Summary of Contents for Laseno SMP-120
-
Page 1: User Manual
Portable Smart Micro Laser Projector User Manual... - Page 2 Thank you for choosing Laseno SMP-120 portable smart micro laser projector. Before using our product, please read this instruction manual carefully. Please read the safety precausions and use the products properly. The content of this user manual might change according to the software version.
- Page 3 Safe Use Precausions To ensure the user’s safety, please read carefully the precausions and use properly this kind of product. Warning: please use the product properly according to the instruction manual. Misuse might cause personal injury. Ｄｏ ｎｏｔ ｕｓｅ ｗｈｅｎ ｄｒｉｖｉｎｇ． Ｐｌｅａｓｅ ｐａｙ ａｔｔｅｎｔｉｏｎ ｔｏ ｔｈｅ ｕｓｅ ｏｆ ｂａｔｔｅｒｙ． It might divert your attention and cause Please do not strike fiercely, or use sharp traffic accidents.
- Page 4 Warning: please use properly this product according to the instruction manual. Misuse might cause personal injury. Ｐｌｅａｓｅ ａｖｏｉｄ ｆａｌｌｉｎｇ ｏｒ ｅｘｔｅｒｎａｌ ｓｔｒｉｋｅ． Ｐｌｅａｓｅ ｕｓｅ ｉｎ ｃｌｅａｎ ｅｎｖｉｒｏｎｍｅｎｔ． It might cause the damages of product The environment with much dust might display and appearance, or the damages of cause the products to work abnormally. internal fittings.
- Page 5 Features Ｌａｓｅｒ ｌｉｇｈｔ ｓｏｕｒｃｅ Ｂｕｉｌｄ－ｉｎ Ａｎｄｒｏｉｄ ｓｙｓｔｅｍ Take laser as light source; auto focus; Based on Android system, it supports 20~50 lumens; working time is over various forms of media play. It is easy to 25,000 hours. check and enjoy music, films, pictures and games whenever and wherever possible.
- Page 6 Mini USB cable Warranty Card 激光移动智能机 ( 微型投影机 ) Portable Smart Micro Laser Projector 用 户 指 南 SMP-120 main part Charger User Manual *The actual fittings might differ from the picture, which will be adjusted according to the actual situations.
- Page 7 Names of different parts Lens Keyboard Interfaces Charger interface USB interface Mini USB interface Earphone interface *USB memory as much as 32GB...
-
Page 8: Charging Instruction
Charging Instruction Connect the DC IN interface of the product and the power box with appendant charger. During charging, LED will be red. When the charging is completed, LED will become green. Charging indicator Charging Charging complete Start up and shut down Press to start up. - Page 9 Self-inspection before the Repair The projector cannot be switched on Please confirm the charging status The projector has abnormal noise Please confirm whether the noise comes from electric fan or other motors. Please confirm whether the file formats are supported. The formats of some files The files cannot be played downloaded from internet cannot be played.
-
Page 10: Key Function
Key function Basic Operation Press on/off to start up, showing main menu. Description Function Long press on/off (4-5 seconds) to shut down. on/off Turn on/Turn off Short press on/off select to shut down or back Cancel/Return enter other modes. Press Home to back to main menu. - Page 11 External Connection – USB memory and other memories USB memory has the character of plug and play. The powerful core supports the display of all mainsteam file formats, videos and audios, pictures, etc. Connect USB memory or mobile hard disk with the product When USB memory is recognized, USB icon on the main screen becomes yellow If it could not recognize USB memory, please confirm to set the USB Settings as Host...
- Page 12 External Connection-Computer It could be connected to a desktop computer or a laptop to browse or install files Connect the USB interface of the computer with USB cable The computer will prompt hardware, meanwhile please drop down the USB incon to select: Selecting 【open the USB memory device】...
-
Page 13: Hardware Specification
Hardware Specification: Light source aser light source 20～50 lumens Brightness Auto focus Focus mode Built-in 1 W single speaker Loundspeaker 3.5mm standard headset jack Audio output 4GB-16GB Memory USB 2.0（Type A） USB HOST USB 2.0（Type AB） USB OTG 116*61*33mm Size Battery working 80 minutes projection;... -
Page 14: Software Specification
Software Specification Android 2.3 System DOC, XLS, PPT, TXT, CHM, UMD, PDB, PDF,OFFICE Document browser JPEG/GIF/BMP/Android2.3 Photo Browser AVI/RMVB/MPEG2/MPEG4/Android2.3 Video Player MP3/WMA/ FLAC/AAC/AC3/OGG/WAV/Android2.3 Music Player... - Page 15 Shanghai Sanxin Technology Development Co.,Ltd. Address：61 Guoshoujing Road, Pudong New Area, Shanghai, ZIP：201203 Tel：86-21-6879 4300 Fax：86-21-6879 4381 Service Hotime：86-400 820 0992 Web Site：www.laseno.com...
