North Kiteboarding 2020 SONAR FOIL SYSTEM User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2 0 2 0
S O N A R F O I L S Y S T E M
U S E R
M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2020 SONAR FOIL SYSTEM and is the answer not in the manual?

Questions and answers

Summary of Contents for North Kiteboarding 2020 SONAR FOIL SYSTEM

  • Page 1 2 0 2 0 S O N A R F O I L S Y S T E M U S E R M A N U A L...
  • Page 2 RELEASE DATE: AUGUST 2019 VERSION: FS01...
  • Page 3 Thank you for choosing North. At North we are drawn to nature’s ever-changing playground – where water meets wind. Those two elements create an alchemy that is never the same, one day to the next. It stirs our restless souls, our hearts quicken. It promises us fire within. We chase it.

  • Page 4: Release Of Liability

    To waive any and all claims, that you have or may have in the future against North Kiteboarding and all related parties resulting from the use of the North Kiteboarding product and any of its components.

  • Page 5: Safety Warnings

    SAFETY WARNINGS For your safety and the safety of others, North Kiteboarding strongly urge you to undergo lessons with a recognised certified instructor prior to using this product. This user manual is NOT a substitution to lessons. Kiteboarding involves unavoidable risks so it is important that you familiarise yourself with these risks and take appropriate measures to minimise risks as much as possible.

  • Page 6: Warranty Policy

    North Kiteboarding website. North Kiteboarding warranties our products to be free from major defects in material or workmanship to the original purchaser ONLY, for a period of 365 days* from the date of purchase.
  • Page 7 There are no warranties that extend beyond the warranty specified herein. For any warranty claims please contact your North Kiteboarding retailer. A claim form can be downloaded from northkb.com.
  • Page 8 CON T EN TS 1. Foil Safety 2. Foil Overview 3. Foil Assembly 3.1. Board Adaptor to Mast assembly 3.2. Fuselage to Mast assembly 3.3. Stabilizer assembly 3.4. Front wing assembly 4. Foil to Board Assembly 4.1. Attaching your Sonar Foil System to the North Scoop using the track mounting system 4.2.
  • Page 9 • We recommend using a North Kiteboarding wing, stabilizer and mast cover for your Foil- set, to provide maximum protection and longevity of the products. U S E R M A N U A L S O N A R F O I L S Y S T E M...
  • Page 10 2. FO IL OVERV I EW 1 - Board Adaptor 2 - Mast 3 - Stabilizer 4 - GeoLock 5 - Fuselage 6 - Front Wing 7 - Foil Tool Kit (Marine grade grease, Torx T40 Tool to tighten screws)
  • Page 11 SCREW PACK A SONAR BOARD ADAPTOR 2 x M8x40 TH CSK T40 Screws SCREW PACK B SONAR FUSELAGE 2 x M8x35 THCS T40 Screws 2 x M8 Flat Washers SCREW PACK C SONAR STABILIZER 4 x M8x16 TH CSK T40 Screws SCREW PACK D SONAR 850 WING 3 x M8x25 TH CSK...
  • Page 12 3. FO IL ASSE M B LY NOTE: It is extremely important that you assemble your North Foil System and Foil Board properly. Assembling the product correctly will ensure the product performs well, is safe for users and will avoid unnecessary damage. WARNING: Do not use power tools for installation as it may cause damage as control of torque and power is limited.

  • Page 13: Stabilizer Assembly

    3.2 FUSELAGE TO MAST ASSEMBLY Ensure all surfaces are free from dirt or sand prior to assembly. This is particularly import- ant when assembling the Fuselage onto the Mast using the GeoLock connection. Next, grease the threads of the screws supplied in Screw Pack B properly using the marine grade grease provided in the Tool Kit.
  • Page 14 4 x M8x23 TH CSK T40 4 x T-Nuts Please Note: Boards (including screw packs above) sold separately. The North Scoop, Chase or Sense Foil Boards can be purchased additionally at a North Kiteboarding retailer. Visit www. northkb.com to find your local retailer. WARNING:...
  • Page 15 Again, insert one T-Nut into each track using the central track entry points, ensuring the correct orientation is maintained as per diagram (diagram 1). This time, slide the T-Nuts all the way forward towards the nose of the board. Position the Board Adaptor of the assembled foil system parallel to the base of the board, above the tracks.
  • Page 16 4.4 ATTACHING YOUR SONAR FOIL SYSTEM TO A NON-NORTH BOARD Please refer to the other manufacturer’s user manual for installation. WARNING: Use of a non-North board with a North Foil System is at the user’s own risk. North Kiteboarding does not accept any responsibility. WARNING: Ensure you’re using the right length screws on the Scoop, the screws have to be fully engaged to...
  • Page 17 5. FO IL A N D B OA R D D I SAS S E M B LY WARNING: Do not use power tools for disassembly as it may cause damage as control of torque and power is limited. Doing so will render your warranty void. WARNING: If required, a soft rubber mallet should be used with great care and attention.
  • Page 18 5.3 FRONT WING DISASSEMBLY Whilst supporting the Front Wing, use the Torx T40 tool provided in the Tool Kit to individually loosen the three screws. Remove the three screws, then carefully and securely set the Front Wing aside. Store screws in a safe and accessible place. 5.4 STABILIZER DISASSEMBLY Whilst supporting the Stabilizer, use the Torx T40 tool provided in the Tool Kit to individually loosen the two screws.

  • Page 19: Maintenance

    Wash your Sonar Foil System in fresh water thoroughly after each use. • • Use recommended North Kiteboarding boards, foot straps and accessories. • Check your Sonar Foil System prior to each use. Ensure screws are tight and there are no cracks, holes or scratches which could compromise your Sonar Foil System’s structure.
  • Page 20 N O R T H K B . C O M...
