Summary of Contents for Fisher Wallace Stimulator
- Page 1 (800) 692 - 4380 info@fisherwallace.com www.fisherwallace.com Instruction Manual for the Treatment of Chronic, Acute and Post-Operative Pain on the Body...
- Page 2 CES stimulation is in use. High Frequency surgical equipment may not be used when CES stimulation is in use. Do not operate the CES stimulator in close proximity to short-wave or microwave therapy equipment. This device is not suitable for use with oxygen or in the presence of a flammable anesthetic...
- Page 3 There is no danger in using the device if you have dental fillings. Do not allow water to enter this device. The Fisher Wallace Stimulator should not be exposed to environmental conditions where the system may get wet. Adverse Reactions (Very Rare)
-
Page 4: Indications For Use
Device Controls The Fisher Wallace Stimulator has one knob that encompasses both the ON/OFF switch for turning the device ON or OFF as well as adjusting the level of current. -
Page 5: Electrode Preparation
Snap the red and black wires onto the receptacles and then connect the other ends of the wires into the stimulator. Black and red colors should be matched. After use, sponges will dry more quickly if removed from the receptacles and allowed to dry by themselves. -
Page 6: Device Cleaning
Treatment Duration When used on the body, the device may be used 2-3 times a day, for 20-40 minutes per treatment session. The device will turn off automatically after 20 minutes. To reactivate the device for another 20 minutes, turn the dial clockwise to the OFF position until you hear an audible click, and then turn the device back on. -
Page 7: Troubleshooting
Troubleshooting If your device turns off before the 20 minutes are up, or when the device is set down on a table or lightly jarred or tapped, re-insert the batteries. Sometimes the batteries will misalign with the metal receptors in the battery compartment and as a result, the device will turn off when lightly jarred or tapped. -
Page 8: Device Specifications
Telephone (800) 692 - 4380 Fax (800) 657-7362 Electronic Equipment (WEEE) Email info@fisherwallace.com Web www.fisherwallace.com Consult instructions for use Upper and lower Type BF Applied Part Class II Medical Caution: Consult temperature limits This stimulator is internally Electrical Equipment accompanying documents powered only... -
Page 9: Limited 1-Year Warranty
Stimulator, except as herein provided, whether such damage claim shall be based on contract, tort, breach of warranty, or otherwise. This warranty shall not apply to any Fisher Wallace Stimulator which has been repaired, tampered with or altered by someone other than a Fisher Wallace Laboratories representative or technician, or which has been subjected to negligence, accident, mishandling or which has not been used in accordance with the enclosed instructions or for the stated purposes. - Page 10 Gastroenterological Pain Red Lead (+) on the spinous process at level of pain in abdomen or colon Black Lead (-) at pain site Treatment Time Yellow Light Indicator / Amperage Level: 3 or 4 10 - 20 minutes (as needed) 1 - 3 times per day or as needed...
- Page 11 Shoulder Pain (Bursitis) Black Lead (-) contacts focal Red Lead (+) on the base of to pain site the neck Treatment Time Yellow Light Indicator / Amperage Level: 3 or 4 10 - 20 minutes (as needed) 2 - 3 times per day or as needed...
- Page 12 Back Pain Lumbosacral - Non Radicular Lumbosacral - Radicular Black Lead (-) on the Red Lead (+) on the base of spinous process at level of the neck pain in abdomen or colon Treatment Time Yellow Light Indicator / Amperage Level: 3 or 4 20 - 40 minutes (as needed) 2 - 3 times per day or as needed...
-
Page 13: Phantom Limb Pain
Phantom Limb Pain Black Lead (-) Red Lead (+) on the base of the neck Treatment Time Yellow Light Indicator / Amperage Level: 3 or 4 20 - 40 minutes (as needed) 2 - 3 times per day or as needed... - Page 14 Arthritic Pain (Fingers) Black Lead (-) Red Lead (+) on the base of the neck Treatment Time Yellow Light Indicator / Amperage Level: 3 or 4 20 - 40 minutes (as needed) 2 - 3 times per day or as needed...
- Page 15 Elbow Pain Black Lead (-) Red Lead (+) on the base of the neck Treatment Time Yellow Light Indicator / Amperage Level: 3 or 4 20 - 40 minutes (as needed) 2 - 3 times per day or as needed...
- Page 16 Neck Pain Black Lead (-) contacts Red Lead (+) on the base of either radiating site the neck Treatment Time Yellow Light Indicator / Amperage Level: 3 or 4 10 - 20 minutes (as needed) 2 - 3 times per day or as needed...
