- Page 1 All manuals and user guides at all-guides.com ® Patent Pending Model No. 831.108150 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction.
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents Warning Decal Placement ..............2 Important Safety Instructions . -
Page 3: Important Safety Instructions
All manuals and user guides at all-guides.com Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the following important precautions before using the spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure 13. - Page 4 All manuals and user guides at all-guides.com has been repaired or replaced by a qualified 27. DANGER—To reduce the risk of drowning: electrician. Prolonged immersion in the spa may cause hyperthermia, a dangerous condition which 20. Keep all electrical appliances such as radios, occurs when the internal body temperature telephones, televisions, and lights at least rises several degrees above the normal body...
-
Page 5: Before You Begin
For your benefit, read this manual carefully before using the IMAGE ® RENEW 815. If you have addition- Before reading further, please familiarize yourself with al questions, please call our Customer Service the parts that are labeled in the drawing below. -
Page 6: Choosing A Location For The Hydrotherapy Spa
All manuals and user guides at all-guides.com Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the spa. These factors vary depending on whether you use the spa inside or outside. We have listed several factors you may wish to consider as you decide where you want to use the spa. -
Page 7: Assembly
All manuals and user guides at all-guides.com Assembly Before beginning assembly, carefully read the • Assembly requires only the included air pump. following information and instructions: Note: The included flat wrench is not required for assembly. The flat wrench is used to remove the •... - Page 8 All manuals and user guides at all-guides.com 2. Orient the dry side jet pack (A) as shown and place it near the three holes in the Inflatable Liner (29). Small Hole Slide the Temperature Probe Gasket (46) over the connector threads on the Temperature Probe Receptacle Assembly (30).
- Page 9 All manuals and user guides at all-guides.com 5. Attach the nozzle on the air pump to the valve on Air Valve the floor of the Inflatable Liner (29). Use the air pump to fill the bottom of the Inflatable Liner with air. Be extremely careful not to puncture the Liner.
-
Page 10: Using The Hydrotherapy Spa
All manuals and user guides at all-guides.com Using the Hydrotherapy Spa The spa is designed to be used by up to three adults. same circuit. Replace the power cord immediately, if it The spa holds 268 gallons of water and offers an becomes damaged. - Page 11 All manuals and user guides at all-guides.com utes. You should now test the pH level of the water. insert the key and turn it counterclockwise a quarter Use the included test strips to check the pH of the turn. water. Refer to the instructions on the test strip pack- aging to see how to use the test strips.
- Page 12 All manuals and user guides at all-guides.com The spa jet unit features an automatic filter cycle and DRAINING THE PUMP freeze protection. If the spa jet unit has not been operated for three hours, the pump will begin circulat- After the spa is drained (see DRAINING THE SPA ing the water for twenty minutes to filter any impuri- above), the pump in the dry side jet pack should also ties.
-
Page 13: Maintenance
All manuals and user guides at all-guides.com Maintenance CLEANING THE INFLATABLE SPA LINER 4. Keep all chemicals out of the reach of chil- dren and pets. The liner should be cleaned with a mild soap solution. 5. Keep all containers closed tightly when not Do not use solvents. -
Page 14: Trouble-Shooting
All manuals and user guides at all-guides.com Trouble-shooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-888-936-4266, Monday–Friday, 8:00 am–6:30 pm Eastern Standard Time (excluding holidays). - Page 15 All manuals and user guides at all-guides.com 9. SYMPTOM: THE SPA JET UNIT CAVITATES allow the spa to maintain a safe tempera- DURING USE ture by running in automatic mode. Allowing the spa jet unit to freeze will dam- a. Adjust the water level. This usually occurs only age the unit.
- Page 16 All manuals and user guides at all-guides.com NOTES...
- Page 17 All manuals and user guides at all-guides.com NOTES...
- Page 18 All manuals and user guides at all-guides.com CUSTOMER RECORD Model No.: Serial No.: Retailer Name: Purchase Date: Retailer Address:...
-
Page 19: Limited 90-Day Spa Warranty
All manuals and user guides at all-guides.com Limited 90 Day Spa Warranty ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under nor- mal use and service conditions, for a period of 90 days from the date of purchase. Specifically covered under this warranty are the spa shell, the plumbing, the components, and the wood or tile exterior. -
Page 20: Ordering Replacement Parts
• The NAME of the product (IMAGE ® RENEW 815 spa) • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST/EXPLODED DRAWING attached to the center of this manual). - Page 21 All manuals and user guides at all-guides.com Remove this Part List/Exploded Drawing from the manual. Save this Part List/Exploded Drawing and the manual for future reference. Protect Your Spa Investment With the help of customer input, we have deter- take 1 to 3 days (depending on the room temperature) mined key information you need to be aware of to to heat the water in the spa.
- Page 22 All manuals and user guides at all-guides.com PART LIST—Model No. 831.108150 R1199A Key No. Qty. Description Key No. Qty. Description Pressure Switch Wet Side Gasket Wet Side Nut Temperature Probe High Limit Rubber Foot Inflatable Cover Tek Screw #8 x 1/2” Screw O-ring Cover Panel Square Endcaps...
- Page 23 All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. 831.108150 R1199A...
