Three Pears Bobbin Instruction Manual page 18

6
Slide the SHORT BOLTS
through the centre hole of the
MOUNTING BRACKETS and
screw into the end of the legs.
IMPORTANT:
Make sure the MOUNTING
BRACKET has the correct side
facing up.
7
Place the Bobbin top face
down on a soft surface. Align
the mounting brackets with the
3 slots on the bottom of the
Bobbin top.
Slide the SHORT BOLTS
through the remaining holes
of the MOUNTING BRACKETS
and screw into the nuts in the
Bobbin top.
6x
15
