Summary of Contents for Spartan CADET
- Page 1 PRODUCT MANUAL CADET Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800.435.3866 SpartanTool.com order by phone order online © 2019 Spartan Tool LLC Part #70700170...
-
Page 2: Table Of Contents
Contents WARNINGS ......................4 TECHNICAL INFORMATION . - Page 3 Notes...
-
Page 4: Warnings
Warnings • Read the safety and operating instructions before using any Spartan Tool product . Drain and sewer cleaning can be dangerous if proper procedures are not followed and appropriate safety gear is not utilized . • Before starting unit, be sure to wear personal protective equipment such as safety goggles or face shield and protective clothing such as gloves, coveralls or raincoat, rubber boots with metatarsal guards, and hearing protection . -
Page 5: Technical Information
Technical Information GENERAL Pipe Sizes 1¼" to 3" diameter Max water delivery 2 .0 GPM Max pressure delivery 1,500 PSI Weight 50 lbs Unit size 14"W x 22½"D x 9"H MOTOR Horsepower 1 .36 HP Speed (RPM) 2,500 Max electric draw 15 Amps Volts Frequency (Hz) -
Page 6: High Pressure Water Jetting
High Pressure Water Jetting High pressure water jetting is the utilization of high pressure water combined with sufficient water flow to remove debris in drain/sewer pipes . High pressure water jetting can also be used to remove debris on surfaces . A high pressure water jet consists of a pump, a motor or engine, a length of high pressure hose, and a various assortment of nozzles . -
Page 7: Safety Procedures
GROUNDING INSTRUCTIONS Before using your Spartan Tool equipment, make sure a properly grounded, three-hole outlet is available . If not, as in some older homes, use a three-prong adapter and connect the green pigtail (or grounding lug) to a known ground, such as a cold water pipe . A three- prong adapter with grounding lug can be purchased from any hardware store . - Page 8 Avoid contact with ears, eyes, or mouth with contents of pipe to lower the risk of infection . Due to possibility of contact with contamination and explosive sewer gases, do not smoke when operating the Cadet Avoid exposing any cuts to drains/sewers and sewer cleaning equipment .
-
Page 9: Pre-Operation Checklist
. Replace the screen, water inlet valve and hose . WARNING Never operate the Cadet without the inlet screen . Damage to the pump may occur . FIG. 2 Use only garden hose with 5⁄8" I.D. Make sure there are no impurities in the incoming water supply. If the possibility of impurities exist, turn on the incoming water supply for 15 seconds to remove debris or rust build up. -
Page 10: Operating Instructions
Unspool the HP hose and push at least 3 feet of hose into the pipe . CAUTION Vibration while operating the Cadet is normal . Protect the high pressure hose from sharp edges and protect property from damge due to contact with the high pressure hose . - Page 11 1 to 2 full turns before energizing the equipment and setting the pressure . 10 . The Cadet will operate up to 1,500 PSI with supplied open nozzle (70700670) and 700 PSI with the supplied closed nozzle (72705400) .
-
Page 12: Preventative Maintenance & Troubleshooting
Preventative Maintenance & Troubleshooting 1. Cold Weather Protection: To avoid damage to the pump and water jet hose, keep the Cadet from freezing temperatures . If the Cadet must be stored in freezing temperatues, you must use one of the following methods: •... -
Page 13: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION Clean . Use adequate size . Inlet suction clogged or improper size . Check more frequently . Inadequate water supply . Check flow available to pump . Worn nozzle . Replace nozzle of proper size . Leaky discharge hose . -
Page 14: Final Assembly
DRAWN CHECKED APPROVE Item Part Number Description Qty. 70700400 Pump, Cadet water 70700200 Bracket, Cadet motor mount 70700210 Shield, Cadet motor 70700300 Motor, Cadet electric 71105800 Adapter, ¾ GHT SWVL - 3⁄8 NPT 71707600 Washer, garden hose w/strainer 77721400 Coupler, ¼" quick male FNPT 79904464 ST EL 90D ½... - Page 15 Nut, 5⁄16-18 ZN clip 73821200 Nut, nylon locking ¼-20 44290500 Bridge rectifier 70700150 Decal, user guide 70700500 Case, Cadet SKB 03850100 Nut, hex KEP 10-32 zinc pltd 70700700 Switch, 15A breaker rocker 79948040 Valve, flow control 3⁄8 NPT 44302800 Strain relief - rt angle power cord 44302810 Nut ½...
-
Page 16: Power Pack Assembly
Power Pack Assembly POWER PACK ASSEMBLY... -
Page 17: Power Pack Assembly
Power Pack Assembly POWER PACK ASSEMBLY... -
Page 18: Motor & Pump Assembly
Motor & Pump Assembly MOTOR & PUMP ASSEMBLY FILL / DRAIN DRAWN CHECKED APPROVE... -
Page 19: Wiring Diagram
Wiring Diagram WIRING DIAGRAM... -
Page 20: Standard Accessories
Accessories STANDARD ACCESSORIES Part Number Description 71109900 Tip cleaner 543500-01 Hose S .S . trap 30' x 3⁄16" ID 70700670 Open nozzle 72705400 Closed nozzle 5G243631 Gloves 70700160 Quick guide 71721400 Male quick coupler ¼ FNPT... -
Page 21: Warranty Information
Spartan Tool will direct where to take or send the equipment for service . If the defect is covered by the warranty, Spartan Tool will repair or replace, at its option, the defective equipment, without charge for labor or materials (freight and insurance are the purchaser's responsibility) . - Page 22 CONTACT US Spartan Tool LLC 1618 Terminal Road Niles, MI 49120 800 .435 .3866 SpartanTool.com 70700000MAN-1907...
