I N S T R U C T I O N
Plasma Presenters Dual Display
Video Conferencing Cart (PPD-Series)
The PPD is a highly functional video conferencing solu-
tion. The cart provides agile mobility for two Large Flat
Panel Displays, side-by-side, with a combined weight of
up to 200 pounds. Optional equipment shelves and video
conferencing accessory shelves can be easily added for
a complete system.
Using the exclusive Q-latch™ Mounting System for
easy installation, the cart provides stable mounting, quick
release and optional security. Additionally, its streamline
shape eliminates trip hazards and allows the display to
roll smoothly up to a conference table
Large swivel casters with lock brakes, pitch adjustment,
and cable management make the cart user friendly.
BEFORE YOU BEGIN
• CAUTION: To prevent damage to the cart, which could affect or void the Factory warranty, thoroughly
study all instructions and illustrations before you begin to install or operate the unit. Pay particular atten-
tion to the "Important Precautions" on Page 1.
• The maximum weight to be installed on the PPD is 200 pounds (90.72 Kg).
• If you have any questions about this assembly, contact Ergo In Demand at 1-800-888-6024 or 541-779-3763
Ergo In Demand, Inc.
1-800-888-6024 541-779-3763 FAX 541-779-0829
4900 Industry Drive
Central Point, Oregon 97502 USA
M A N U A L
PART NO. 8809-000004 (Rev. B)
01-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPD Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Ergo In Demand PPD Series

  • Page 1 “Important Precautions” on Page 1. • The maximum weight to be installed on the PPD is 200 pounds (90.72 Kg). • If you have any questions about this assembly, contact Ergo In Demand at 1-800-888-6024 or 541-779-3763 PART NO. 8809-000004 (Rev. B) Ergo In Demand, Inc.
  • Page 2: Table Of Contents

    Instruction Manual Dual Display Video Conferencing Cart IMPORTANT WARNINGS and CAUTIONS! WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions. CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the corre- sponding instructions.
  • Page 3: Inspect Parts Before Assembly

    Instruction Manual Dual Display Video Conferencing Cart INSPECT PARTS BEFORE ASSEMBLY Inspect The Cart 1. Carefully inspect the cart for shipping damage. If any damage is apparent, call your carrier claims agent and do not continue with the assembly procedure until the carrier has reviewed the damage.
  • Page 4 Instruction Manual Dual Display Video Conferencing Cart Figure 1. Parts...
  • Page 5: Optional Accessories

    Instruction Manual Dual Display Video Conferencing Cart OPTIONAL ACCESSORIES 1. Acrylic Shelf Casters 2. Video Conferencing Shelf ASSEMBLE CART Locking Casters Numbers in ( ) refer to parts shown in Figure 1. Assemble cart as follows: 1. Place base (10) upside down and thread two locking Figure 3.
  • Page 6 Instruction Manual Dual Display Video Conferencing Cart 6. Adjust tilt head to desired tilt by slightly loosening four 1/4-20X5/8” button head cap screws (130) securing tilt head spreaders (50), adjust tilt head to desired angle (angle 0 - 7 1/2º), and tighten four 1/4-20X5/8” button head cap screws (see Figure 6).
  • Page 7: On Cart

    Instruction Manual Dual Display Video Conferencing Cart MOUNT PLASMA DISPLAYS ON CART 1. Measure the distance from the center of your display to its outermost edge. Make sure to leave some space between dis- NOTE: plays when mounted. 2. Using the measurement found in Step 3 and the face- plate (160) as a template, measure from the center of the dual screen mounting bracket (60) to find the correct mounting holes for your application (see Figure 8).
  • Page 8 Instruction Manual Dual Display Video Conferencing Cart Figure 9. Dual Mounting Head with Face Plates Attached Nylon washer between latch and plate 10-24x1/2” Screw Latch 10-24 Nut Figure 10. Install Latch Latch Face Plate Q-latch Q-clamp Q-latch 1/4-20X7/8” Screw Q-lock Figure 11.
