- Page 1 OWNER’S MANUAL HTS56 HTS56 5.1 CHANNEL HOME THEATER SYSTEM WITH LED LIGHT EFFECTS...
-
Page 3: Important Safety Instructions
Please read this installation guide carefully for proper use of your Rockville HTS56 5.1 Channel Home Theater System. Should you need technical assistance during or after your installation please call our technical help line at 1-646-758-0144, Monday through Friday, 9am to 5pm EST. - Page 4 SET UP Place speakers in the desired position (see speaker positioning diagram on the next page). Using the included color coded speaker cables, connect the center, front, and sat- ellite speakers to the corresponding Audio Output RCA plugs on the subwoofer unit. Next plug the LED power cables to the corresponding LED power RCA plugs.
-
Page 5: Component Connections
HTS56 HOME THEATER SYSTEM COMPONENT CONNECTIONS 1. RCA AUX AUDIO INPUT: Use the RCA Auxillary jacks to connect computers, cell- phones, or any other external sound source with a 3.5mm output. You will need an RCA to 3.5mm Y cable. -
Page 6: Positioning The Speakers
POSITIONING THE SPEAKERS 1. Most people place the subwoofer in the front of the room, near the sound input source, for ease of connection. But since bass frequencies are omnidirectional the subwoofer can be placed anywhere. Try placing it near a wall or a corner for increased bass. 2. - Page 7 Make sure you have all the necessary screws and brackets. There should be five brackets and one bag of screws. If any of these items are missing, please contact Rockville. Using two screws, secure one bracket to the back of each speaker you wish to mount.
-
Page 8: Rear Panel
REAR PANEL... - Page 9 HTS56 HOME THEATER SYSTEM REAR PANEL 1. Power input 2. Power switch 3. FM antenna 4. RCA AUX in 5. Front L / R RCA DVD audio input 6. Center / subwoofer RCA DVD audio input 7. Rear L / R RCA DVD audio input 8.
-
Page 11: Front Panel
HTS56 HOME THEATER SYSTEM FRONT PANEL (MASTER UNIT) 1. Input: Use this key to switch between AUX, SD, USB, and FM modes. 2. Standby: While in AUX/SD/USB/FM modes, press and hold for 3 seconds to enter standby. 3. Master volume: turn the knob left or right to increase or decrease the system’s volume. -
Page 12: Remote Control Functions
REMOTE CONTROL FUNCTIONS : Power/Standby SD: SD input 5.1/2.1: Channel mode select USB: USB input FM: enter FM radio mode AUX: Auxillary input DVD: DVD input BT: enter Bluetooth mode SAVE: Save stations to unit memory TUNE +/– : Manually tune FM stations : Play/Pause in USB/SD/BT modes AUTO: Automatic station search CH–... -
Page 13: Mic Input
3. Turn on the Bluetooth feature on your device and ensure that it is in “discoverable” mode. Search for “Rockville HTS56” on your list of available devices and select it. 4. If your device requires a password, please use “0000”. -
Page 14: Specifications
FEATURES • HTS56 5.1 Channel Home Theater System with LED Light Effects • Plug and play system with everything you need right out of the box • 1000 Watts Peak Power • 500 Watts Program Power • 250 Watts Continuous RMS Power •... - Page 15 Entrance A, Inwood, NY 11096 Hereby declares that the product Rockville HTS56 complete powered home theater sys- tem complies with FCC rules as mentioned in the following paragraph: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 16 RockvilleAudio.com © 2019 ROCKVILLE // Features and specifications are subject to change and or improvement without notice.
