Model No. HF-TR9750.0
Serial No.
__
USER'S MANUAL
The serial number is found in the
location shown below. Write the
serial number in the space above.
Serial Number Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, please see
HOW TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and in-
structions in this manual before
using this equipment. Keep this
manual for future reference.
www.HotelFitness.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR9750 and is the answer not in the manual?

Questions and answers

Related Manuals for Hotel Fitness TR9750

Summary of Contents for Hotel Fitness TR9750

  • Page 1 Model No. HF-TR9750.0 Serial No. USER'S MANUAL The serial number is found in the location shown below. Write the serial number in the space above. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, please see...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. HOTEL FITNESS is a registered trademark of Hotel Fitness Club, Inc. FREEMOTION is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. Hotel Fitness and FreeMotion Fitness assume no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 19. The treadmill is capable of high speeds. 23. Do not change the incline of the treadmill by Adjust the speed in small increments to placing objects under the treadmill. avoid sudden jumps in speed. 24. Inspect and properly tighten all parts of the treadmill regularly.

  • Page 5: Before You Begin

    Thank you for selecting the new HOTEL FITNESS manual. To help us assist you, please note the product ® TR9750 treadmill. The TR9750 treadmill offers an im- model number and serial number before contacting us. pressive array of features designed to help you The model number and the location of the serial num- achieve your fitness goals.

  • Page 6: Assembly

    ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires only the included hex keys. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.

  • Page 7: Be Used (See How To Move The Treadmill On

    3. Connect the Upright Wire Harness (100) to the Power Wire Harness (57). See the inset drawing. The con- nectors should slide together easily and snap into place. If they do not, turn one connector and try again. IF THE CONNECTORS ARE NOT INSERTED PROP- ERLY, THE CONSOLE MAY BE DAMAGED WHEN THE POWER IS TURNED ON.

  • Page 8: How To Use The Chest Pulse Sensor

    HOW TO USE THE CHEST PULSE SENSOR HOW TO PUT ON THE CHEST PULSE SENSOR each use, it may remain activated longer than nec- essary, draining the battery prematurely. The chest pulse sensor consists of two components— the chest strap and the sensor unit (see the drawing •...

  • Page 9: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT tric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. Plug the power cord into a surge suppressor, Your treadmill features a walking belt coated with high- performance lubricant.
  • Page 10 FEATURES OF THE CONSOLE IMPORTANT: If there is a sheet of clear plastic on the face of the console, remove the plastic. To pre- vent damage to the walking platform, wear clean The console offers an impressive array of features de- athletic shoes while using the treadmill.
  • Page 11 CAUTION: 3. Insert the key into the console. Before operating the Next, stand console, read the following precautions. on the foot • Do not stand on the walking belt when turn- rails of the ing on the power. treadmill. Locate the Clip •...
  • Page 12 HOW TO USE THE MANUAL MODE 4. Change the incline of the treadmill as desired. 1. Insert the key into the console. To change the incline of the treadmill, press the See GETTING STARTED on page 11. Incline increase and de- crease buttons.
  • Page 13 Distance—The center Before using the handgrip pulse sensor, remove section of the main dis- the sheets of clear plastic from the metal contacts. play will show the dis- In addition, make sure that your hands are clean. tance that you have walked or run.
  • Page 14 HOW TO USE A PRESET PROGRAM During the workout, CURRENT SEGMENT the profile will show 1. Insert the key into the console. your progress. The flashing segment of See GETTING STARTED on page 11. the profile represents the current segment 2.
  • Page 15 HOW TO USE A PULSE-DRIVEN PROGRAM When a pulse-driven workout is selected, the name of the selected workout and the total workout time Pulse-driven workouts automatically control the speed will scroll across the main display. The words and incline of the treadmill to keep your heart rate near ENTER AGE and the current age setting will then a target level while you exercise.
  • Page 16 5. Enter a target heart rate setting. When only three seconds remain in the first seg- ment of the workout, a series of tones will sound After you have entered your age, the words and then the speed and/or incline of the treadmill ENTER PERCENT and the current target heart will change, if needed, to bring your heart rate rate setting for the workout will be shown in the...
  • Page 17 HOW TO USE THE FITNESS TEST PROGRAM 5. Press the Start button to start the workout. The fitness test workout measures your relative fitness When you press the button, the main display will level. For the best results, the workout should be used show the words LEVEL 1, indicating that the first at a time when your energy level is high;...
  • Page 18 Note: The Speed and Incline buttons will not The console features a dis- function while the fitness test workout is selected. If play demo mode, designed your pulse is not detected during the workout, the to be used if the treadmill is letters PLS will flash in the main display.

  • Page 19: How To Move The Treadmill

    HOW TO MOVE THE TREADMILL Note: It may be helpful to leave the treadmill at an in- cline while moving it. Before moving the treadmill, make sure that the power cord is unplugged from the wall outlet. Lift Due to the size and weight of the treadmill, moving it Handrails Here requires two persons.

  • Page 20: Preventive Maintenance

    PREVENTIVE MAINTENANCE Regular maintenance is necessary for optimal performance and long life of the treadmill. Please read and follow all instructions below. If the treadmill is not maintained as described, components may wear excessively, the treadmill may be damaged, and the warranty will be voided. If you have questions about maintenance, please see the back cover of this manual.
  • Page 21 TURNING THE WALKING PLATFORM Both sides of the walking platform are designed to be used as walking surfaces. If the surface becomes dam- aged, or if there is any wood showing through the coating, the walking platform can be turned over. The walking platform typically needs to be turned over after approximately 6,000 to 7,500 miles (10,000 to 12,000 kilometers).
  • Page 22 REPLACING THE WALKING BELT When the walking belt becomes worn, it should be replaced. The walking belt will need to be replaced after every 12,000 to 15,000 miles (19,000 to 24,000 kilometers). Please see the back cover of this manual to order a new walking belt.

  • Page 23: Six-Month Preventive Maintenance Record

    SIX-MONTH PREVENTIVE MAINTENANCE RECORD Photocopy this form and use it to record the preventive maintenance performed on the treadmill. Each copy of the form can be used for six months (26 weeks). When maintenance is performed, write the date in the appropriate spaces.

  • Page 24: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the back cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 25 PROBLEM: The walking belt is off-center SOLUTION: a. If the walking belt has shifted to the left: Remove the key and unplug the power cord. Using the included hex key, turn each idler roller bolt 1/4 of a turn in the direction shown. Be careful not to overtighten the walking belt.
  • Page 26 PROBLEM: The displays of the console do not function properly a. Remove the key and unplug the power cord. Remove the 1/4" x 1" Screws (2) attaching the Motor Hood (1), and lift off the Motor Hood. Locate the Reed Switch (34) and the Magnet (16) on the left side of the Pulley (73).

  • Page 27: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning any time. During the first few minutes of exercise, your exercise program, consult your physician. body uses carbohydrate calories for energy. Only after This is especially important for persons over the first few minutes of exercise does your body begin age 35 or persons with pre-existing health...

  • Page 28: Part List

    PART LIST—Model No. HF-TR9750.0 R0409A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description Motor Hood Circuit Breaker 1/4" x 1" Screw Motor Bushing #10 x 1/2" Screw 3/8"...
  • Page 29 Key No. Qty. Description Key No. Qty. Description Controller Wire Hood Bracket, Back 7/32" Hex Key Incline Motor Spacer 5/16" Hex Key Chest Pulse Sensor Power Board #8 x 1/2" Screw 1/4" 3/4" Bolt Transformer Motor Bracket 15ʼ Wire Cable Tie Caution Decal Belt Guide –...
  • Page 31 R0409A...

  • Page 32: How To Contact Customer Care

    Hotel Fitness and FreeMotion Fitness are not responsible or tal/physical therapy settings. This product is not intended to be liable for indirect, special, or consequential damages arising...
