Autowel NICE-80DP User Manual

I.g.b.t. inverter plasma cutting m/c

Advertisement

User
Manual
I.G.B.T.
INVERTER
PLASMA Cutting M/C
NICE -
80DP
NICE - 100DP
NICE - 130DP
Autowel Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NICE-80DP and is the answer not in the manual?

Questions and answers

Summary of Contents for Autowel NICE-80DP

  • Page 1 User Manual I.G.B.T. INVERTER PLASMA Cutting M/C NICE - 80DP NICE - 100DP NICE - 130DP Autowel Co., Ltd.
  • Page 2 2. Users has to pay attention to the subjects set forth Article 3 "installation" when installing the main power units and accessories. Autowel has no liability of accessories, which are consumable and not to manufactured by Autowel - 1 -...
  • Page 3: Table Of Contents

    ◀ CONTENTS ▶ 1. PRODUCT INTRODUCTION 2. CONFIGURATION AND SPECIFICATION 3. INSTALLATION 4. OPERATION AND HANDLING 5. SAFETY INTRODUCTION 6. MAINTENANCE AND INSPECTION 7. TROUBLE SHOOTING Before using welding machine, users have to read the all contents described by manual to have better quality of weld, and to reduce maintenance works.
  • Page 4: Product Introduction

    1. Product introduction Autowel NICE-80(100, 130)DP PLASMA Cutting M/C is controlled by I.G.B.T inverter, and cutting metal plate by Plasma Arc via current(A) with compressed air. The use rate with the low input power and high output is maximized. 2. Configuration and Specification...
  • Page 5 2) Standard specification Type NICE-80DP NICE-100DP NICE-130DP Name AC 220V 1P, 3P AC 220V/380V BOTH Input Voltage 1P, 3P 220V/380V BOTH Input Power 9,6KW 11.2KW 18.2KW Frequency 50/60Hz Max. output current 100A 110A 130A optimal cutting 12mm 15mm 18mm 20mm 25mm max.
  • Page 6: Installation

    3. Installation * Installation Diagram Ground P-80 Torch Description Description MAIN NFB(3Ø 50A, more) Ground (3rd level Ground) Input 5.5SQ and more Torch (P-80) 8M Air Hose inner dia 8mm Earth WCT-14SQ, more Compressor 3HP, more Fig.1 Total Installation Diagram - 5 -...
  • Page 7 Fig. 2 Rear Panel - 6 -...
  • Page 8: Operation And Handling

    4. Operation and handling 4-1. Front panel and name 4-2. Function and explanation 1) Cutting Current : Output current adjustment when cutting base metal. 2) Power Lamp : It turns on when the power on/off switch is on. 3) Cutting Lamp : It turns on during cutting process. 4) Warning Lamp : It turns on when occurring error of air and temperature error of air : not work when air pressure is lower than 2Kgf/cm error of temperature : stop operation when Temperature is over 85 .
  • Page 9 6) Pilot switch : ON- Arc beam is coming out from torch nozzle when cutting the base metal as per non-contact. OFF- use it at low current when cutting the base metal as per contact. 7) Self hold switch : ON- Cutting start when press torch switch, and after torch switch release, cutting is continuously on process, and stop(off) cutting when press torch switch again.
  • Page 10: Maintenance And Inspection

    6. Maintenance and Inspection Check Items POINT Description Period Output Fasten connector Fasten enough 2 months opening cover, and Inner Part Dust 1-3months blow out dry air. open coke of unit, Air Unit water of inner and drain water and everyday dry it.
