All manuals and user guides at all-guides.com Service SR2100/ N1S, /C1S Manual Tuner Amplifier STANDBY OPEN/CLOSE MULTI JOG (PUSH ENTER) VOLUME TUNER MODE TUNER BAND MEMORY DISPLAY TIMER PHONES STANDBY OPEN/CLOSE SR2100 TABLE OF CONTENTS TECHNICAL SPECIFICATION ................1 BLOCK DIAGRAM ....................2 SCHEMATIC DIAGRAM AND PARTS LOCATION .......... -
Page 2: Ordering Parts
MARANTZ Parts for your equipment are generally available to our National Marantz Subsidiary or Agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified. -
Page 3: Technical Specification
All manuals and user guides at all-guides.com 1. TECHNICAL SPECIFICATIONS FM TUNER SECTION Frequency Range ............................87.5 - 108.0 MHz Usable Sensitivity ..........................IHF 1.8 V/16.4 dBf Signal to Noise Ratio ........................Mono/Stereo 76/72 dB Distortion ............................Mono/Stereo 0.2/0.3 % Stereo Separation ............................. -
Page 4: Block Diagram
All manuals and user guides at all-guides.com 2. BLOCK DIAGRAM... -
Page 5: Schematic Diagram And Parts Location
All manuals and user guides at all-guides.com 3. SCHEMATIC DIAGRAM AND PARTS LOCATION TUNER MODE TUNER LCD BACK LIGHT LED SU56 SU57 DU51 DU52 DU53 PU74 SU53 SU54 SU55 +12V SU51 SU52 (RLD) RU72 RU71 BAND MEMORY DISPLAY TIMER DOOR SU71 QU53 DU54... - Page 6 All manuals and user guides at all-guides.com C VERSION A101 STDIST PV04 (RTU) ANT N.C GNDGND VT VDD R510 4.7k (RTR) R512 C503 PLL-BLOCK +12V R502 C505 100/10V 1/4W +12V C507 2.2k 2.2/50 L302 C303 0.01 R506 R504 D501 10/50V 4.7k C504 R211...
- Page 7 All manuals and user guides at all-guides.com N VERSION PV04 A101 STDIST (RTU) ANT N.C GNDGND VT VDD (RTR) R510 4.7k R512 +12V C503 PLL-BLOCK R502 C505 100/10V 1/4W +12V C507 2.2k 2.2/50 L302 R504 C303 0.01 R506 4.7k C504 D501 C209 10/50V...
- Page 8 All manuals and user guides at all-guides.com Z005 QB03 QB02 QB01 PB04 AC INLET AC OUTLET QB01 L78MR06 JB01 JB03 RB02 CB06 LB02 AC INLET 10/50V 12.5V 5.9V AC12.8V JB03 1P SW. WB01 UN-INS.UB02 DB03 DB01 4.8V CB05 POWER JB06 UB02 TO J802 (PV04) 0.01...
- Page 9 All manuals and user guides at all-guides.com QN02 QV02 QV06 QV01 QN05 QN03 QN04 QN07 QN06 QD02 QN01 QV03 QV05 QV04 QA01 QA02 QA04 Q202 Q204 Q203 QA03 QA05 Q201 Q501 AUX1 RC-5 Q206 Q301 QV51 PV01 TC7W14FU U035 U034 CN05 DA05 DA06...
- Page 10 All manuals and user guides at all-guides.com PU54 QU51 QU53 QU52 RU61 RU67 RU98 QU53 DU54 DU53 RU72 RU71 SURROUND TU-MODE TUNER BAND MEMORY TIMER RU58 RU59 RU60 RU51 RU52 RU53 DISPLAY RU74 RU68 RU54 RU55 RU56 DU52 SU52 SU53 SU54 SU55 SU56...
-
Page 11: Service Mode
All manuals and user guides at all-guides.com 4. SERVICE MODE 1.Tracking po int memory of present memory L / CD segment luminou s Connect an AC cable plug to mains whil e pressing <DISPLAY>and <ENTER> Turn JOG Turn JOG Turn JOG Press <ENTER>... -
Page 12: Audio Adjustment
All manuals and user guides at all-guides.com 5. AUDIO ADJUSTMENT Main Amplifier Idle Current Adjustment 1. Test Point: Lch: U299 (+), U300 (-) or R737, 0.18 oh ms X2 Rch: U297 (+), U298 (-) or R738, 0.18 ohms X2 2. Adjust Resistor Lch: R719, Rch: R720 3. -
Page 13: Tuner Adjustment
All manuals and user guides at all-guides.com 6. TUNER ADJUSTMENT 1. AM auto stop Level Check Sou rce Sign al Inpu t Signal Sign al Reception Adjust. Adjustment Step Outpu t Level and P–No. Conn ection Frequ ency Frequ ency po int Value Modu lation... - Page 14 All manuals and user guides at all-guides.com 2.3 FM STEREO Distortion Adjustment Adjust the L-channel with the RF sign al mod ulated on ly L-chann el first and con firm the R-chann el with RF signal modu lated on ly R-chann el. Inpu t Signal Sign al Sou rce Sign al Outpu t...
-
Page 15: Ic Data
All manuals and user guides at all-guides.com 7. IC DATA QU51:NJU6450A PIN FUNCTION BLOCK DIAGRAM Page Address Register I / O Buffer Page Address Decoder ~SEG ~COM Line Decoder Line Counter E (RD) Common Displey Timing Timing R/W (RD) Staet Line Register Generator Generator PIN CONFIGURATION... - Page 16 All manuals and user guides at all-guides.com QU01 : MB90583B PIN FUNCTION Pin PORT Name of port Desc ription P20/A16 P-DOWN Power Detect=H Power Detect LOW:SUB-CLOCK P21/A17 ANA .SW/PLL /RDS CLOCK Active H P22/A18 ANA .SW/PLL /RDS DATA OUT Active H Q351:LC72722M P23/A19 ANA .SW/PLL .RDS CE...
- Page 17 All manuals and user guides at all-guides.com Q501:LC72130 QE01:LC75372E BLOCK DIAGRAM BLOCK DIAGRAM PIN CONFIGURATION PIN CONFIGURATION...
-
Page 18: Exploded View And Parts List
All manuals and user guides at all-guides.com 8. EXPLODED VIEW AND PARTS LIST C Version 5 1 2 7 3 X 8 ( K ) 0 0 1 D Z 0 0 5 5 1 5 7 2 X 6 ( U ) ( 0 0 7 C ) GE A R A S S Y . - Page 19 All manuals and user guides at all-guides.com VERS. PART NO. POS. PART NO. DESCRIPTION COLOR (PCS) (MJI) 019B 9965 000 08290 SCREW FOR ESCUTCHEON 327J010110 021B 9965 000 08291 FRONT PANEL 327J248010 025B 4822 526 20213 MAGNET KIT 271K305500 031B 9965 000 08292 BUTTON L 327J270050 033B...
-
Page 20: Electrical Parts List
All manuals and user guides at all-guides.com 9. ELECTRICAL PARTS LIST NOTE ON SAFETY FOR FUSIBLE RESIST OR : ASSIGNMENT OF COMMON PARTS CODES. RESISTORS The suppliers and their type numbers of fusible resistors are as 1) GD05 x x x 140, Carbon film fixed resistor, 5% 1/4W follows ;... - Page 21 All manuals and user guides at all-guides.com VERS. VERS. POS. PART NO. POS. PART NO. PART NO. PART NO. DESCRIPTION DESCRIPTION COLOR (PCS) COLOR (PCS) (MJI) (MJI) PB04-BACK UP POWER PU04-CAPACITORS(COMMON) SUPPLY CIRCUIT BOARD PLASTIC FILM CAPACITOR PB04-CAPACITORS 5% 50V : CU08 CU15 CB01 9965 000 06706 CER.
- Page 22 All manuals and user guides at all-guides.com POS. VERS. PART NO. POS. VERS. PART NO. PART NO. PART NO. DESCRIPTION DESCRIPTION COLOR COLOR (PCS) (PCS) (MJI) (MJI) QU20 9965 000 08323 IC S-80843ALNP-EA7-T2 HC10098530 QU51 9965 000 08223 IC NJU6450A HC10215090 QU31 QU53...
- Page 23 All manuals and user guides at all-guides.com POS. VERS. PART NO. POS. VERS. PART NO. PART NO. PART NO. DESCRIPTION DESCRIPTION COLOR COLOR (PCS) (PCS) (MJI) (MJI) CN04 4822 124 41539 ELECT 47 F M 16V OA47601620 C505 4822 124 90357 ELECT 2.2 F M 50V OA22505020 CN05 4822 122 40617 CER.
- Page 24 All manuals and user guides at all-guides.com VERS. PART NO. VERS. POS. POS. PART NO. PART NO. PART NO. DESCRIPTION DESCRIPTION COLOR COLOR (PCS) (PCS) (MJI) (MJI) R725 D503 N 4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000 4822 050 26809 5% 1/6W GG05680160 30V 0.1A...
- Page 25 All manuals and user guides at all-guides.com POS. VERS. PART NO. PART NO. DESCRIPTION COLOR (PCS) (MJI) Q712 4822 130 11033 TRS. 2SC5196 R OR O HT351962A0 Q713 4822 130 11034 TRS. 2SA1939 R OR O HT119392A0 Q714 4822 130 11034 TRS. 2SA1939 R OR O HT119392A0 Q717 4822 209 83732 IC AN7062 V-AMP IC...
