Lineum Star Phantom
Lineum Star Phantom
®
Model ULB48-TD
Dual Color Undercover Interior LED Lightbar
IMPORTANT:
Please read all of the following instructions before installing your new warning light.
Please Note: These instructions are provided as a general guideline only.
Specific mounting and/or wiring, may be necessary and are the sole
responsibility of the installer. Star Headlight & Lantern Co., Inc. assumes no
responsibility for the integrity of the installation for this or any of its products.
PLIT505 REV. B
9/13/17
Advertisement
Summary of Contents for Star Headlight & Lantern Lineum Star Phantom ULB48-TD
- Page 1 Lineum Star Phantom Lineum Star Phantom ® Model ULB48-TD Dual Color Undercover Interior LED Lightbar IMPORTANT: Please read all of the following instructions before installing your new warning light. Please Note: These instructions are provided as a general guideline only. Specific mounting and/or wiring, may be necessary and are the sole responsibility of the installer.
- Page 2 Mounting Please review the Programming section BEFORE mounting your light. There are several options you may wish to set prior to installation. Star Phantom ® line of lights is designed to be mounted on the inside of your vehicle. They are not intended for exterior applications and are not warranted against water damage.
- Page 3 Mounting (CONT'D) This light is designed to be mounted in the rear window of a vehicle using both the forked brackets and the corner post brackets. Failure to use both brackets could result in a faulty mount and will void the warranty. If your vehicle is not compatible with these brackets you must custom design mounting brackets Forked Brackets Corner Post Brackets...
- Page 4 Forked Bracket Installation (CONT'D) 4. Repeat steps 1-3 for the opposite attaching bracket . 5. Determine an appropriate user-supplied screw to penetrate the headliner and securely mount the bracket to the roof brace (or other Mounting mounting location) through the mounting hole in each forked bracket. Hole CAUTION: Take care to ensure when selecting a screw and drilling the hole that it is capable of supporting the weight of the light and that it does not penetrate the...
-
Page 5: Rear Window
CORNER POST BRACKET INSTALLATION 1. After the forked brackets are installed, you will need to attach the corner post REAR WINDOW mounting brackets. 2. Connect one of the double-slotted "L" brackets to one of the slotted straight brackets using one of the screws, a flat washer, a tooth washer, and a nut. - Page 6 Corner Post Bracket Installation (CONT'D) 5. Adjust the mounting brackets so that they rest flat against the corner post on each side of the vehicle. 6. Once the brackets are adjusted to the desired position, tighten all the screws on the brackets.
-
Page 7: Quick Wiring Guide
Wiring For proper installation and full operability, this light requires a 20A ignition switched power source, connections to the negative terminal of the battery, and 4-6 external switches rated for a minimum 1A (user supplied). These lights come with a pre-installed 8-conductor harness. In addition, the cable also contains a bare drain wire and foil shielding. - Page 8 Programming Programming is optional. If the default settings are acceptable, skip to the Operation section. If you will be changing any of the options on your lightbar, this should be done prior to installation. Programmable features include the following: • Traffic Director or Takedown Mode •...
-
Page 9: Pattern Programming
Programming (CONT'D) Pattern Programming Not only does this light have several Patterns to select from, but it also incorporates advanced programming that allows you to select which heads flash On and Off with one another (Phase), and which heads are active in any of the functions (Head Enable). Basic Pattern Selection The first step in programming is to select a basic pattern for each of the 4 modes: •... - Page 10 Programming (CONT'D) Phase Selection (Programmable for Patterns 1-16 only) Each flashing head has two Phases, an “On” phase and an “Off” phase. You can program each head for either Phase, allowing you to customize which heads flash On together and which are Off together. This can be done for your Communication Level 1, Level 2, and TD Warn functions.
- Page 11 Programming (CONT'D) Pattern Cycling of Simultaneous Functions This section is OPTIONAL. ‘Pattern Cycling of Simultaneous Functions’ refers to how the light reacts if you activate more than one function at the same time. This light is programmed such that when you activate one of the Traffic Directing patterns (Left, Right, or Center-Out) at the same time as one of the Warning patterns (Level 1 Flashing, Level 2 Flashing, or TD Warn) they will alternate with the bar producing 3 traffic directing cycles, then 1 Warning cycle, and repeat (ex: Left, Left, Left, Warn, Left, Left, Left,...
- Page 12 Programming (CONT'D) Resetting to Factory Default Settings 1. Connect the Red wire to power and the Black wire to Ground. 2. Flip the Program Mode switch ON position (DOWN in the diagram above). All Traffic Director (or Pursuit) lights should start flashing. 3.
- Page 13 Operating Instructions Functions Switched Through Wires Main control of this light is done though the wires in the harness. They should be connected to +12VDC through several switches (user supplied) as described in the Wiring section. NOTE: RED MUST BE CONNECTED TO POWER BLACK MUST BE CONNECTED TO GROUND TD Warn (White w/Brown)
- Page 14 LED FIVE YEAR LIMITED WARRANTY The manufacturer warrants this LED light against factory defects in material and workmanship for five years after the date of purchase. The owner will be responsible for returning to the Service Center any defective item(s) with the transportation costs prepaid. The manufacturer will, without charge, repair or replace at its option, products, or part(s), which its inspection determines to be defective.
- Page 15 NOTICE Due to continuous product improvements, we must reserve the right to change any specifications and information, contained in this manual at any time without notice. Star Headlight & Lantern Co., Inc. makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 16 -15-...
