WinFast CarePhone
Quick Installation Guide
WinFast CarePhone Hardware Installation
Before installing WinFast CarePhone, please make sure the outgoing
network is correctly configured as instructed by your ISP.
We recommend you to use Windows XP SP2 operating system with
Internet Explorer 6.0 or newer version of browser.
This installation guide is only intended for connecting WinFast
CarePhone. For other advanced functions or information related to the
product, please read the complete user manual on the CD. Or you can
visit our website
http://www.leadtek.com.tw
for the detailed product
information.
Thank you for buying WinFast CarePhone. Please read this guide
carefully as the following chapters will take you through the installation
and network configuration of WinFast CarePhone. Please contact our
technical staff if you encounter other problems concerning the
installation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CarePhone and is the answer not in the manual?

Questions and answers

Summary of Contents for WinFast CarePhone

  • Page 1 Internet Explorer 6.0 or newer version of browser. This installation guide is only intended for connecting WinFast CarePhone. For other advanced functions or information related to the product, please read the complete user manual on the CD. Or you can visit our website http://www.leadtek.com.tw...

  • Page 2: Hardware Connection

    1. Connect the Ethernet cable from the computer to the switch or hub. 2. Connect the Ethernet cable from WinFast Fig. 1-2 CarePhone to the same network device. (Fig. 1-2) Procedure Step 1 Connect the included DC 5V power adapter to Fig.
  • Page 3 Step 3 Right-click the "My Neighborhood" icon on desktop and choose "Properties". Right-click on "Local Area Connection" icon, and choose "Properties". (Fig. 1-5) Fig. 1-5 Choose "Internet Protocol (TCP/IP)" and click "Properties". (Fig. 1-6) Choose "Use the following IP address", and type 192.168.0.139 as the IP address.
  • Page 4 The default IP address of WinFast CarePhone is 192.168.0.100, so you have to type "Ping 192.168.0.100" and press "ENTER". The "PING" command is used to make sure if the computer and WinFast CarePhone are correctly connected. If the computer and WinFast CarePhone are correctly connected, the MS-DOS window will look like Fig.
  • Page 5 Note: To prevent IP conflicts between the product and other devices in the local area network, we recommend you to use an independent network connection to connect the computer and WinFast CarePhone through Switch/Hub. Step 6 Click "Internet Explorer". Click the "stop" icon , click "tools", and choose "Internet...
  • Page 6 IE will ask you to download ActiveX control. Please notice the status bar (Fig. 1-13) and the message below the address bar. Click the message below the address bar and choose "Install ActiveX Control". (Fig. 1-14) Fig. 1-13 Fig. 1-14 Note: If the firewall in your computer is enabled, you will see a security alert.
  • Page 7 Downloading ActiveX will take 30 seconds to 1 minute. Do not close the window when downloading. When the installation is completed, the image will be displayed in the browser. (Fig. 1-17) Step 7 We recommend you to choose "User Management" to modify the Username and Password after you login for the first time and after you download ActiveX Control.
  • Page 8 Other references To set up the information of the persons to call to, please refer to: Leadtek_WinFast_CarePhone_PC_UserManual_B5 For the detailed descriptions of all the parameters and functions of the product, please refer to: Leadtek_WinFast_CarePhone_PC_UserManual_B5 For troubleshooting (including the problems during installation), please refer to: Leadtek_WinFast_CarePhone_PC_UserManual_B5...
  • Page 9 WinFast CarePhone Network Connection The following will tell you how to install WinFast CarePhone to your networl. (Please see the complete document on the CD for the detailed instructions on how to configure the network settings.) Please make sure your computer has connected to the Intranet or Internet through the Router or ADSL/Cable Modem.
  • Page 10 Internet, and usually works in conjunction with the Hub or the Switch. Follow the steps below to connect WinFast CarePhone to the network environment with a router. Procedure 1. Connect the Ethernet cable to WinFast CarePhone.
  • Page 11 Enabling APS will manage the phone number of WinFast CarePhone and the network configuration of the server more effectively. Just choose the appropriate IP address type in the built-in web page of WinFast CarePhone, and APS will save you a lot of troubles for setting up the system information.
  • Page 12 After APS is successfully downloaded, the system indicator (yellow) will stop blinking. Go to the WinFast CarePhone homepage to reboot the unit or use the "RESET" button on the back to manually restart the unit.
  • Page 13 Using Leadtek SoftPhone 1 SoftPhone Interface The functions are illustrated in the following figure. Minimize and Registration Call Display M y Account Show all Close Keys status Call history Show Webcam Missed calls Button Show Answered calls Add contact menu Show Detail calls Phonebook...
  • Page 14 2 Starting SoftPhone There are two ways to start SoftPhone: 1. From the Windows task bar: Start Programs Leadtek Research Inc SoftPhone SoftPhone. 2. Click the SoftPhone shortcut on the desktop. Windows Security Alert: Windows firewall may block SoftPhone and displays an alert message.
  • Page 15 Note: Before making a call, please notice the following items: 1. Please check the speaker and microphone on your computer before using Leadtek SoftPhone. 2. Please run SoftPhone first to make sure no errors will occur. 3. Please make sure the network connection is working before you can make a call.
  • Page 16 3 Making a Call The SoftPhone allows you make calls by using different methods to enter a number. Leadtek SoftPhone can dial to a phone number or an IP address. Dialing to a phone number (Proxy Mode) 1. In Proxy Mode, You need to register to the SIP Server with a VOIP account.
  • Page 17 Other methods You can also use the following methods to make calls: Select a number from the phonebook (Fig. 5) Select a number from the calls log (Fig. 6) Modifying the number When you enter the wrong number, you can use the "Backspace" key on the keyboard to erase a number, or you can click to clear the entire number.
  • Page 18 4 Displaying Incoming and Outgoing Calls The system screen will display both incoming and outgoing calls. 1. When there is an incoming call, the screen will look like Fig. 7. 2. When there is an outgoing call, the screen will look like Fig. 8. 3.
  • Page 19 5 Calls Log Calls Log can display all missing, incoming and outgoing calls. Click button to view the list. Show All Call Logs To view all calls, select the tab and select the "Show All" option to view all calls that have been received through SoftPhone.
  • Page 20 6 Phonebook This function allows users to store contacts which can be divided by groups, added, or deleted. Phonebook To display the Phonebook, click button on the main panel. Display by Contact To view all name by contact, click the tab, select the "Display by Contact"...
  • Page 21 IP: Input the IP address of the contact. Password: If the contact uses SoftPhone, you don't have to input password. If the contact uses WinFast CarePhone, the password is the same with the surveillance password in the WinFast CarePhone homepage.
  • Page 22 Examples For Advanced Settings The following examples show how Leadtek SoftPhone users call WinFast CarePhone users. Virtual IP Address Service Private 172.16.5.123 Fixed IP Address Provider Internet Intranet 61.62.13.57 Tunneling Fixed IP Address 59.120.139.66 Service Service Fixed IP Address Internet...
  • Page 23 7 Call Recording Call recorder will record participants of concurrent call. The call recording depends on whether you manually start recording at the conversation to store your local and remote video/audio stream at your disk. Mute Button The mute button is used to mute or silence the voice of the caller during the conversation with other parties.
  • Page 24 8 Appendix SIP Setting If you have multiple providers account, you have to specify through which provider you would like to make a call. You may configure provider proxy for outbound calling by following steps: 1. Bring up the main panel 2.
