Installation Instructions
Installing the Handle
1. Push aside the door gasket on the side you
wish to install the handle. Under the gasket
you will see two designated holes for handle
installation and pre-installed screws.
2. Install the handle tightly as shown with two
screws, lock washers and flat washers pre-
installed.
Reversing the door swing of your appliance
Should you desire to reverse the opening direction of the door, please follow the instructions below:
Open the glass door to a 90-degree angle, take out the 2 screws from the lower
A.
door axis (2), remove the door (3), axis plate spacers and the axis plate from the
door.
Take out the 3 hinge screws from the top right hinge (4) and remove it.
B.
Unscrew 2 screws at the bottom of the door and remove the Reed switch (6), then
C.
install the Reed switch at the top of the door frame.
Remove the decorative hole covers (8) from the top left of the cabinet and install
D.
the new top hinge (7) at top of the cabinet with 3 screws. Install the decorative hole
covers on the top right of the cabinet.
Install the door with spacers and correctly align door.
E.
