Summary of Contents for Blueshape MVQUICKAL
- Page 1 HOT SWAP SYSTEM FOR ALEXA® USING V-LOCK LITHIUM ION BATTERIES Model MVQUICKAL OPERATING INSTRUCTIONS Revision 1.0 www.blueshape.net Printed in Malta 2011...
- Page 2 Introduction MVQUICKAL is a hot swap system to be installed as an interface between an ALEXA Plus camera and a V-lock battery pack. The main purpose is to allow battery replacement without any power interruption to the camera through an intelligent detection of the battery removal.
- Page 3 UPS is providing continuity power. When operating as the main power source, the runtime provided by MVQUICKAL depends by the state of charge of its internal battery and the actual power consumption. The LED array displays the state of charge based on the internal...
- Page 4 How to check the state of charge Out from the box, the internal battery of MVQUICKAL has a state of charge of about 50% or higher. To verify the state of charge: When the external battery is installed: Press the “Check” button to verify the state. The LED will stay on for about 3 sec showing the state (see table above).
- Page 5 LED button once to restart the countdown and prolong the operating period. It is preferable to switch off MVQUICKAL after a working session or before storage to minimise the power consumption and the self- discharge.
-
Page 6: Technical Specifications
COMMS Data communication Exercise caution handling these contacts and do not touch by hand unnecessarily. Package contents: • MVQUICKAL • Charger 110 ~ 240V/ 3A • Power connector • Operating manual At our own responsibility we declare that this product is... - Page 7 3. Figure shows lower Alu spacer part fixed to camera. Note the 2 large terminals (+ve) and (-ve) and the tiny data connector that now need to be connected to the wires on the main body of MVQUICKAL...
- Page 8 4. Figure shows the main upper body brought into proximity of the lower body for connection 5. Screw in the main body using 6. MVQUICKAL is now ready to the 4 x M3x48 longer screws provided...
- Page 9 Warranty BLUESHAPE MVQUICKAL is warranted to be free from defects in materials, workmanship and functionality for a period of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation.
- Page 12 NEW CELL TOP Srl VIA LIGURIA 4-6, 42124 REGGIO EMILIA, ITALY TEL. +39 0522 518556 FAX. +39 0522 277084 WEB: www.blueshape.net EMAIL: info@blueshape.net...
