Swan Electronics ES4117C Installation Instuctions

Power supply module v1.0

Hide thumbs

(2) 0.01 µF 250 VAC Ceramic Disc Capacitor

(1) ES4117C Power Supply Module v1.0

WARNING: Voltages inside the power supply CAN & WILL KILL YOU! You MUST also know how

to work around HIGH VOLTAGE safely. If you do not, get assistance from someone who does.

PRELIMINARY INFORMATION

Determine the operating status of the power supply before beginning this upgrade. Is the power supply

working now? You need to know where you are starting from or you may have difficulty finding your way

home again.

This module was specifically designed for an easy retrofit into the Swan 117C power supply.

The instructions are step-by-step. It is strongly recommended you read the entire document before you

begin and read each step completely before starting the step. There may be a bit of information gleaned

at the end of the step that you wished you had just a minute earlier. The process of labeling or tagging

wires is strongly recommended on any repair or rebuild project. Wires are color coded but it is a good

idea to label them anyway as referenced in the instructions. Masking tape and a ball point works fine.

( )

Read, re-read and fully understand these instructions prior to beginning this upgrade. Be

sure to perform the steps in the order they are listed. Also, be sure to label wires as they are

disconnected from various points inside the power supply. This will help when the time comes to

re-attach the wires that will be disconnected during installation of the module.

TOOLS THAT YOU WILL NEED TO PERFORM THIS UPGRADE

Long nose pliers

Side cutters, flush cutters, or lead trimmers

Soldering iron and 60/40 electronics solder

Schematic of the Swan 117C power supply (A CORRECTED copy is included at the end of the

instructions)

TOOLS THAT WILL BE HELPFUL IN PERFORMING THIS UPGRADE

Desoldering equipment (desoldering braid or vacuum desoldering tool)

Nut drivers

Wire strippers

Forceps or hemostat clamp

Paper and pencil or digital camera for taking notes and documentation

ES4117C SWAN POWER SUPPLY MODULE v1.0

INSTALLATION INSTUCTIONS

ELECTRONIC SPECIALTIES

53 North 16

Fairfield, Iowa 52556

Phone: 641-472-7084, FAX: 641-472-7620

Email:

PARTS SUPPLIED WITH THIS KIT

Street, PO Box 1960

elespe@lisco.com

(1) 3-Wire AC Line Cord

Table of Contents

Need help?

Do you have a question about the ES4117C and is the answer not in the manual?

Questions and answers

Summary of Contents for Swan Electronics ES4117C

Page 1 ES4117C SWAN POWER SUPPLY MODULE v1.0 INSTALLATION INSTUCTIONS ELECTRONIC SPECIALTIES 53 North 16 Street, PO Box 1960 Fairfield, Iowa 52556 Phone: 641-472-7084, FAX: 641-472-7620 Email: elespe@lisco.com PARTS SUPPLIED WITH THIS KIT (2) 0.01 µF 250 VAC Ceramic Disc Capacitor (1) 3-Wire AC Line Cord (1) ES4117C Power Supply Module v1.0...
Page 2 ES4117C POWER SUPPLY MODULE INSTALLATION INSTRUCTIONS Unplug the AC power cord from the mains outlet and allow time for the high voltage to discharge to 0 VDC. Disconnect the remote power supply cable from the Swan radio. Do not plug in the power cord and re-apply power until you have completed the installation, inspected it and removed any short circuits and stray wire clippings.
Page 3 6. Next is a small BLACK wire that is one end of choke L2, and a small RED lead to one half of the dual-section 40 µF electrolytic capacitor. The three leads described in 5 and 6 are connected to the top end of two 68KΩ 2W resistors in parallel. 7.
Page 4 Unsolder and remove the original AC line cord wire (probably BLACK) from terminal strip lug #1 and clean any excess solder from the lug. Unsolder and remove the original ceramic disc capacitor lead from terminal strip lug #1. Unsolder and remove the other lead of the original ceramic disc capacitor from the ground lug and clean any old solder from the lugs.
Page 5 PCB when it is installed. Place the new power supply PCB over the transformer oriented so that the number ES4117C is toward you but DO NOT attach to the mounting studs until the wiring is completed.
Page 6 TESTING THE ES4117C EXERCISE EXTREME CAUTION IN THE FOLLOWING STEPS To test the supply you will need a voltmeter capable of safely measuring 1000 VDC and 500 VAC.
Page 7 #4 and connect that point to the L1 location on the PCB. Please don’t hesitate to call or write if you have questions or comments. Thank you Paul Kraemer, K0UYA UPDATED SCHEMATIC FOR THE ES4117C SWAN POWER SUPPLY Distributed by: HARBACH ELECTRONICS, LLC Jeff Weinberg – W8CQ...
