Summary of Contents for THERMEx Wasteminator III
- Page 1 Wasteminator III & IV English...
- Page 3 Please read the following before using the food waste disposer: 1, Please read the manual before using the food waste disposer 2, Please look after any child nearby when using the food waste disposer to prevent potential hazards. 3, Please don’t insert fingers into the disposer when the disposer is operating.
- Page 4 Food Waste Disposer Users’ Manual 1.Parts installation drawings B Series installation parts（Picture 1.1） （Picture 1.1） Installation parts disposer discharging parts 1. plug 9. Dishwasher water inlet 10. Rubber seal 2. Sink flange 11. Pipe flange 3. rubber gasket 12. hexagon socket screw 4.
- Page 5 Food Waste Disposer Users’ Manual C series installation parts（picture 1.2） （picture 1.2） Installation parts disposer Discharging parts 1. plug 5. connection house 9. Rubber seal 2. Sink flange and 6. clamp 10. Bend pipe flange splash guard 3. Rubber gasket 7.
- Page 6 Food Waste Disposer Users’ Manual D series installation parts（picture 1.3） （picture 1.3） Installation parts disposer discharging parts 1. Filter and splash guard 11. propeller 13. Rubber seal 2. Sink flange 12.dishwasher water inlet 14. Bend pipe flange 3. Rubber gasket 15.
-
Page 7: Disconnect Sink Drain
Food Waste Disposer Users’ Manual 2.Check the installation size 1. Disposer's height( 1 ) 2. The bottom of sink to the middle of discharging mouth（If not stainless steel sink you are using, please add extra 12mm to this height.）( 2 ) 3. - Page 8 Food Waste Disposer Users’ Manual 5.Attach Upper Mounting Assembly to Sink B Series rubber mounting assembly（Picture 5.1） 1-1. Put one of two rubber gasket under sink flange. Ensure sink hole area is clear of debris and place sink flange/gasket into sink hole. 1-2.
-
Page 9: Connect Disposer To Mounting Assembly
Food Waste Disposer Users’ Manual Note: If the dishwasher connection is made without removing the plug, the dishwasher may overflow. Remove Knockout Plug （Picture 7.1） 1. Lay disposer on its side and insert screwdriver （1） into the dishwasher inlet so tip rests on outer edge of knockout plug. 2. -
Page 10: On/Off Control
Food Waste Disposer Users’ Manual 1. Place metal flange over discharge tube. Insert rubber gasket with gasket lip facing the metal flange into discharge tube. 2. Secure metal flange and discharge tube to disposer with bolts. 3. Rotate disposer so that discharge tube is aligned with drain trap. - Page 11 Food Waste Disposer Users’ Manual 3. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of appliance by a person responsible for their safety.
- Page 12 Food Waste Disposer Users’ Manual ・Grind hard material such as small bones and fruit pits to clean inside of grind chamber. ・Grind citrus, melon rinds, vegetables, and coffee grounds. ・After grinding, run water for at least 15 seconds to flush drain line. ・Switch off or unplug the appliance before attempting to free a jammed rotor with implement.
- Page 13 Food Waste Disposer Users’ Manual to cool for 3-5 minutes and lightly push red reset button on the disposer bottom （See picture 11.2）(Note: for B series DC model, C series and D series, the reset button is located at the side of disposer.) Warranty is determined by the unit serial Number and date of installation.
- Page 16 THErmEx SCANDINAVIA A/S SErVICEAFD.: THErmEx SCANDINAVIA AS Farøvej 30 • 9800 Hjørring • Danmark Tlf.: 98 92 62 33 Tel.: 22 21 90 20 • Fax: 22 21 90 21 E-mail: service@thermex.dk E-mail: service@thermex.no • www.thermex.no THErmEx SCANDINAVIA S.L.U. THErmEx SCANDINAVIA AB Importgatan 12 A •...
