Gigabit Ethernet 1000 Base SX
Fiber # of
Part #
Connector Fibers
S30-2MLC LC 2
S35-2MLC LC 2
OM1 Multimode fiber @ 200/500MHz-km
OM2 Multimode fiber @ 500.500MHZ-km Laser Rated for GbE LANs
Gigabit Ethernet 1000 Base SX
Fiber # of
Part #
Connector Fibers
S30-2MLC-2 LC 2
OM3 Multimode fiber @ 2000/500MHz-km Optimized got 850nm VCSELs
Gigabit Ethernet 1000 Base LX
Fiber
Part #
Connector Fibers
S30-2SLC-10 LC
S35-2SLC-10 LC
S30-2SLC-30 LC
S35-2SLC-30 LC
6
All manuals and user guides at all-guides.com
Fiber Type
Max Distance
OM1 &
OM1/OM2 Length
OM2
220/550m
Multimode 850nm
(720/1800ft)
220/550m
Multimode 850nm
(720/1800ft)
Max
Fiber Type
Distance
OM3
OM3
2km
Multimode
(1.2mi)
# of Fiber Max Wave
Type Distance Length
Single 10km
2 1310nm
Mode (6.2mi)
Single 10km
2 1310nm
Mode (6.2mi)
Single 30km
2 1310nm
Mode (18.6mi)
Single 30km
2 1310nm
Mode (18.6mi)
Optical Optical Receiver
Wave
Budget Power Sensitivitiy
(dBm) (dBm)
7.5 -9.5 ~ -1
7.5 -14 ~ -8
Optical
Wave Optical
Budget
Length Power (dBm)
(dBm)
1310nm 10 -9 ~ -1
Optical Optical
Budget Power
(dBm) (dBm)
18 -9.5 ~ -3
18 -9.5 ~ -3
18 -2 ~ +3
18 -2 ~ +3
IFS SFP Tranceivers User Manual
Operating
Temperature
(dBm)
0 to + 50C
-17
(32 to 122F)
-40 to +75C
-17
(-40 to 167F)
Receiver
Operating
Sensitivitiy
Temperature
(dBm)
0 to + 50C
-19
(32 to 122F)
Receiver
Operating
Sensitivitiy
Temperature
(dBm)
0 to + 50C
-20
(32 to 122F)
-40 to +75C
-20
(-40 to 167F)
0 to + 50C
-23
(32 to 122F)
-40 to +75C
-23
(-40 to 167F)
