaning ........Assembly Instructions Troubleshooting ......Before Assembly ......Cable Replacement ……………… Assembling the PS-6615 …...…..Mounting Bracket ……………..…. Warranty Battery Installation ......Model PS-6615 Warranty ........Leveling the Platform ....Obtaining Service …………... -
Page 3: Introduction
Introduction Cautions & Warnings Failure to comply with the following may The Befour, Inc. line of electronic void the warranty on the scale. portable scales uses the most sophisticated microprocessor technology available. Each precision To ensure proper operation of the... -
Page 4: Assembly Instructions
Carefully inspect the carton for shipping damage before unpacking. If significant damage is found, keep all packaging and contact your shipper or Befour immediately. Claims must be filed with the shipper as soon as possible after receipt of damaged goods. -
Page 5: Mounting Bracket
Battery Installation This scale is powered by four (4) disposable D-cell alkaline batteries and features Befour’s exclusive ECO Weigh system that will provide 100,000+ weighings. Use the following procedure when installing a new set of batteries: 1. Using a medium Phillips screwdriver, loosen the two screws on the left side of the control console. -
Page 6: Operation Instructions
OPERATION INSTRUCTIONS Weighing Quick-Start Depress ON/ZERO button. Wait until “0.0” appears on display. Step on scale. Console Keypad The CX7 console has seven buttons. Note that some buttons perform more than one function. ON/ZERO: Depress to turn scale on or reset to zero. MENU: Depress for advanced functions such as programming the clothing deduction for the Pro-BMI calculation. -
Page 7: Special Features
. Tare: An object weighing more than 1.6 lbs. (ie. cane) can be subtracted from the total weight to determine net weight. (See pg 9) 9. ECO Weigh: Befour’s exclusive ECO Weigh battery management system provides many more weighings (100,000+) per set of batteries than other brands of scales (5 x when compared to other D cell powered scales, 10 x compared to C cell powered scales, and 50 x compared to AA celled scales). -
Page 8: Using The Pro-Bmi Function
Using the Pro-BMI Function When using the scale, the Body Mass Index (BMI) of a user can be calculated. The height of the user must be entered to correctly determine BMI. The Pro-BMI function operates in both pounds (height input in inches or feet and inches) and kilograms (height input in centimeters). -
Page 9: Using The Tare Function
Using the Tare Function Note: Only for objects heavier than 1.6 lbs. 1. Turn the scale on and wait for the display to read “0.0”. 2. Place the object(s) on the scale platform. The display will indicate the weight of the object(s). 3. -
Page 10: Programming Auto-Off Time
Programming Auto-Off Time Your scale has been preset at the factory to shut down after one minute of no use. This can be programmed from 12 seconds to 25 minutes to suit your needs. 1. Depress ON/ZERO and wait for the display to show “0.0”. Do not stand on platform. -
Page 11: User Setting Options
User Setting Options Your scale has four additional settings that you may customize for your specific needs. They are: Tone on/off: A tone sounds whenever a weight is locked in or a button is pressed. (Factory setting = 1 is “on”.) 0 = tone off. LB/KG lock: The LB/KG button can be disabled so that the scale will weigh in only the selected unit of measure. -
Page 12: Calibration
Calibration Your scale has been properly calibrated at the factory and should not require any further adjustments. The following procedure should be performed only to correct any error in calibration. Calibration is protected by a security code to avoid inadvertent access. 1. -
Page 13: Care And Maintenance
CARE AND MAINTENANCE Cleaning Procedures Proper care and cleaning of Befour scales is essential to ensure a long life of accurate and effective operation. In addition to routine cleaning, include a regular check of all structural apparatus. All external surfaces can be wiped clean with a damp cloth or tissue. -
Page 14: Model Ps-6615
This electronic scale has been inspected and tested Obtaining Service in accordance with rigid quality specifications at Befour, Inc. As a result, Befour, Inc. warrants for a Call the Befour, Inc. period of three (3) years from the date of purchase... -
Page 15: Specifications
SPECIFICATIONS Model PS-6615 Specifications DIMENSIONS Platform Height 1.75 inches (4.5 cm) Width 16 inches (41 cm) Length 18 inches (46 cm) Weight 11.5 lbs. (5.2 kg) Console Height 2.25 inches (6 cm) Width 6 inches (15.2 cm) Depth 8.75 inches (22.4 cm) Weight 2.3 lbs. -
Page 16: Transmitting Data
Optional AC Power Operation An AC adapter to power your scale through a standard AC outlet is available from Befour as an option. It plugs into the port located on the console left endcap. Due to the exceptional battery life, most owners will find battery operation to be the preferred method of powering the scale.
