Summary of Contents for Blitz Master Wheel 50
- Page 1 Operating Instruction Mobile Wheel Carriage Master Wheel 50 Type Serial number Date Rev. D 106431 03/15...
-
Page 2: Table Of Contents
Material damage. operating instructions ......4 Operator obligations ......4 Dangers in handling the Information and tips. Master Wheel 50 ........4 Maintenance work, repairing faults, disposal ...... 5 Special dangers ........5 Technical data ........6 Transport and assembly ....7 Assembling the feet ....... -
Page 3: Introduction
Operating Instruction Introduction Introduction Warranty and liability Blitz lifting tools are the result of many years Our “General terms of sales and supply” of experience. The high quality standards apply. The operator has been in possession and the well-considered concept guarantee thereof since the conclusion of the contract. -
Page 4: Instructions For Adhering To The Operating Instructions
• Do not climb on to the Master Wheel 50, undisturbed operation of the short lifter. travel with it or climb on to the load! • The operating instructions must be ad- • Carry out lifting, lowering and moving... -
Page 5: Maintenance Work, Repairing Faults, Disposal
Special dangers • Separate the charging device from the Master Wheel 50 and the electric mains before the start of repair work. • Remove voltage from the appliance at all times before the start of repair work; to do this, remove the plug from the battery. -
Page 6: Technical Data
Operating Instruction Technical data Technical data Master Wheel 50 Load bearing capa- city Stroke 1400 Weight Length Width Height 1860 Volume db(A) <75 Vibration m/s2 <2,5 Temperature range °C +10 - +40 Wheel dimensions 185/80 min. 325/35 Wheel dimensions max. -
Page 7: Transport And Assembly
Transport and assembly Transport and assembly Assembling the wheel support The Master Wheel 50 is supplied in a carton box ready for operation. A suitable means of transport, e.g. a high-lift truck, is required for transport. Feet, handles and wheel support must be assembled on the basis of the in- structions. -
Page 8: Operation
• Do not exceed the maximum load bearing capacity of the Master Wheel 50. • Do not climb on to the Master Wheel 50, Fig. 5: travel with it or climb on to the load! • Carry out lifting and lowering operations... -
Page 9: Lifting Loads
Operating Instruction Operation Lifting loads • Lightly press button “Lift” (1) and slightly lift the wheel. • Check that the wheel is held securely. • Now fully press the button “Lift” (1) and lift the wheel to the desired height. Lowering loads • Check that the wheel is held securely. -
Page 10: Faults / Causes / Rectification
Operating Instruction Faults / causes / rectification Faults / causes / rectification There may be simple reasons if the lifter does not work properly. Please check the possible causes as specified on the following pages. Call our technical service if you are unable to de- fine the source of the problem. -
Page 11: Maintenance And Repair
Operating Instruction Maintenance and repair Possible causes Rectification Dirt, lubrication • Remove spindle cover and lubricate the Control shaft and pillar guide. motor brake motor battery Maintenance and repair The operator must carry out regular servicing every 3 months. If the appliance is in perma- nent operation or in a particularly dirty envi- ronment, shorten the maintenance intervals accordingly. - Page 12 Operating Instruction Table of Contents Whenever necessary Replace batteries. Description of periodic work Warning Risk due to unexpected activation. Before the start of the periodic work: • Separate the appliance from the electrical mains. • Press the emergency off switch •...
-
Page 13: Safety Examination
Operating Instruction Safety examination Safety examination Greasing load support rollers • All rollers must run easily. The safety examination is necessary to gua- rantee the safety of the Master Wheel upon commissioning. This must be carried out and certified in specified cases by a qualified per- Replacing the battery son. -
Page 14: Appendix
Capacité Fabrik-Nr. max. Druck pneum. Serial No. max. pressure pneum. Série N° pression pneum. max. Baujahr max. Druck hydr. Year max. pressure hydr. Année pression hydr. max. BLITZ M. Schneider • Werkzeug- u. Maschinenfabrik GmbH • D-78199 Bräunlingen 106431 03/15... -
Page 15: 11.2 Safety Examination
Operating Instruction Appendix 11.2 Safety examination Master Wheel 50 Serial No. Year of construction Test steps for the safety examination • Nameplate attached and labelling in place • Warning signs in place (load bearing capacity and warning instructions) • Check supporting construction for deformation and cracks •... - Page 18 BlitzRotary GmbH Hüfinger Straße 55 D-78199 Bräunlingen Telefon +49.771.9233.0 Telefax +49.771.9233.99 info@blitzrotary.com www.blitzrotary.com...
