Using the ModelSource 640-pin Generic Device Adapter To search the entire manual set, press this toolbar button. For help, refer to intro.pdf. Release R3.6b November 2001...
Page 2
All rights reserved. Printed in USA. Information in this document is subject to change without notice. Synopsys and the Synopsys logo are registered trademarks of Synopsys, Inc. For a list of Synopsys trademarks, refer to this web page: http://www.synopsys.com/copyright.html All company and product names are trademarks or registered trademarks of their respective owners.
Describes the application note and lists the typographical conventions and symbols used in it; tells how to get technical assistance. Describes the hardware and software needed to create a Logic Model using the 640-pin Generic Device Adapter. Synopsys, Inc. Preface ...
Daughterboard. Briefly outlines software development tasks and provides references. Describes mounting the Adapter onto the Modeling Systems; labeling the Daughterboard; verifying the model; and unmounting the Adapter. Provides a pinout listing for J1-J6 connectors. Synopsys, Inc. November 2001...
( [pin2 ... pinN]). Getting Help If you have a question while using Synopsys products, use the following resources: 1. Start with the available product documentation installed on your network or located at the root level of your Synopsys CD-ROM. Every documentation set contains...
The Synopsys Website General information about Synopsys and its products is available at this URL: http://www.synopsys.com Comments? To report errors or make suggestions, please send e-mail to: doc@synopsys.com To report an error that occurs on a specific page, select the entire page (including headers and footers), and copy to the buffer.
The DUT can include more than one physical package, as long as the components fit within an area approximately 6” x 6”. One 640-pin Generic Device Adapter Daughterboard, henceforth referred to as the “Daughterboard”, to which you attach the DUT.
User-created Shell Software files, described in the Shell Software Reference Manual. The product-specific Shell Software files GEN640.ADP and GEN640.PKG, provided by Synopsys and described in later text. R3.3b or later of the Runtime Modeler Software. The lm utility, R3.3b or later, for labeling the Daughterboard.
Connectors J1-J6: These are to be installed from the far side, and are designed to mate with corresponding connectors on the Adapter. The location of Pin A1 of each connector is indicated on the drawing. Details of the connector pins are provided in text that follows. November 2001 Figure 3 on page Synopsys, Inc.
Page 12
Chapter 2: Building the Daughterboard The ModelSource 640-pin Adapter Figure 1: 640-pin Adapter Daughterboard Synopsys, Inc. November 2001...
As with connectors J1 and J3, the left (signal module) side has rows B and E exclusively connected to ground. The right (power module) side has no rows B, C, or E. November 2001 Figure 2 shows details of J1–J6 connector “J1–J6 Connector Pinouts” on Synopsys, Inc.
Twelve Southco retractable screw fasteners, 47-65-221-70. To mount the stiffeners: Fourteen 4-40 1/4” pan head Phillips screws One Teradyne Signal Module Two Teradyne Power Modules Rows B, C, and E do not exist Synopsys, Inc. November 2001...
One EEProm, Catalyst semiconductor CAT93C86. Note The above does not include the package type designation; that is up to the model designer. Two Synopsys board stiffeners (short), 600-00193 (or build according to specifications). Two Synopsys board stiffeners (long), specifications). Figure 3 shows a drawing of the short and long board stiffeners.
For ease of testing, create test points for the following signals: J1-D17 (KEEPALIVE) J1-A15 (TRIGGER) J1-A19 (PLAY) J1-A17 (SAMPLE) Any voltages used by the DUT “J1–J6 Connector Pinouts” on page Synopsys, Inc. November 2001...
Page 17
Power Supply +5V DC, 6A max ADJVCC1 +3-5V DC, 6A max ADJVCC2 +3-5V DC, 6A max -5.2V DC, 400mA max P12V +12V DC, 400mA max FANP12V +12V DC, 400mA max (for fan/heat sink only) Synopsys, Inc. Table 1. Do not...
Page 18
Chapter 2: Building the Daughterboard The ModelSource 640-pin Adapter Synopsys, Inc. November 2001...
Ejectors for disconnecting the Daughterboard from the Adapter Guide pins that fit the Daughterboard guide pin holes to ensure correct orientation Test points for the signals TRIGGER, KEEPALIVE, PLAY, FEEDBACK, SAMPLE, ADJVCC1, +5V, -5V, and GND November 2001 Synopsys, Inc.
Page 20
Mates with J4 Test Points Mates with J5 Mates with J1 Test Points Figure 4: The 640-pin Generic Device Adapter Ejector Ejector Synopsys, Inc. Guide Mates with J3 Mates with J6 Mates with J2 Test Points November 2001...
To disconnect the Daughterboard from the Adapter, follow these steps: 1. Remove the lid from the Adapter. 2. Loosen the Southco retractable screw fasteners. 3. Push the ejectors on the Adapter. 4. Carefully lift the Daughterboard from the Adapter. 5. Replace the Adapter lid. November 2001 Synopsys, Inc.
Page 22
Chapter 3: Connecting the Daughterboard The ModelSource 640-pin Adapter Synopsys, Inc. November 2001...
As for all Generic Device Adapters, you must create one or more Shell Software files that contain DUT-specific information, such as pinouts, device names, propagation delays, timing checks. Files Provided by Synopsys The Adapter Mapping (.ADP) file, GEN640.ADP: This file provides signal mapping between the Adapter and the ModelSource modeling system. You should be able to use this file without modification.
Page 24
Figure 5 shows part of the template GEN640.PKG file provided by Synopsys. {*******************************************************************} {* Copyright (c) 2001by Synopsys, Incorporated {*All rights reserved. {*******************************************************************} {* Logic Model PACKAGE map file for Generic 640 Device Adapter. {*******************************************************************} { package_map_revision {*******************************************************************} package_mapping J1A2...
Each modeling system has a knob on the right and on the left side for moving the top and bottom modeling boards, respectively, backwards and forwards. Turn each knob individually counterclockwise to bring each modeling board forward to connect with the Adapter. November 2001 Completing the Model ModelSource User’s Manual. Synopsys, Inc.
Note The pattern memory available for simulation is limited to the smallest amount of available memory on any one of the eight modeling boards in the four modelers. and the Logic Model Development Synopsys, Inc. ModelSource User’s Manual. November 2001...
4. Push the Adapter so that it is flush against the front panel of the modeling system assembly, and slide it up as far as you can. 5. Pull the Adapter straight out and away from the modeling system assembly. November 2001 Synopsys, Inc.
Page 28
Chapter 5: Completing the Model The ModelSource 640-pin Adapter Synopsys, Inc. November 2001...
The pinouts for connectors J1 through J6 of the 640-pin Adapter and the Daughterboard are listed in Table 2. Do not use pins that are labeled RESERVED. Table 2: Pinouts for Connectors J1-J6 Connector November 2001 Signal SEAT1 DUT171 DUT173 DUT170 DUT169 DUT168 DUT167 DUT166 DUT165 DUT164 DUT163 DUT162 DUT161 TRIGGER Synopsys, Inc.
Page 30
Table 2: Pinouts for Connectors J1-J6 Connector Signal SAMPLE PLAY DUT198 DUT197 DUT196 DUT202 DUT194 DUT193 DUT192 DUT191 DUT190 DUT189 DUT188 DUT187 DUT186 DUT185 DUT226 DUT225 DUT224 DUT223 DUT222 DUT221 Synopsys, Inc. November 2001...
Page 31
Table 2: Pinouts for Connectors J1-J6 Connector November 2001 Signal DUT220 DUT219 DUT218 DUT217 DUT237 DUT215 DUT214 DUT213 DUT172 DUT174 DUT175 DUT176 DUT177 DUT178 DUT179 DUT180 DUT181 DUT182 DUT183 DUT184 TEMP Synopsys, Inc.
Page 32
Table 2: Pinouts for Connectors J1-J6 Connector Signal DUT199 DUT200 DUT201 DUT195 DUT203 DUT204 DUT205 DUT206 DUT207 DUT208 DUT209 DUT210 DUT211 DUT212 DUT227 DUT228 DUT229 DUT230 DUT231 DUT232 DUT233 DUT234 Synopsys, Inc. November 2001...
Page 33
Table 2: Pinouts for Connectors J1-J6 Connector November 2001 Signal DUT235 DUT236 DUT216 DUT238 DUT239 DUT240 DUT11 DUT13 DUT10 DUT9 DUT8 DUT7 DUT6 DUT5 DUT4 DUT3 DUT2 DUT1 FEEDBACK KEEPALIVE Synopsys, Inc.
Page 34
Table 2: Pinouts for Connectors J1-J6 Connector Signal DUT38 DUT37 DUT36 DUT42 DUT34 DUT33 DUT32 DUT31 DUT30 DUT29 DUT28 DUT27 DUT26 DUT25 DUT66 DUT65 DUT64 DUT63 DUT62 DUT61 DUT60 DUT59 DUT58 DUT57 DUT77 Synopsys, Inc. November 2001...
Page 35
Table 2: Pinouts for Connectors J1-J6 Connector November 2001 Signal DUT55 DUT54 DUT53 DUT12 DUT14 DUT15 DUT16 DUT17 DUT18 DUT19 DUT20 DUT21 DUT22 DUT23 DUT24 EEOUT EEIN EECLK EEPE EESEL EEVCC DUT39 DUT40 Synopsys, Inc.
Page 36
Table 2: Pinouts for Connectors J1-J6 Connector Signal DUT41 DUT35 DUT43 DUT44 DUT45 DUT46 DUT47 DUT48 DUT49 DUT50 DUT51 DUT52 DUT67 DUT68 DUT69 DUT70 DUT71 DUT72 DUT73 DUT74 DUT75 DUT76 DUT56 DUT78 DUT79 Synopsys, Inc. November 2001...
Page 37
Table 2: Pinouts for Connectors J1-J6 Connector November 2001 Signal DUT80 SEAT1 SEAT2 DUT160 DUT159 DUT158 DUT136 DUT156 DUT155 DUT154 DUT153 DUT152 DUT151 DUT150 DUT149 DUT148 DUT147 DUT132 DUT131 DUT130 DUT129 DUT128 DUT127 Synopsys, Inc.
Page 38
Table 2: Pinouts for Connectors J1-J6 Connector Signal DUT133 DUT134 DUT135 DUT157 DUT137 DUT138 DUT139 DUT140 DUT141 DUT142 DUT143 DUT144 DUT145 DUT146 DUT105 DUT106 DUT107 DUT108 DUT109 DUT110 Synopsys, Inc. November 2001...
Page 39
Table 2: Pinouts for Connectors J1-J6 Connector November 2001 Signal DUT91 DUT93 DUT90 DUT89 DUT88 DUT87 DUT86 DUT85 DUT84 DUT83 DUT82 DUT81 DUT118 DUT117 DUT116 DUT122 DUT114 DUT113 DUT112 DUT111 Synopsys, Inc.
Page 40
Table 2: Pinouts for Connectors J1-J6 Connector Signal DUT92 DUT94 DUT95 DUT96 DUT97 DUT98 DUT99 DUT100 DUT101 DUT102 DUT103 DUT104 DUT119 DUT120 DUT121 DUT115 DUT123 DUT124 DUT125 DUT126 SEAT2 ADJVCC1 Synopsys, Inc. November 2001...
Page 41
Table 2: Pinouts for Connectors J1-J6 Connector November 2001 Signal ADJVCC1 ADJVCC1 ADJVCC1 P12V P12V P12V P12V SEAT3 Synopsys, Inc.
Page 42
Table 2: Pinouts for Connectors J1-J6 Connector Signal DUT640 DUT639 DUT638 DUT616 DUT636 DUT635 DUT634 DUT633 DUT632 DUT631 DUT630 DUT629 DUT628 DUT627 DUT612 DUT611 DUT610 DUT609 DUT608 DUT607 DUT606 DUT605 DUT604 DUT603 DUT595 Synopsys, Inc. November 2001...
