GENERAL INSTRUCTIONS
FOR INSTALATION, USE
AND MAINTENANCE
WASHER-EXTRACTORS
HIGH SPEED
DFI-25/57 MP
P-537085

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DFI-25 MP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Domus DFI-25 MP

  • Page 1 GENERAL INSTRUCTIONS FOR INSTALATION, USE AND MAINTENANCE WASHER-EXTRACTORS HIGH SPEED DFI-25/57 MP P-537085...
  • Page 2 DFI – 25 MP DFI – 57 MP Figs. 1 A = Electric hose B = Cold water inlet C = Hot water inlet D = Drainage E = Vapour outlet F = Vapour inlet G = Decalcified water inlet H = Electric hose dispensers Cold water inlet...
  • Page 3 Fig. 3 Fig. 2 Fig. 4 Fig.5 A = Mains tap; B= Filter; C=Hose; A.C.= Hot water; A.F.= Cold Water; A.D.= Decalcified water Fig. 6 Fig. 7 A = Drainage bend tube B = Clamp A = Mains tap B = Filter...
  • Page 4 Fig. 8a Fig. 8b To change to 230 V, the frequency variator must be replaced. Fig. 9...
  • Page 5 A = Prewash detergent B = Wash detergent C = Bleach D = Softener E = Neutralizer Fig. 10 Fig. 11...

  • Page 6: Table Of Contents

    INDEX Pag. 1.- INSTALATION........................ 6 1.1.- Installation outline ...................... 6 1.2.- Positioning........................6 1.3.- Water connection......................6 1.4.- Vapour connection ..................... 6 1.5.- Draining system......................6 1.6.- Electrical connection ....................7 1.7.- Dispenser connection....................7 1.8.- Technical specifications ..................... 8 2.- PROGRAMMING ......................

  • Page 7: Installation Outline

    1.- INSTALLATION 1.1.- Installation outline See figure 1. 1.2.- Positioning The machine must be firmly secured on the floor, which will support the weight of the washer-extractor and the pressure transmitted while spinning. After unpacking the washer-extractor, the pieces that secure the floating part and the chassis, which are necessary for the transportation must be removed.

  • Page 8: Electrical Connection

    1.6- Electrical connection − Gain access to the connection strip by removing the top cover of the machine and fixing the sheathed cable in the rear panel. − Connect the strip and check the engine, heating elements and contactor connections for a correct working tension (fig.

  • Page 9: Technical Specifications

    1.8.- Technical specifications Model DFI–25 MP DFI–57 MP Drum capacity litres Drum diameter 1050 Drum depth Entrance diameter Height 1495 1906 Width 1083 1505 Depth 1238 1459 Net weight 1100 Washing speed Spin speed G Factor Motor output Heating output Heating output Maximum absorbed power 43.5...

  • Page 10: Programming

    2.- PROGRAMMING 2.1.- Keys description The numeric key utiThis numeric key can be used for all selections. During programming it allows to insert a new step in an existing cycle. During execution it allows to check the number of r.p.m. of the drum in the programmed engine. Numeric keys that can be used in all selections.
  • Page 11 The numeric key can be used for all selections. If pressed during the execution of a programme, it disables all the relays outputs, except the draining relay. PAUSE It is disabled during distribution and spin cycles. It controls the door electromagnet. UNLOCK It is only enabled if the programme is not being executed.
  • Page 12 SIGNAL 2 Unbalance The LED lights on immediately after an unbalance situation, indicating the operator that the machine is experiencing unbalance, at least once, during the execution of the programme. It lights off when the cycle or programme finishes. SIGNAL 3 Feeding fault The LED is activated together with the buzzer in intervals of 1 sec.
  • Page 13 PROGRAMMING POWER START + RESET PROGRAMME Nº Programme Nº ENTER EXECUTION ? RESET START ACCESS ACCESS ACCESS ACCESS CODE CODE CODE CODE PROGRAMME ENGINE CYCLE PROGRAMME OPTIONS PROGRAMMING PROGRAMMING SETTING EXECUTION...

  • Page 14: Engine Programming

    2.2.- Engine programming. PROGRAMME n. START + RESET RESET ENTER Edit Motors MOTOR n. nº ENTER Exist ? T. FORWARD = s ALREADY EXIST ! sec nº ENTER ENTER T. PAUSE = s T. FORWARD = sXX sec nº ENTER T.

  • Page 15: Engines Programming

    2.3.- Engines programming. Access code 45 When pressing START and RESET simultaneously, the access code for the engines programming will be requested with the message: Entering 45 and then ENTER, will display for two seconds: EDIT MOTORS Enter the number of the engine action to be programmed (1 to 15): MOTOR No.

  • Page 16: Cycle Programming

    NOTE: Work methods for the engines: FORWARD - PAUSE - BACKWARD T. FORWARD = SXX T. PAUSE = SXX T. BACKWARD = SXX FORWARD - PAUSE T. FORWARD = SXX T. PAUSE = SXX T. BACKWARD = S O FORWARD T.
  • Page 17 Example: PREWASH = n. Enter the required number (between 1 and 99) followed by ENTER, two situations may occur: 1- The selected cycle does not exist in the memory and must be programmed. 2- The selected cycle already exists; in this case it can be displayed and edited. 1- The selected cycle does not exist: the first step programming will be entered immediately and will be displayed for 2 sec.
  • Page 18 Example: LEVEL NO ENTER LEVEL = cm Select the required value followed by ENTER. NOTE: If the cause for the end of a STEP is a temperature or a level the screen will display the next message: WDT = NO Select the time for the WDT.
  • Page 19 NOTE: COOLING PHASE This option is included in the programming steps. Before completing the draining process a cooling step can be carried out. There are 5 parameters to be programmed: MINIMUM LEVEL, MAXIMUM LEVEL, TEMPERATURE, WDT and MOTOR. The operation is as follows: a.- Water discharges to the minimum level b.- Water is loaded to the maximum level and temperature is displayed.
  • Page 20 ENGINE When activated, after pressing ENTER, the number of wash engine related to the required working mode from 1 to 15 is asked. See page 11 Engine Programming. When the required engine has been confirmed with ENTER, the screen will display: RMP = Enter the desired value and press ENTER to confirm.

  • Page 21: Programme Setting

    Press INS and for 2 seconds the following message will be displayed: START STEP X and then to the question: COOLING ? NO it will require to program the new step with the procedure already described. After having added one or more new steps to the memory and confirmed their memorizing, press STOP. d.- Eliminate one or more existing steps.
  • Page 22 1) The programme does not exist: The following message will be displayed on the screen for 2 seconds: NOT FOUND ! then: C>1 ? Pressing ENTER the screen displays: C1> PREWASH = ? By pressing the keys INC and DEC, you can choose the desired type of cycle: Prewash, wash, rinse, spin and unwind.
  • Page 23 Example: C1> RINSE = 1 By pressing the keys INC and DEC the different cycles that form the programme can be displayed. You can modify the programme by entering or eliminating one or more cycles. a.-To erase a cycle you must press the DEL key and the cycle to be erased will be displayed, then press STOP to the question: STORE ? Confirm pressing ENTER.

  • Page 24: Examples

    2.6.- Examples ENGINES PROGRAMMING Resolution - - - - - - - - - - - - - - - - - - - : 1 s Time - - - - - - - - - - - - - - - - - - - - - - : 240 s Min.
  • Page 25 CYCLES PROGRAMMING Prewash No X Wash Rinse Spin Unwind Step 10 11 12 13 14 15 16 17 18 19 20 21 22 Function Cooling Min. level c m = Compensat. Load Max. level c m = Discharge º C = Tem p e r at ur e Cold water m in =...
  • Page 26 PREWASH CYCLE XX CYCLE END CYCLE BEGINNING DISCHARGE HARD WATER FORWARD ENGINE XX OUTLETS BACKWARD DETE R G E N T 1 HEATING TEMPE R A T U R E INLETS LEVEL TIME T IME WDT1 5min. WDT2 4min. WDT2 1min. STEP 1 STEP 2 STEP 3...
  • Page 27 PROGRAMME EXAMPLE PROGRAMME XX 1st CYCLE PREWASH 1 2nd CYCLE RINSE 2 3rd CYCLE WASH 3 4th CYCLE RINSE 2 5th CYCLE SPIN 5 6th CYCLE UNROLL 2 Each programme can include 15 cycles. Each cycle can be repeated several times. VERY IMPORTANT: The drainage preceding each spin must be done at 25 r.p.m.
  • Page 28 PROGRAMME EXECUTION POWER START + RESET PROGRAMME Nº Programme Nº ENTER EXECUTION ? RESET START ACCESS ACCESS ACCESS ACCESS CODE CODE CODE CODE PROGRAMME ENGINE CYCLE PROGRAMME OPTIONS SETTING PROGRAMMING PROGRAMMING EXECUTION...

  • Page 29: Programme Execution

    3.- PROGRAMME EXECUTION 3.1.- Programme execution. In order to carry out a wash programme, the following steps must be followed: Put the dirty clothes in the washer-extractor drum. Close the washer extractor door Press the main switch (1) fig. 9. The pilot lights on. When connecting the programmer, and after each self diagnosing phase, the latter is ready for choosing a programme.
  • Page 30 NOTE: During the heating and load/discharge of water, the safety timer WDT is activated, which controls the whole machine. If it reaches its time, an alarm message will be displayed on the screen, indicating that some of the heating, load or discharge phases have not been completed within the maximum allowed time.
  • Page 31 SLOWING DOWN The slowing down procedure is called during the spin cycle, only when the slow or fast spin engine is activated: 1.-In case of swinging 2.-When the ADVANCE key is pressed 3.-When the STOP key is pressed 4.-During the reinitialization process after a disconnection 5.-When the time for a step ends The slowing down is variable, it depends on the time passed since the engine start and if the engine spins fast or slow.
  • Page 32 POWER DOWN If during the execution of a programme a power failure of less than 1 second occurs, this failure will be ignored. If the power failure lasts more than 1 second, the machine will stop. When the power supply comes back the screen displays "RE-START CYCLE ?" and the POWER-DOWN LED of the front panel (signal 3) lights on.

  • Page 33: Programming

    4.- PROGRAMMING Programme 1 (8 Cycles) Programme 5 (8 Cycles) Prewash 2 Prewash 1 Wash 1 Wash 4 Rinse 1 Rinse 1 Spin 3 Spin 3 Rinse 1 Rinse 1 Rinse 2 Rinse 2 Spin 1 Spin 1 Unwind 1 Unwind 1 Programme 6 (5 Cycles) Programme 2 (8 Cycles)
  • Page 34 ENGINES PROGRAMMING Resolution - - - - - - - - - - - - - - - - - - - : 1 s Time - - - - - - - - - - - - - - - - - - - - - - : 240 s Min.
  • Page 35 Prewash 01 Prewash 02 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Drain Cold water Cold Water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 36 Prewash 03 Prewash 04 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 37 Wash 01 Wash 02 Step Step Function Function Cooling Cooling Load balanced Load balanced Discharge Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 38 Wash 03 Wash 04 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 39 Wash 05 Wash 06 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 40 Spin 01 Spin 02 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 41 Spin 03 Spin 99 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 42 Rinse 01 Rinse 02 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 43 Rinse 04 Rinse 05 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 44 Rinse 06 Rinse 99 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 45 Unwind 01 Unwind 99 Step Step Function Function Cooling Cooling Load balanced Load balanced Rinse Rinse Cold water Cold water Hot water Hot water Unwind Unwind Heating Heating Detergent 1 Detergent 1 Detergent 2 Detergent 2 Detergent 3 Detergent 3 Detergent 4 Detergent 4 Hard water...
  • Page 46 Step Function Cooling Load balanced Rinse Cold water Hot water Unwind Heating Detergent 1 Detergent 2 Detergent 3 Detergent 4 Hard water Relay 16 Relay 11 Relay 12 Relay 13 Engine no. Drum Speed rpm Final step Level (cm) Temp. (ºC) Time...

  • Page 47: Faults Indication

    5.- FAULTS INDICATION The device is constantly controlling the state of temperature and level transductors in order to avoid faults during operation due to the wear of the same. Furthermore, the use of safety timers (WDT), which set a time limit to the water load, discharge and heating phases, avoids possible faults caused by a lack when it comes to filling or emptying the tub or failure to reach the temperature level.
  • Page 48 The most likely causes in this case may be: during the load phase: 1.-Fault in the water inlet solenoid valve 2.-There is no water in the supply line or the flow is very low. 3.-The discharge valve could be clogged, open or closed. 4.-Defective connection between the tub and the level sensor In this case the operator can decide whether to continue with the process, with a reduced water load, by pressing START, or stop the washing process by pressing RESET.

  • Page 49: Service Functions

    6.- SERVICE FUNCTIONS MAINTENANCE WARNING The machine requires automatically the intervention of the maintenance service when reaching a certain number of preselected washes (programmes), through the message: MAINT. REQ. This message is displayed at the beginning of each programme, and it is repeated in each successive START until the maintenance technician disables it.
  • Page 50 TEMPERATURE HISTERESIS ACCESS CODE 209 Through access code 209 the temperature histeresis, initialised at 3 ºC, can be displayed. To change the value press ENTER, the new value (min. 1 and max. 10) and ENTER for confirmation. If the displayed value is correct press RESET to exit. DISPLAYING TEMPERATURE ACCESS CODE 210 - 211 The temperature and the changes made with the INC and DEC keys, can be displayed either in...
  • Page 51 TOTAL NUMBER OF WASHES DISPLAY ACCESS CODE 215 The EL6 is equipped with two counters to control the number of washes (programmes) carried out. The first counter is a simple counter with a value of 65.000 and is used for the total counting of the number of washes.
  • Page 52 EEPROM MEMORY ERASURE ACCESS CODES 220 For maintenance reasons, it is possible a total or partial erasure of the memory. With access code 220, all the programmes and steps will be erased, but the machine parameters and cycle 99 of anti swinging "Unroll-cycle"...
  • Page 53 IMPORTANT: The memory card must be completely inserted with the contacts facing upwards. The insertion and removal of the memory must be carried out with the EL6 disconnected. ADVANCE KEY DISABLING ACCESS CODE 225 Through access code 255 the ADVAN key is disabled during programme execution. Every time this access code is activated, the key is activated or disabled displaying the message "YES"...

  • Page 54: Access Codes

    7.- ACCESS CODES To access press START and RESET simultaneously, then enter the desired number: PROGRAMMING CODES NUM. FUNCTION Cycle programming Programme writing Engine programming CODES FOR MAINTENANCE FUNCTIONS NUM. FUNCTION Language selection: 1 Italian, 2 English, 3 German, 4 Spanish, 5 French Configuration 16 or 24 relays Drum max.

  • Page 55: Installation Precautions

    8.- INSTALLATION PRECAUTIONS For the optimum operation of the machine it is advisable to follow these indications: 1) Install the power unit as close as possible to the control unit. The connection ribbon cannot exceed 20 cm in length. 2) Avoid the routing of powered cables near the two units and the connection ribbon (if possible shield the electronic part from the rest of the installation).
  • Page 56 CYCLES PROGRAMMING Prewash No X Wash Rinse Spin Unwind Step 10 11 12 13 14 15 16 17 18 19 20 21 22 Function Min. level c m = Cooling Compensat. Load Max. level c m = Discharge Tem per atu r e ºC = Cold water m i n =...
  • Page 57 ENGINES PROGRAMMING Resolution - - - - - - - - - - - - - - - - - - - : 1 s Time - - - - - - - - - - - - - - - - - - - - - - : 240 s Min.

  • Page 58: Maintenance

    9.- MAINTENANCE − Daily remove any traces of detergent or liquids from the dispenser drawer. − Never use powdered or abrasive detergents for cleaning; use only water and soap. − Clean the water inlet filters once a month. − Never clean the exterior by water injection; functional parts of the machine could damage. −...

  • Page 59: Faults

    9.2.- Faults PROBLEM CAUSE CORRECTIVE ACTION Spring or shock absorber breakage. Change them Micro is in the wrong position. Position it correctly Micro cable loose. Tie it correctly Micro stop loose. Tighten bolts Spin with excessive Faulty gauge sensor. Change gauge movement or non-existent.
  • Page 60 Maquinaria para lavanderia · Machinery for laundry · Machines pour blanchisserie C/ Energia s/n Pol. Ind. La Quintana 08514 Sant Julia de Vilatorta (Barcelona) · SPAIN Tel.: (34) 93 888 71 53 · Fax: (34) 93 888 76 63 · E-mail:domus@domus.es http://www.domus.es...
