Summary of Contents for Unova Intermec EasyCoder 501
- Page 1 All manuals and user guides at all-guides.com Installation Instructions P/N 1-960345-02 Edition 2 September 1998 EasyCoder 501/601 Dual Serial Interface Kit...
- Page 2 All manuals and user guides at all-guides.com EasyCoder 501/601 – Installation Instructions DUAL SERIAL INTERFACE KIT Introduction The Serial Interface Board adds two serial communication ports ("uart2:" and "uart3:") to the standard serial communication port ("uart1:"). Note: Illustrations show an EasyCoder 501. The printer's software detects when a Serial Interface Board is The principles for fitting this optional installed and adds communication and buffer setup options for the...
- Page 3 All manuals and user guides at all-guides.com EasyCoder 501/601 – Installation Instructions DUAL SERIAL INTERFACE KIT, cont'd. Step-by-Step Installation The only tool required is a Torx #T10 screwdriver. Instructions Turn off the power and remove the power cord. Remove the communication cable from communication port "uart1:".
- Page 4 All manuals and user guides at all-guides.com EasyCoder 501/601 – Installation Instructions DUAL SERIAL INTERFACE KIT, cont'd. Step-by-Step Installation Remove the existing cover plate. Instructions, cont'd. Make sure that the CPU board is strapped and equipped for the desired type of communication on "uart1:" (see the EasyCoder 501 or EasyCoder 601 Technical Manual).
- Page 5 All manuals and user guides at all-guides.com EasyCoder 501/601 – Installation Instructions DUAL SERIAL INTERFACE KIT, cont'd. Step-by-Step Installation Reassemble the printer in reverse order. Instructions, cont'd. Connect the communication cables to their respective connec- tors. Please refer to page 6 for pinout descriptions. Connect the power cord and turn on the power.
- Page 6 All manuals and user guides at all-guides.com EasyCoder 501/601 – Installation Instructions DUAL SERIAL INTERFACE KIT, cont'd. Straps "uart3:" "uart2:" The following straps are used to set up the desired type of interface on the communication ports "uart2:" and "uart3:". Communication Port "uart2:"...
-
Page 7: Connector Configuration
All manuals and user guides at all-guides.com EasyCoder 501/601 – Installation Instructions DUAL SERIAL INTERFACE KIT, cont'd. Connector Configuration "uart2:" is a DB25 female connector. "uart3:" is a DB25 male connector. The mounting holes are connected to chassis ground. "uart2:" "uart3:"...
