Lifestyle SRGG51103 User Manual

5-burner lp island grill

Advertisement

Quick Links

5-Burner LP Island Grill
Model No.: SRGG51103 / SRGG51103A
Product size assembled:
User Manual
H1240 x W2263 x D847mm (SRGG51103)
H1240 x W1708 x D635mm (SRGG51103A)
Rotisserie kit is an option, which is not included in every carton
Keep the instructions for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRGG51103 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lifestyle SRGG51103

  • Page 1 Model No.: SRGG51103 / SRGG51103A Product size assembled: User Manual H1240 x W2263 x D847mm (SRGG51103) H1240 x W1708 x D635mm (SRGG51103A) Rotisserie kit is an option, which is not included in every carton Keep the instructions for future reference.
  • Page 2: Technical Data

    Technical data SUPPLIED BY: Shinerich Industrial Ltd. 8/F, Noble Center No.1006, 3rd Fuzhong Road Futian District, Shenzhen, China 5-BURNER LP ISLAND GRILL Model No. SRGG51103 / SRGG51103A Product Name 22.2kW (1 g/h) PIN Number Main burners Qn : 17kW (12 g/h) Rotisserie burner 2.6kW (189g/h)
  • Page 3: Before You Start

    Before you start WARNINGS Do’s Dont’s DO NOT USE INDOORS USE OUTDOORS ONLY CAUTION! DANGER!
  • Page 4: Further Information

    Further information Proper use: The barbecue is a gas barbecue for outdoor use. It is designed Never use charcoal, lighter fluid, lava rocks, gasoline, kerosene, to be used exclusively in accordance with these instructions for or alcohol within this product. preparing foods that are suitable for barbecue cooking.
  • Page 5 Assembly CAUTION! GAS DISPLACES OXYGEN Number of people required to assemble Time to assemble 4 hours Tools required supplied supplied...
  • Page 6 Connecting and disconnecting the gas bottle Parts and tools needed than excluded The tube shall be readily visible across its entire length f inspection after installation. DANGER! IGNITION OF ESCAPING GAS Function setting or anti-clockwise opened rotate to the end Possible consequences: 1/4 position Safety measures:...
  • Page 7 Connecting and disconnecting the gas bottle Shutting off the gas bottle (Fig.2-A, 2-B) 7.6m Or anti-clockwise rotate the nut on regulator G1 to release the regulator G1. Use a standard leak detector to ensure all connections are tight. Confirm all barbecue control knobs are in the off positio “...
  • Page 8: Operation

    Operation Using the rotisserie burner Warnings Your grill mayn't be equipped with motor, motor bracket and Before proceeding, make certain that you have assembled the rotisserie fork. The instructions below include operation for grills appliance according to instructions. equipped with a rotisserie burner. Be sure to follow the instructions Use your Barbecue at least 100cm away from any wall or surface.
  • Page 9: Cleaning And Maintenance

    Cleaning and maintenance Tips for better cookouts and longer barbecue life 1. Cooking Grill 1, Use the upper cooking grid (warming rack) for keeping Clean with hot soapy water. To remove any food residue, use a cooked food warm, toasting breads or cooking delicate foods mild cream cleaner on a non-abrasive pad.
  • Page 10: Troubleshooting

    Troubleshooting PROBLEM POSSIBLE CAUSE PREVENTION/CURE Burner will not light Wires or Electrode covered with Clean wire and/or electrode with rubbing alcohol using igniter cooking residue Wipe dry with cloth Electrode and burners are wet Electrode cracked or broken – Replace electrode sparks at crack W ire loose or disconnected Reconnect wire or replace electrode/wire assembly...
  • Page 11: Fixtures And Fittings

    Fixtures and Fittings Components supplied (not actual size) Components supplied (not actual size) Description Visual Description Visual Warming rack Cart shelf Cooking grate Match lighter Flame tamer Rotisserie fork Grill body and cart assembly Grease tray Front support pole Left cabinet front door Right triangle tabletop Side burner cooking grate Left cabinet bottom panel...
  • Page 12 Fixtures and Fittings Fittings supplied (not actual size) Dimensions Visual 6 x 12 mm washer Allen wrench M6 x 12 bolt M6 x 14 screw M4 x 10 screw D4 washer M6 x 10 screw M6 nut M4 nut 6 x 18 mm washer Wrench...
  • Page 13: Getting To Know Your Product

    Getting to know your product...
  • Page 14 Assembly instructions SRGG51103 Step 1.1 - 1.2 - 1.3 - 1.4 - 2.1 - 2.2 - 2.3 - 2.4 - 3.1 - 3.2 - 4.1 - 4.2 - 5.1 - 5.2 - 5.3 - 6 - 7a - 8a - 9 - 10.1 - 10.
  • Page 15 Assembly instructions EE x 16 M4x10 supplied FF x 16 II x 16 supplied DD x 10 M6x14 supplied...
  • Page 16 Assembly instructions DD x 4 M6x14 supplied EE x 4 M4x10 supplied...
  • Page 17 Assembly instructions EE x 16 M4x10 supplied FF x 16 II x 16 supplied DD x 10 M6x14 supplied...
  • Page 18 Assembly instructions EE x 4 M4x10 supplied DD x 4 M6x14 supplied...
  • Page 19 Assembly instructions DD x 4 M6x14 supplied BB x 1 CC x 4 M6x12 JJ x 2 6 x 18 mm...
  • Page 20 Assembly instructions DD x 4 M6x14 supplied BB x 1 CC x 4 M6x12 JJ x 2 6 x 18 mm...
  • Page 21 Assembly instructions KK x 1 DD x 9 M6x14 supplied...
  • Page 22 Assembly instructions 21 22 AA x 2 6 x 12 mm GG x 2 M6x10 supplied HH x 2 supplied M6 x 30 supplied supplied...
  • Page 23 Assembly instructions M6 x 30 BB x 1 CC x 2 M6x12 supplied...
  • Page 24 Assembly instructions M6 x 30 DD x 2 M6 x 14 supplied M6 x 30 BB x 1 CC x 2 M6x12 supplied...
  • Page 25 Assembly instructions M6 x 30 DD x 2 M6 x 14 supplied DD x 8 M6x14 supplied...
  • Page 26 Assembly instructions 10.1 M4 x 10 EE x 2 M4x10 supplied 10.2 M4 x 10 supplied...
  • Page 27 Assembly instructions...
  • Page 28 Assembly instructions M6 x 10 supplied supplied M6 x 10 supplied supplied...
  • Page 29 LIGHT SWITCH WIRE CONNECTING LAYOUT Attach the transformer and grounding wire to the cart rear panel with four M4x10 screws and M4 nuts. Grounding wire M4 x 10 Illustration of wire connection Lamp Switch LED Switch Halogen bulb wire Red wire Red wire Black wire Black wire...
  • Page 30 BURNER SYSTEM ILLUSTRATION WIRE CONNECTING SYSTEM LAYOUT Rotisserie burner assembly Lamp Electrode wire Side burner Rotisserie burner valve assembly Metal hose Side valve assembly Hose Main burner valve assembly Battery compartment LED switch Lamp switch Transformer Main burner igniter wire (in red color, 5pcs) Electrode wire (thick one) Igniter switch wire...
