- Page 1 EC1000 ENGINE CRANE 1 TONNE MAX CAPACITY OWNER’S MANUAL FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
- Page 2 Always lock the legs and jib in position before lifting a load. The nuts and bolts supplied with the crane are all high strength and should not be sub- stituted for inferior types. Before each use ensure that all nuts and bolts are correctly fitted and tight. WWW.SGS-ENGINEERING.COM PAGE 2...
- Page 3 OPERATING INSTRUCTIONS WARNING: This double pump long ram is designed for lifting purposes only – not for supporting loads. Do not load beyond its rated capacity. IMPORTANT: It is possible that air has got into the hydraulic system causing poor lifting performance.
- Page 4 Attach the hook and chain assembly (No. 24) to the boom using nut, bolt and washer (No. 23 & 10). Secure the handle (No. 19) to the main support post (No. 8) using four bolts (No. 21) and four washers (No. 20). Now tighten all nuts and bolts. WWW.SGS-ENGINEERING.COM PAGE 4...
- Page 5 ITEM DESCRIPTION ITEM DESCRIPTION BASE RAM UNIT LEFT LEG BOLT M16X90 RIGHT LEG NUT & WASHER M16 LOCK PIN BOLT M16X60 SPLIT PIN HANDLE BOLT M6X30 WASHER 8 NUT M6 BOLT M8X20 MAIN SUPPORT POST BOOM EXTENSION BOLT M14X90 BOLT M14X75 NUT &...
- Page 6 Pump feels unsteady The cup seal could be Replace cup seal. under load. worn out. Will not lower completely. Air block. Unit requires Release air from the hydraulic lubrication. pump by removing filler plug. Oil external moving parts. WWW.SGS-ENGINEERING.COM PAGE 6...
- Page 7 SGS Engineering (UK) Ltd West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd Engine Crane TYPE OF EQUIPMENT: EC1000 PART NUMBER: APPLICATION OF EC COUNCIL DIRECTIVES / STANDARD:...
