Aeon 60210 Manual

Three positions allow you to select the best height for your TV set on the stand. Use the appropriate hooked
opening on the vertical bar (11) to determine TV height. Using the top hooked opening on vertical bar (11) will set
the TV lower on the stand, while the bottom hooked opening will set the TV higher on the stand. Attach one of the
three hooked opening to the upper cross bar of the TV stand.
11
A
A) With two people, carefully life the top of the TV to hang the vertical rails (part # 7) onto the horizontal cross bar of the TV
mount, catching the hooked opening of the vertical rails securely. Next, secure the bottom of the vertical rails and rmly
'lock' them into place. (Refer to step 6 to determine appropriate height setting).
B) Using a screwdriver and the two fasteners labeled part "K", thread (each) fastener upwards through the angled metal tab on Side
A and Side B to secure both vertical rails onto the TV bracket.
Note: Since your TV is now wall mounted, access to these fasteners will be limited. If your TV is facing you, please swivel the TV to
the left to tighten the fastener on 'Side A' and then swivel to the right to tighten the fastener on 'Side B' .
Select Height for Your TV Set
C
B
Attach Rails to TV Bracket
Side A
TV Wall Mount with Two Shelves
Hardware List
Side B
Parts List
MANUAL
